JL Audio C2-525X Bundle #4 – 99620 | 99613 | 93265 | 98642 | 90356 | 90429
Brand: JL Audio
Model Number: 162869
UPC: BUNDLE
Model Number: 162869
UPC: BUNDLE
Save $402.85
$2,206.85
$2,609.70
|
OR
|
Payments as low as
$183.90/mo
Order Now Limited Quantities Items may ship separately Call to Inquire
JL Audio C2-525X Bundle #4
This Bundles Includes:
(1) JL Audio C2-525X 5.25″ Coaxial Speakers – Pair – #99613
(1) JL Audio C2-525 2-Way Component System – Pair – #99620
(1) JL Audio CP210-W0v3 Subwoofer with Dual 10W0v3 Subwoofer Drivers– #93265
(1) JL Audio RD900/5 5-Channel Car Amplifier – #98642
(1) JL Audio XD-PCS8-1B Premium 8 AWG 12 V Power Connection Kit – #90356
(1) JL Audio XD-CLRAIC4-18 18 Ft (5.49 m) Core Series 4 Channel Audio Interconnect Cable – #90429
Order Now – Limited Quantities – Items may ship separately – Call to Inquire
Frequently Bought Together
Related Products:
-
Alpine ILX-507 7″ Receiver | PXE-C80-88 8-Channel Sound Processor Amp...
Save $798.00
$2,999.00
$3,797.00
Alpine ILX-507 7″ Receiver | R-A90S 6-Channel Amplifier | R2-SB10V 10...
Save $447.00
$2,399.00
$2,846.00
Product Description
Features & Specifications
Documents
Warranty
JL Audio C2-525X Bundle #4
This Bundles Includes:
(1) JL Audio C2-525X 5.25″ Coaxial Speakers – Pair – #99613
(1) JL Audio C2-525 2-Way Component System – Pair – #99620
(1) JL Audio CP210-W0v3 Subwoofer with Dual 10W0v3 Subwoofer Drivers– #93265
(1) JL Audio RD900/5 5-Channel Car Amplifier – #98642
(1) JL Audio XD-PCS8-1B Premium 8 AWG 12 V Power Connection Kit – #90356
(1) JL Audio XD-CLRAIC4-18 18 Ft (5.49 m) Core Series 4 Channel Audio Interconnect Cable – #90429JL Audio C2-525x #99613 – 5.25″ Coaxial Speakers – Pair
The JL Audio C2-525x systems deliver sparkling high-frequency detail, smooth mid-range and powerful mid-bass, thanks to real silk dome tweeters and precision-engineered woofer designs.
The JL Audio C2-525x system features 5.25-inch (130 mm) woofers with mineral-filled polypropylene cones, long excursion capabilities and stamped steel frames. The woofer design benefits from JL Audio’s vast woofer design experience and advanced modeling systems.
Tweeters are coaxially mounted and built with 0.75-inch silk dome diaphragms that deliver smooth, extended response, on and off axis. The small size of the C2 tweeter minimizes tweeter protrusion, allowing C2 coaxials to fit behind most factory speaker grilles.
Speaker grilles are included, each consisting of a black grille tray with satin silver accents and a black steel mesh grille with an electroformed JL Audio logo.
Sonic character: Clean and Dynamic
Sold as a pair.
JL Audio C2-525 #99620 – 2-Way Component System – Pair
The JL Audio C2-525 systems deliver sparkling high-frequency detail, smooth mid-range and powerful mid-bass, thanks to real silk dome tweeters and long linear excursion woofer designs.
The C2-525 system features 5.25-inch (130 mm) component woofers with mineral-filled polypropylene cones, long excursion capabilities and stamped steel frames. The woofer design benefits from JL Audio’s vast woofer design experience and advanced modeling systems.
The C2 component tweeters are built with 0.75-inch silk dome diaphragms that deliver smooth, extended response, on and off axis. Flush-mounting and surface-mounting fixtures are included to fit a wide variety of installation needs.
C2 crossover networks are compact and built with premium component parts, including Mylar® capacitors and segmented air-core inductors. Three levels of tweeter attenuation are provided, as well as a tweeter protector.
Woofer grilles are included, each consisting of a black grille tray with satin silver accents and a black steel mesh grille with an electroformed JL Audio logo.
Sonic character: Clean and Dynamic
Sold as a pair.
Silk Dome Tweeter Summary: Light, fast moving silk dome material promotes high-frequency accuracy.
Detailed Information:
Silk is a natural material with inherently good characteristics as a tweeter diaphragm. In addition to being very light in weight, silk exhibits excellent damping properties, which reduces ringing and resonances in the tweeter’s passband, leading to a smooth, pleasing high-frequency character free from unnatural sibilance or exaggerated brightness. Compared to a harder material dome, a silk tweeter does not exhibit as much ultra-high frequency extension, but is preferred by many audiophiles for its overall balance.JL Audio CP210-W0v3 Subwoofer with Dual 10W0v3 Subwoofer Drivers – #93265
JL quality at a great price
JL Audio built the BassWedge CP210-W0v3 enclosure to make car-rattling bass for a reasonable price, without the need for a ton of power. The enclosure’s designed to match the two 10″ subs loaded into it, so you know you’ll get every ounce of performance out of this enclosure.
An excellent combination
The CP210-W0v3 BassWedge contains two 10″ W0v3 subwoofers that handle up to 600 watts RMS, and are loaded into a specially built slot-ported enclosure. The enclosure can be placed with the woofers firing downwards, or in typical front or rear firing applications, giving you immense bass regardless of how you place it.
Solid MDF enclosure
JL Audio uses state-of-the-art automated woodworking equipment to fabricate the high-quality MDF enclosure with rugged automotive carpeting, nickel-plated push terminals, and solid internal wiring.
Enclosed Subwoofer System with Dual 10W0v3-4 Subwoofer Drivers, Dark Gray Carpet (600 W, 2 ?) – Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofers to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
JL Audio RD900-5 – 5 Ch. Class D System Amplifier 900 W
Crafted as an all-in-one, total system solution, the JL Audio RD900-5 is engineered to power a complete audio system consisting of a subwoofer + four satellite system with 900 watts of high-performance sound. Equipped with JL Audio’s exclusive NexD switching technology, this complete power package efficiently generates a potent 70 watts of crystal-clear audio into 4 ohms, plus a robust 500 watts for a subwoofer system, all from a single compact chassis.
Each pair of main channels is also fully bridgeable, stoutly producing 200 watts of full-range audio bliss (into 4 ohms), creating an ultra-powerful 3-channel amplifier.
Conveniently located on top of the JL Audio RD900-5, you’ll find a complement of studio-grade signal processing features, all hidden beneath a removable protective cover. Each pair of main channels is equipped with a 12 dB / octave high-pass filter, with a dedicated low-pass filter for its subwoofer channel.
All three crossovers offer continuously variable frequency selection from 50-500 Hz, for precise filtering. Dual-range, differential-balanced inputs are also onboard, capable of accepting most input voltage levels, plus automatic turn-on capability (via signal sensing or DC-offset sensing) for maximum versatility.
LED clipping indicators are also standard equipment for each channel section. This all-new, innovative feature lets you easily set your amplifier’s input sensitivity settings, quickly and accurately, with no special equipment needed. The JL Audio RD900-5 features a durable, black powder-coated finish and a top-mounted, dual-color LED light strip that reports the overall status and condition. With the addition of an RBC-1 remote level control (sold separately), you can conveniently control the subwoofer’s output remotely from the driver’s seat.
JL Audio XD-PCS8-1B Premium 8 AWG 12 V Power Connection Kit, Single Amplifier #90356
Amplifier installation kits can save you time & money when installing an amplifier in your vehicle like the JL Audio XD-PCS8-1B 8 AWG Amplifer. Instead of purchasing everything you need separately like power/ground cables, remote turn-on cable, fuse blocks, fuses, and more, you can get an amp kit that already has the cables & accessories in one package. This JL Audio 8 AWG Amplifier Power Connection Kit includes all the necessary hardware and wire to power one amplifier and is designed specifically for car audio systems up to 400 watts. The included premium power/ground cable is made from 100% oxygen-free copper and is true-to-gauge for ultimate power transfer. This XD-PCS8-1B power amp kit includes 19-feet of 8 AWG frosted blue power cable, 3-feet of 8 AWG clear ground cable, 20-feet of 18 AWG blue remote turn-on wire, Maxi Fuse holder, 40 Amp fuse and more. Amplifier wiring kits come in various gauge configurations depending on the wattage of your sound system and include all the necessary components you need to successfully install an amplifier. This kit is appropriate for single amplifiers with fuse ratings from 20A to 40A.
JL Audio XD-CLRAIC4-18 #90429 18 Ft (5.49 m) Core Series 4 Channel Audio Interconnect Cable
The JL Audio XD-CLRAIC4-18 is 4-channel Twisted-Pair Audio Interconnect Cable. Twisted construction for increased quality.Pure oxygen free copper conductors with Polyethylene Dielectrics molded connector bodies for extended durability.
Product: JL Audio C2-525X Bundle #4 - 99620 | 99613 | 93265 | 98642 | 90356 | 90429JL Audio C2-525x – 2-way 5-1/4″ speakers (pair)
– injection-molded mica-filled polypropylene woofer with butyl rubber –
surround
– 3/4″ silk dome tweeter
– built-in crossover network
– 4-ohm impedance
– power range: 15-100 watts RMS (225 watts peak power)
– frequency response: 63-22,000 Hz
– sensitivity: 89 dB
– depth: 2-1/2″
– Frame Outer Diameter* 5.20 in / 132 mm
– Grille Tray Outer Diameter 6.01 in / 153 mm
– Motor Outer Diameter 2.76 in / 70 mm
– Frontal Coaxial Tweeter Protrusion 0.46 in / 12 mm
– Frontal Grille Protrusion .72 in / 18 mm
– Mounting Hole Diameter 4.56 in / 116 mm
– Mounting Depth 2.50 in / 64 mmJL Audio C2-525 – Description: Evolution® C2 5.25 in. / 130 mm 2-Way Component System:
– 5.25 in. / 130 mm Woofers;
– 0.75 in. / 19 mm Silk Dome Tweeters
– Height (A) 4.72 in. / 119.9 mm
– Width (B) 3.36 in. / 85.3 mm
– Depth (C) 1.44 in. / 36.6 mm– Grilles Included
– Woofers: Injection-molded, Mica-filled, Polypropylene Cone,
– Butyl Rubber Surround, 1 in. Voice Coil on Kapton Former, Flat,
– Symmetrical Roll Spider, Ferrite Magnet
– Tweeters: 0.75 in. (19 mm) Silk Dome, Ferrofluid Cooling /
– Damping, Neodymium Magnet
– Crossover
– Networks: 1st Order Low-Pass Filter, 2nd Order High-Pass Filter,
– 3-Position Adjustable Tweeter Level, Premium Mylar Capacitors Premium
– Air-Core Inductors
– Continuous Power Handling: 60 Watts
– Rec. Power Range (per channel): 15 – 100 Watts– System
– Efficiency: 89.0 dB @ 1W/1m
– 95.0 dB @ 1W/0.5m
– Nominal Impedance: 4 ohms
– System Frequency Response: 63 Hz – 22 KHz ± 3 dB
– Woofer Frame Outer
– Diameter* (A) 5.20 in. / 132.0 mm
– Woofer Grille Tray
– Outer Diameter** (B) 6.01 in. / 152.8 mm
– Woofer Magnet Outer
– Diameter (C) 2.76 in. / 70.0 mm w/o cover
– Frontal Coaxial
– Tweeter Protrusion*** (D) N/A
– Woofer Frontal
– Grille Protrusion**** (E) 0.72 in. / 18.2 mm
– Woofer Mounting Hole
– Diameter (F) 4.56 in. / 115.9 mm
– Woofer Mounting
– Depth (G) 2.50 in. / 63.5 mm w/o cover
– Flush Mount Fixture
– Diameter (A) 1.87 in. / 47.5 mm
– Flush Mount Trim-Ring Diameter
– (B) N/A
– Flush Mount Mounting
– Hole Diameter (C) 1.625 in. / 41.3 mm
– Flush Mount Mounting
– Depth (D) 0.76 in. / 19.3 mm
– Surface Mount
– Fixture Diameter (E) 1.69 in. / 42.9 mm
– Surface Mount
– Protrusion (F) 0.92 in. / 23.4 mmJL Audio CP210-W0v3 Woofer Size (inches) 10
Speakers Per Box 2
Woofer Material Polypropylene
Enclosure Type Ported
Color Gray
Pieces in System 1
Width (inches) 29-5/8
Height (inches) 13-7/8
Depth (inches) 17-1/2
Second Depth (inches) 14
Connector Type Spring post
Frequency Response 25-250 Hz
Power Range (Watts RMS) 600
Maximum Wattage 1200
Sensitivity 84 dB
Impedance 2 ohmsJL Audio RD900/5 Rated Continuous (RMS) Power @ 14.4 V
– Main Channels @ 4 Ω 70 W RMS x 4
– Main Channels @ 2 Ω 100 W RMS x 4
– Main Channels – Bridged @ 4Ω 200 W RMS x 2
– Subwoofer Channel @ 4 Ω 225 W RMS x 1
– Subwoofer Channel @ 3 Ω 325 W RMS x 1
– Subwoofer Channel @ 2 Ω 500 W RMS x 1
– Subwoofer Channel @ 1.5 Ω N/ARated Continuous (RMS) Power @ 12.5 V
– Main Channels @ 4 Ω 60 W RMS x 4
– Main Channels @ 2 Ω 90 W RMS x 4
– Main Channels – Bridged @ 4Ω 180 W RMS x 2
– Subwoofer Channel @ 4 Ω 200 W RMS x 1
– Subwoofer Channel @ 3 Ω 250 W RMS x 1
– Subwoofer Channel @ 2 Ω 350 W RMS x 1
– Subwoofer Channel @ 1.5 Ω N/AGeneral Specifications
– Frequency Response (Main Channels) 12 Hz – 22 kHz (+0, -1dB)
– Frequency Response (Subwoofer Channel) 10 Hz – 500 Hz (+0, -1dB)
– S/N Ratio, referred to highest rated power (Main Channels) >104 dB below rated power (A-weighted, 20 Hz – 20 kHz noise bandwidth)
– S/N Ratio, referred to 1 W >84 dB (A-weighted, 20 Hz – 20 kHz noise bandwidth)
– Damping Factor @ 4 Ω >150 / 50 Hz
– Damping Factor @ 2 Ω >75 / 50 Hz
– Input Voltage Range @ RCA Inputs Switchable from 200 mV – 2 V RMS (Low) to 800 mV – 8 V RMS (High)
– Min.Copper Power / Ground Wire Gauge 4 AWG wire
– Fuse Rating 80 A (AFS, AGU or MaxiFuse)Signal Processing
– Filter Mode(s): Channels 1 & 2 (front) High-Pass only
– Filter Slope(s): Channels 1 & 2 (front) 12 dB/octave
– Filter Frequency Range: Channels 1 & 2 (front) 50 Hz – 500 Hz
– Filter Mode(s): Channels 3 & 4 (rear) High-Pass only
– Filter Slope(s): Channels 3 & 4 (rear) 12 dB/octave
– Filter Frequency Range: Channels 3 & 4 50 Hz – 500 Hz
– Filter Mode(s): Subwoofer Channel Low-Pass only
– Filter Slope(s): Subwoofer Channel 12 dB/octave
– Filter Frequency Range: Subwoofer Channel 50 Hz – 500 Hz
– Detented, Calibrated Filter Freq. Potentiometers No
– Filter Defeat Function No
– Infrasonic Filter: Subwoofer Channel No
– Remote Level Control Optional (RBC-1)
– Remote Level Modes Sub Ch.
– Channel Input Mode Switch Yes (2/4/6 ch.)
– Pass-Through Preamp Output No
– Source Channel Selection for PreOuts N/AJL Audio XD-PCS8-1B General
– Number of Amplifiers Supported: 1
– Power/Ground Wire Size: 8 gauge
– Power Wire Length: 19 feet
– Power Wire Color: Blue
– Ground Wire Length: 3 feet
– Ground Wire Color: Clear
– Speaker Wire Included: No
– Remote Wire Length: 20 feet
– Interconnect (RCA) Signal Cables Included: No
– Fuse Holder: MAXI
– Fuse Size: 40A
– Distribution Block Included: No
– Complies to AWG Standards: Yes
– Wire Material: OFC (Oxygen-Free Copper)JL Audio XD-CLRAIC4-18 Specifications
– 18 Ft (5.49 m) Core Series 4 Channel Audio Interconnect Cable
– Twisted construction for increased quality
– Pure oxygen free copper conductors with Polyethylene Dielectrics
– Molded connector bodies for extended durability
– Length: 18 Ft (5.49 M)Estimated Shipping
