Hertz HCP 4M 4 Channel Marine Amplifier

HCP 4M | Ch: 4 – 3 – 2 | 760 W

HCP 4M four channels  marine amplifier feature a compact design ready to face the open water environment, providing tons of clean power. The HCP M heat sink has been crafted from extruded aluminium, a material unmatched for lightness, robustness and heat dissipation. To keep size to a minimum, the power transistors are placed between the PCB and the top side of the heat sink where heat is gathered. Built up heat is then directed to the special dissipation “wings” along the side of the amplifier. Both Pre-In and Speaker-In inputs feature a special balanced circuitry, ensuring high rejection against electro-magnetic interferences for noise-free results. The HCP M amplifiers crossover section ensure extreme flexibility: fully adjustable Lo-pass, Hi-pass filters with 12 dB/Oct. and 24 dB/Oct. slopes according to the amplifier model; Bass Boost is also available to enhance low frequencies. The HCP 4 M fourchannel model features also an extended frequency range filter, which can be used when designing active 2-way speaker systems.

HCP 4M Features:

1. Engineered and tested for the real environment of application (UV, salt-fog, vibrations, high/low temperature, thermal shock, dust).
2. Compact design built from extruded aluminium heatsink with top side ensuring effective heat transfer.
3. Power supply featuring multiple winding transformer, LOw-ESR 105 degree C capacitors, AB-Class 2Ohm stable output stage.
4. Lo-Pass (50 Hz to 500 Hz) and Hi-Pass (80 Hz) 12 dB crossover filters providing the ability to build a front + rear or a sub + front system.
5. Bridge operation mode to drive a subwoofer or to create a powerful dual-mono system.
6. Bass Boost adjustable via selector, for more punch from speakers.
7. Special balanced input circuitry to reject electro-magnetic disturbances.
8. Hi-Level and Lo-Level inputs to be compatible with any source
9. Short-circuit and thermal protections with auto resetting

HCP 4M Physical Specs

• A – 315 mm – 12.40 in
• B – 291 mm – 11.45 in
• C – 190 mm – 7.48
• D – 166 mm – 6.53 in
• E – 50 mm – 1.97 in
