JL Audio CP210-WOV3 Subwoofer | JD250/1 Amplifier | RBC-1 Remote Bundle – 93265 | 98360 | 98015
This Bundle Includes:
(1) JL Audio CP210-W0v3 #93265 – Subwoofer with Dual 10W0v3 Subwoofer Drivers
(1) JL Audio JD250/1 Monoblock Class D Car Audio Subwoofer Amplifier- 98360
(1) JL Audio RBC-1 Car Audio Bass Remote Control 98015
JL Audio CP210-W0v3 Subwoofer with Dual 10W0v3 Subwoofer drivers
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofers to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with “JL AUDIO” embroidery on the top edge and “Slot-Ported BassWedge™” embroidered on the port mouth.
Recommended amplifier power: 150 – 600W
Nominal Impedance: 2 ?
JL Audio JD250/1 Monoblock Class D Subwoofer Amplifier – #98360
Monoblock Class D Subwoofer Amplifier, 250 W x 1 @ 2 ? / 150 W x 1 @ 4 ? – 14.4V
Designed to produce a healthy 250 watts into 2 ohms (14.4V, 1% THD), the JD250/1 amplifier is a great solution for powering subwoofers in a cost-conscious system. Our proprietary NexD™ switching technology delivers large amounts of real-world power output with excellent efficiency and ultra-low distortion.
The JD250/1’s controls are located on the input panel. while the power and speaker connections can be found along the opposite end of its extruded aluminum chassis. Signal processing features include a 12 dB / octave low-pass filter, with continuously variable frequency selection from 50-500 Hz, and a variable bass boost EQ. Dual-range, differential-balanced inputs are also on-hand, capable of accepting line-level and speaker-level signals. Automatic turn-on capability (via signal sensing or DC-offset sensing) is standard, along with a set of preamp outputs so you can easily pass signals to another amplifier.
The JD250/1 is also equipped with an onboard LED-clipping indicator ring, surrounding the input sensitivity control. This useful feature lets you easily set your amplifier’s input sensitivity, quickly and accurately, without special equipment. With the addition of an RBC-1 remote level control (sold separately), you can control the subwoofer level from the driver’s seat.
JL Audio RBC-1 Car Audio Bass Remote Control #98015
The JL Audio RBC-1, is a “Bass Boost” switch that activates a +6dB boost centered at 48 Hz.
JL Audio amplifiers feature bass-boost circuitry to help you adjust low-frequency impact in your vehicle. The RBC-1 wired remote bass control works with all of JL Audio’s A-Series, G-Series, RD Series, mono JX-Series, and most Slash v2 amps. You can mount the RBC-1 controller in the front of your vehicle and dial in the amount of bass you want from the driver’s seat — mounting instructions, hardware, and a 18″ cable are included.
Connect the JL Audio RBC-1 to your amp, and it converts the amp’s selectable bass boost (0 or 6 dB) to a variable boost (0 to 12 dB). With the Slash v2 amps, the RBC-1 takes the place of the amp’s boost knob, allowing you to adjust your bass boost from 0 to 15 dB. With RD Series and JX-Series mono amps, the RBC-1 controls the amp’s subwoofer level, from full mute to full volume.
