Clarion XC2510 Compact Class D 5-Channel Marine Amplifier – 50 watts RMS x 4 at 4 ohms + 300 watts RMS x 1 at 2 ohms – #92761

Clarion’s XC2510 5-channel amplifier delivers 50 watts RMS to your front and rear speakers while sending up to 300 watts RMS to a sub, all from a chassis that’s just slightly larger than your hand. This micro-sized amp can fit almost anywhere, even behind many dashboards. And Clarion managed to pack more watts per square inch inside this little powerhouse than almost any other 5-channel amp made.

Ready for outdoor work

The XC2510’s circuits are coated on both sides for protection, so this amp is a great candidate for powering speakers and subs in ATVs, boats, and other challenging applications. Clarion nickel-plated all the connectors to resist corrosion and ensure electrical flow, even during harsh conditions.

Super-clean signal

The XC2510’s input circuitry resists the electronic noise common in cars, so you will enjoy clean, distortion-free music. Soft turn-on and turn-off circuitry prevents potentially damaging thumps to your system as it powers on or off.

Variable high-pass filters help you clarify the sound by eliminating the extremely low bass that your speakers can’t reproduce, while a low-pass filter eliminates the higher frequencies from the subwoofer to clean up your bass. A bass boost on the sub channel lets you emphasize the low-end thump. You’ll also appreciate the high-level inputs, so you can hook this amp up to almost any system, even to factory radios without RCA connections.

Circuit Design Achieves High Quality Sound

Clarion amplifiers feature uncompromising resistance to magnetic noise, thereby minimizing distortion, as well as high quality terminals to offer low electrical and contact resistance. Easy subwoofer system configuration is possible with the embedded high pass and low pass filters. The result is high quality sound you can enjoy in a variety of systems.

Corrosion Resistant RCA and Connectors on All XC series Amplifiers

By utilizing corrosion resistant RCA and Connectors, XC series amplifiers offer improved durability and reliability in harsh environments. The XC series amplifiers are true marine amplifiers with efficient aluminum heatsinks and locking power terminals for the harsh marine conditions.

MOS-FET Power Amp

There’ s only one way for Clarion’ s main units to deliver unyielding power output and linearity: MOS-FET amplification, or Metal Oxide Semiconductor Field Effect Transistor amplification. Smaller and more efficient than conventional power supplies, a MOS-FET amplification circuit delivers power with less distortion and zero On/Off switching noise. This means you can crank up the volume or set it to easy listening. Either way, your sound will be crystal clear.

HIgh-Density Amp with Four-Layer Circuit Board

A four-layer circuit board topology reduces noise interference while filtering signals to produce high-quality sound.

2-Ohm Stability

Utilizing this design for peak performance and unwavering reliability, Clarion’s amplifiers can drive lower impedance loads for increased power.

CEA 2006 Power Ratings

50W × 4 + 200W x 1 RMS [4Ω @ ≤ 14.4V 1% THD+N]
75W x 4 + 300W x 1 RMS [2Ω @ ≤ 14.4V 1% THD+N]
S/N ≧ 70dB (Ref: 1W into 4Ω)

XC2510 Features:

• 700 Watts of Maximum Power Output
• 50 Watts × 4 + 200 Watts × 1 Continuous @ 4-Ohms
• 75 Watts × 4 + 300 Watts × 1 Continuous @ 2-Ohms
• 150 Watts × 2 Continuous @ 4-Ohms Bridged
• 4 Layer Conformal Coated PCB Assembly
• Bass Boost Adjustment
• MOS-FET Power Supply
• 12dB/Oct. Low/High Pass Electronic Crossover. Variable 35-250Hz (SUB) / 15-250Hz (FR/RR)
• Variable Gain Control
• Turn-On/Off Muting Circuitry (Soft Mute)
• Ground Loop Isolation Input Circuit
• Corrosion Resistant Nickel Plated RCA, Power, and Speaker Connections
• RCA and High Level Speaker Inputs
