Hertz SS 12 D2 SPL Show 12″ DVC Subwoofer
Brand: Hertz
Model Number: SS12D2
UPC: 8018823126335
Model Number: SS12D2
UPC: 8018823126335
Save $70.99
$389.00
$459.99
|
OR
|
Payments as low as
$32.42/mo
Availability: In Stock
Hertz SS 12 D2 SPL Show 12″ DVC Subwoofer
- Spl dual voice coil
- 2000 W peak power
- progressive double-layer spiders
- 2 + 2 Ohm
Related Products:
-
Hertz SP 4.900 SPL Show D-Class 4 Channel Amplifier
Save $230.00
$999.99
$1,229.99
Hertz HP 6001 SPL Show Class D 6000W Mono Amplifier with Crossover
Save $300.00
$3,199.99
$3,499.99
Hertz MP15K SPL 2 Channel Unlimited Stereo Amplifier
Save $1,710.00
$9,679.99
$11,389.99
Product Description
Features & Specifications
Documents
Warranty
Hertz SS 12 D2 SPL Show 12″ DVC Subwoofer
SS 12 D2 | 300 (12) mm (in.) | 184 (7.24) mm (in.) | Spl dual coil subwoofer | 2000 W | 2 + 2 Ohm | Dual Voice Coil
SS 12 D2 subwoofer featuring 30 cm (12 in.) cone is eager to thrill the enthusiasts with their power.
The suspension system reinforced with progressive double-layer spiders keeps the performance constant over time, especially in the heavy use typical of Bass Wars events.
Heat dissipation is essential for this type of use and has been maximized thanks to an accurate design. The use of a robust 75 mm (3 in.) dual winding (2 + 2 Ω) voice coil developed in 4-layer configuration on a support with venting holes allows the SS 12 D2 to manage the impressive 2000 W peak power! The basket has been designed for optimal thermal dissipation and high mechanical resistance.
The non-pressed paper cone with the addition of cotton fiber is the ideal compromise between stiffness and lightness, essential for a high sensitivity value. Suspension and leadwires are oversized to withstand the very high excursions generated by the massive ferrite engine.
Push connectors accept cables with cross-section up to 12 AWG, for a practical and safe connection, suitable for the high currents involved.
Features
- 175 mm (3 in.) dual voice coil (2 + 2 Ω) developed in 4-layer configuration on a support with venting holes for a peak power of 2000 W.
- Double layer spider with progressive profile for maximum consistency of performance over time.
- Multi-layer foam surround to ensure very high excursion, essential for generating high SPL during Bass Wars.
- Oversized suspension and leadwires to withstand very high excursions.
- Impressive oversized ferrite magnet assembly for maximum control.
- 12 AWG high current Nickel-plated push connectors for a practical and safe connection.
- Non-pressed paper cone with added cotton fiber for maximum sensitivity.
SS 12 D2 Physical Specifications
- A – 320 mm – 12.6 in.
- B – 283 mm – 11.14 in
- C – 184 mm – 7.24 in.
- D – 161 mm – 6.34 in.
Frequency response
Enclosures
SEALED BOX
BOX TECH DATA – SEALED BOX Vb l(cu.ft.) 35 (1.24) Fc Hz 47 Fb Hz – Qtc 0,83 W mm(in.) 500 (19.68) H mm(in.) 400 (15.75) D mm(in.) 270 (10.63) Mounting Hole – M 283 (11.14) Wood Thickness 19 (0.75) PANELS CUT LIST – SEALED BOX A mm(in.) 500 x 400 (19.68 x 15.75) Qty 2 B mm(in.) 500 x 232 (19.68 x 9.13) Qty 2 C mm(in.) 362 x 232 (14.25 x 9.13) Qty 2 REFLEX BOX
BOX TECH DATA – REFLEX BOX Vb l(cu.ft.) 55 (1.94) Fc Hz – Fb Hz 51 Qtc – W mm(in.) 550 (21.65) H mm(in.) 400 (15.75) D mm(in.) 380 (14.96) Mounting Hole – M 283 (11.14) Wood Thickness 19 (0.75) PANELS CUT LIST – REFLEX BOX A mm(in.) 550 x 400 (21.65 x 15.75) Qty 2 B mm(in.) 550 x 342 (21.65 x 13.46) Qty 2 C mm(in.) 362 x 342 (14.25 x 13.46) Qty 2 Product: Hertz SS 12 D2 SPL Show 12" DVC SubwooferTechnical Specs Size mm (in.): 300 (12)
Power Handling – Continuous W: 1000
Power Handling – Peak W: 2000
Impedance Ohm: 2 + 2
Depth mm (in.): 184 (7.24)
Voice Coil Type: dual
No Filter Component: SPL DUAL COIL SUBWOOFER
Voice Coil Ø: 75 (3)
Magnet size D x d x h mm (in.): 170 x 90 x 40 (6.69 x 3.54 x 1.57)
Weight of one component kg (lb.): 8,8 (19.4)
Magnet: Ferrite
Cone: Non pressed paper with cotton fibre
Xmech mm (in.): 10,6 (0.42)Electro-acoustic Specs D mm: 253
Xmax mm: 15,4
Re Ohm: 0,96
Fs Hz: 36
Le mH: 0,9
Vas I: 24,52
Mms g: 282,8
Cms mm/N: 0,07
BL T*m: 9,37
Qts: 0,64
Qes: 0,70
Qms: 7,0
Spl dB: 86Car Subwoofer Features Dual Voice Coil
Car Subwoofer Size 12"
RMS Power 801 to 1200 Watts
