JL Audio CP108LG-W3v3 MicroSub slot-ported enclosure with one 8″ W3v3 subwoofer – #93133

$449.95

JL Audio CP108LG-W3v3 #93133 MicroSub slot-ported enclosure with one 8″ W3v3 subwoofer

  • ported enclosure with one 8″ W3v3 subwoofer
  • 5/8″ medium density fiberboard construction covered with black carpet
  • steel-mesh grille
  • 4-ohm total impedance
  • power handling: 50-250 watts RMS
  • frequency response: 28-250 Hz

In stock

Free Shipping
SKU: CP108LG-W3v3 Item #: 93133 Category:

Frequently Bought Together

JL Audio CP108LG-W3v3+JL Audio XD300/1v2+JL Audio JX250/1
Price for all three:   $1,299.85

Product Description

 JL Audio CP108LG-W3v3 #93133 MicroSub slot-ported enclosure with one 8″ W3v3 subwoofer

JL Audio CP108LG-W3v3 MicroSub enclosed subwoofer system delivers impressive bass without needing a lot of power or taking up much space. This MicroSub handles up to 250 watts RMS, housing one 8″ W3v3 subwoofer that offers impressive low end. The enclosure is designed from the ground up to get optimum performance from its driver, so you get much more than just a box with a speaker inside.

This incredible JL Audio CP108LG-W3v3 MicroSub subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its 8W3v3 subwoofer driver into an efficient slot-ported design.

Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure’s internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.

This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.

Finish: Black, high-grade automotive carpet with silver “JL AUDIO” embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.

The JL Audio CP108LG-W3v3 MicroSub is a compact bass solution for vehicles with limited space such as trucks or convertibles. This slot-ported enclosure is loaded with one 4-ohm 8W3v3-4 woofer. The W3v3 subwoofer is one of the cleanest, most efficient, and best sounding subwoofers in its class. The W3v3 features a DM Optimized Motor System that provides constant and strong linear excursion that result in reduced distortion and higher bass reproduction. These woofers also feature Elevated Frame Cooling technology that delivers cool air directly to the voice coil of the woofer. This increases power handling and sound quality. The W3v3 series subwoofers offer many more patented technologies that truly make this series stand out above the rest. If you are struggling on a decision, JL Audio will never disappoint.

The enclosure features top quality MDF (medium density fiberboard), cut using state-of-the-art CNC woodworking equipment, and covered with high-grade automotive carpeting. Extensive interior bracing permits the use of thinner MDF that maximizes the enclosure’s internal volume relative to its exterior volume. Each driver is also protected by a black steel-mesh grille. It also features a side firing slot port. The flared port opening minimizes turbulence and improves overall fidelity.

Additional Information

Weight9.0 kg
RMS Power

201 to 400 Watts

Speaker Size

8″

Specifications

Subwoofer Specifications:
– 8″ W3v3 Series Subwoofer Driver
– Power Handling:
– RMS: 250 watts
– Recommended Power Range: 75 – 250 watts
– Impedance: Single 4-Ohm
– Injection-molded, mineral-filled polypropylene cone
– Nitrile butadiene rubber surround
– Stamped steel basket
– Customization trim ring
– Floating-cone attach method
– Highly linear, DMA-Optimized motor system
– Insert molded suspension, coil and terminal sub-assembly
– Patented vented reinforcement collar (VRC)
– Elevated frame cooling design
– Nickel plated brass spring terminals
– Engineered lead-wire design and attachments
– Black Steel-Mesh Grille Insert Included
– Sensitivity: 83.24 dB
– Xmax: 10.0 mm
– Matching Amplifiers:
– JL Audio JX250/1
– JL Audio XD300/1v2
– 2 Year Manufacturer’s Warranty

Enclosure Specifications:
– Slot-Ported MicroSub Enclosure Box
– Low-profile slot-ported carpeted enclosure
– Black carpeted finish
– Steel mesh grille for protection
– Dimensions: 5-1/8″D x 18-5/8″W x 11″H
