Hertz HMD1 24V Class D 1000W Mono Marine Amplifier

Brand: Hertz
Model Number: HMD124V
UPC:
Model Number: HMD124V
UPC:
Free Shipping

Save $210.00

$1,189.99

$1,399.99

|

OR

|

Payments as low as

$99.17/mo

PayBright
Special Order

Availability: IN STOCK

Hertz HMD1 24V Mono Marine Amplifier

  • IP64 Certification
  • Corrosion Resistant
  • Salt Fog Proof
  • Water Jet Tested
Special Order

Product Description

Features & Specifications

Documents

Warranty

Hertz HMD1 24V Class D 1000W Mono Marine Amplifier

HMD1 24V | Ch: 1 | 1000 W

HMD1 24V mono amplifier is the perfect solution to add one or more marine subwoofer to your vassel, being the ideal power extension of HMD8 DSP. At 1 Ohms it is stable and can supply up to 1000 W of power with extremely compact dimension. Ultra power in comapcty Size.

Advanced Class D

Thanks to the Hertz advanced D-CLASS output stage, HMD1 joins maximum sound quality with unmatched efficiency to be very compact and easily installed in any position of the boat.

Corrosion Protection

Electronics components corrosion caused by exposure in wet environments is totally neutralized by the use of dedicated Marine grade (epoxy coated) PCB boards.

Salt Fog Proof

To satisfy the standards required by ASTM-B117, Hertz Marine products are tested with massive salt fog spray to ensure a complete resistance to corrosion, typical of this atmospheric agent.

Water Jet Tested

The protection grade IP64 define all the Hertz Marine products as totally protected against water jets of different entities, making them highly performant in the marine environment.

HMD1 24V Physical Specs

HMD1 24V

  • Max size W x H x D (mm/inch): 243 x 48 x 159 mm | 9.56 x 1.8 x 6.25 in
  • Weight (kg/lbs): 1,98 (4.36)
Brand Hertz   Model Hertz HMD124V
Product: Hertz HMD1 24V Class D 1000W Mono Marine Amplifier
General Specs

Channels: 1

POWER SUPPLY
Power supply voltage / fuse: 11 ÷ 15 VDC / 2 x 30A
Operating power supply voltage: 6.5 ÷ 17 VDC
Idling current: 1.3 A
Idling current off: 0.05 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power: 50 A
Remote IN: 6.5 ÷ 15 VDC (1 mA)
ART – Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable): 2 ÷ 7 VDC

AMPLIFIER STAGE
Distortion – THD @ 1 kHz, 4Ω, 70% Rated Power: 0.1%
Damping factor @ 1 kHz, 4Ω, 2 VRMS: 140
Bandwidth @ -1.5 dB: 10 Hz ÷ 500 Hz
S/N ratio (A weighted @ 1 V Input) Master Input: 110 dBA
Input sensitivity Pre-In: Selectable: 0.6 – 2.0 – 6.0 VRMS
Input sensitivity Speaker-In: Selectable: 2.0 – 6.5 – 20 VRMS
Minimum load impedance: 1Ω
Adjustable Crossovers: yes

Output Power

1Ch @ 4Ω: 500 W
1Ch @ 2Ω: 800 W
1Ch @ 1Ω: 1000 W
Total Power RMS: 1000 W

Inputs / Filters

Pre-In Inputs RCA
Speaker-In Inputs Wired

Mobile Amplifier Channels

1 Channel (Mono)

Mobile Amplifier Class

Class D

Mobile Amplifier Features

DSP Processing

Mobile Amplifier Fuse Rating

50

Mobile Amplifier RMS

751 watts and Up

Mobile Min Impedance

1
