Alpine HCE-C114 Universal rear-view camera

The new Alpine HCE-C114 rear view camera system offers color image reproduction and has a LUX (luminance emittance) range of 1.5-100,000, delivering improved picture performance in low-light conditions. It comes with a 23-ft RCA cable, for easier installation in large vehicles.

Back up better

The Alpine HCE-C114 rear-view camera is an excellent add-on when you’re buying a new touchscreen car stereo. With low light capability and a wide viewing angle, you’ll have a perfect picture of what’s behind your vehicle, day or night.

This tiny camera measures less than one square inch, so it’ll fit just about anywhere. The package includes a 21-foot cable with composite video RCA plugs that allows the camera to connect to any in-dash receiver or front-mount screen with a composite video input.

Frame it

Looking for another mounting option? The HCE-C114 is compatible with Alpine’s KTX-C10LP license plate mounting kit (not included).

Universal Rearview Camera:

Add the Alpine HCE-C114 universal rearview camera to your vehicle’s aftermarket in-dash receiver with monitor for added safety when backing in and out of a parking space. The rearview camera assists you, the driver, in checking behind your vehicle by sending images to your in-dash receiver’s monitor, showing conditions behind the car.

1/4″ CMOS Image Sensor:

The HCE-C114 is equipped with a 1/4″ CMOS image sensor with an effective resolution of 640 x 480 (307,000 total pixels). The image sensor offers automatic metering and automatic white balance adjustment for high-quality rearview images. The image sensor has an illumination range of 1.0 to 100,000 lux.

Wide-Angle Lens:

The rearview camera’s wide-angle lens has a focal length of f=1.28mm and brightness of f=24, with a 132° (h) x 105° (v) field of view. Because this is a wide-angle lens, there is a difference in distance perspective between what is normally seen behind the vehicle and what appears on the screen of your in-dash receiver.

Weatherproof Housing:

The Alpine HCE-C114 employs a weatherproof (IP67) housing to protect the backup camera from the outdoor elements.

Composite Video Output:

The included 23′ composite video cable allows you to connect the Alpine HCE-C114 universal rearview camera to any aftermarket receiver with a composite video camera input and built-in screen. You can also swap out the 23′ composite video cable for a shorter or longer composite video cable.

Power & Ground Harness:

The Alpine HCE-C114 features an attached 5′ power & ground harness. The power wire (red) of the harness must be connected to the positive side of your vehicle’s rear lamp, while the ground wire (black) needs to be connected to your vehicle’s metal chassis.

Included Mounting Bracket:

The included mounting bracket allows you can be install the backup camera on the rear bumper or by the license plate of your SUV, truck, van, or car. The mounting bracket attaches to the camera with two included screws. The mounting bracket also has an adhesive backing, along with four included screws to secure the camera to your vehicle. Once mounted, you can adjust and tilt the mounting bracket up or down for the best camera angle and view.
