Hertz HMX 6.5 S 6.5″ 2-Way Marine/Powersports Coaxial Speakers

HMX 6.5 S | 165 (6.5) mm (in.) | 95,6 (3.76) mm (in.) | Two Way Coaxial | 150 W | 4 Ohm

The HMX 6.5 S hi-performance powersport coaxial speakers is optimized to perform in infinite baffle, with a solid bass and an outstanding output. The  tweeter feature an acoustic lens optimized for best off-axis dispersion and maximized SPL. The attractive stainless steel tweeter mesh grille provides perfect high-frequency transfer and a rock-solid protection. The UV resistant polypropylene cone co-molded with Santoprene rubber surround together with the basket and grille injected with a Hi-temperature and UV resistant polymer neutralize water, dust and mud. The aramid fiber spider with silicone-insulated lead wires ensures durability and constant performance over time. The high-excursion mobile equipment is driven by a massive magnetic group, to deliver high undistorted sound pressure.

HMX 6.5 S Features

1.  Engineered and tested for the real environment of application (UV, salt-fog, vibrations, water spray, thermal shock, dust).
2.  1.4” Neodymium magnet tweeter featuring a PEI material dome combined with faceplate and acoustic lens optimized for best off-axis dispersion and highest SPL.
3.  Sound-transparent stainless steel tweeter mesh grille providing efficient high-frequency transfer, attractive look and a rock-solid protection.
4.  Long-throw 25mm (1”) voice coil woofer fine-tuned for infinite baffle application featuring polypropylene cone injected with UV inhibitors and comolded Santoprene surround.
5.  Aramid fiber spider with silicone-insulated lead wires ensuring durability and constant performance over time.
6.  FEM optimized high-excursion mobile equipment driven by a massive magnetic group encapsulated into a marine-grade polymer injected basket.
7.  Sealed built-in crossover with resettable solid-state tweeter protection circuit.
8.  Gold-plated corrosion resistant terminals.

HMX 6.5 S Physical Specs

• A – 172,2 mm – 6.78 in
• B – 128 mm – 5.04 in
• C – 95,6 mm – 3.76 in
• D – 69 mm – 2.72 in
• F – 26,6 mm – 1.05 in

Frequency response
