JL Audio CP212-WOV3 Subwoofer | JD500/1 Amplifier | RBC-1 Remote Bundle – 93283 | 98362 | 98015

This Bundle Includes:

(1) JL Audio CP212-W0v3 #93283 – Subwoofer with Dual 12W0v3 BassWedge, Ported
(1) JL Audio JD500/1 1 Ch. 500 Watt 2 Ohm Subwoofer Amplifier – #98362
(1) JL Audio RBC-1 Car Audio Bass Remote Control – #98015

This JL Audio CP212-W0v3 slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.

The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofers to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.

The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.

This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.

Finish: Dark gray, high-grade automotive carpet with “JL AUDIO” embroidery on the top edge and “Slot-Ported BassWedge™” embroidered on the port mouth.

Construction: MDF

Recommended amplifier power: 150 – 600W
Nominal Impedance: 2 ?

JL Audio CP212-W0v3 Loaded Sub Enclosure

JL Audio’s dual 12″ slot-ported loaded BassWedge subwoofer enclosure has a peak power rating of 1200 watts and an RMS rating of 600 watts. The enclosure is loaded and wired with two JL Audio 12W0v3 single 4-ohm subwoofers. The W0v3 offers superb excursion capability, linearity and an overall performance output that puts it right at the top of its price class. The driver features a very beefy 2.0-inch diameter voice coil, a DMA-optimized motor system and JL Audio’s patented Elevated Frame Cooling design – all purpose-engineered for enhanced power handling and reliability. What this also means, is your system will be immediately injected with the increase in output and better sound fidelity that one expects from a JL Audio product. In addition, excellent excursion capability and linearity allow it to reproduce sub-bass with striking extension and quality. When matched up with the proper power source, signal and setup the W0v3 is capable of a well rounded sound that is unparalleled by any other driver in its price range.

Flexible JL Audio Power

The CP212-W0v3 Enclosure can be driven with as little as 150 Watts. However, for best audio performance it is recommended to run an amplifier capable of between 400 – 600 Watts of continuous power per driver, like the JL Audio XD600/1v2 or JL Audio JX500/1D. In addition, The ultra-versatile BassWedge shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.

Striking Linearity and Control

DMA is JL Audio’s proprietary Dynamic Motor Analysis system and is aimed at delivering superior dynamic stability and low distortion. As a result of DMA optimization, W0v3 motors remain linear in motor force over an extreme range of excursion and also maintain a highly stable fixed magnetic field in the gap over a wide power range. This leads to tight, clean, articulate bass that also allows for extreme linear excursion, phenomenal power handling and control, control, control.

JL quality at a great price

JL Audio built the BassWedge CP212-W0v3 enclosure to make car-rattling bass for a reasonable price, without the need for a ton of power. The enclosure’s designed to match the two 12″ subs loaded into it, so you know you’ll get every ounce of performance out of this enclosure.

An excellent combination

The CP212-W0v3 BassWedge contains two 12″ W0v3 subwoofers that handle up to 600 watts RMS, and are loaded into a specially built slot-ported enclosure. The enclosure can be placed with the woofers firing downwards, or in typical front or rear firing applications, giving you immense bass regardless of how you place it.

Solid MDF enclosure

JL Audio uses state-of-the-art automated woodworking equipment to fabricate the high-quality MDF enclosure with rugged automotive carpeting, nickel-plated push terminals, and solid internal wiring.

JL Audio JD500/1 Monoblock Class D Subwoofer Amplifier – #98362

Monoblock Class D Subwoofer Amplifier, 500 W x 1 @ 2 ? / 250 W x 1 @ 4 ? – 14.4V

Designed to produce a whopping 500 watts into 2 ohms (14.4V, 1% THD), the JD500/1 amplifier is a great solution for powering subwoofers in a cost-conscious system. Our proprietary NexD™ switching technology delivers large amounts of real-world power output with excellent efficiency and ultra-low distortion.

The JD500/1’s controls are located on the input panel. while the power and speaker connections can be found along the opposite end of its extruded aluminum chassis. Signal processing features include a 12 dB / octave low-pass filter, with continuously variable frequency selection from 50-500 Hz, and a variable bass boost EQ. Dual-range, differential-balanced inputs are also on-hand, capable of accepting line-level and speaker-level signals. Automatic turn-on capability (via signal sensing or DC-offset sensing) is standard, along with a set of preamp outputs so you can easily pass signals to another amplifier.

The JD500/1 is also equipped with an onboard LED-clipping indicator ring, surrounding the input sensitivity control. This useful feature lets you set your amplifier’s input sensitivity, quickly and accurately, without special equipment. With the addition of an RBC-1 remote level control (sold separately), you can control the subwoofer level from the driver’s seat.

JL Audio RBC-1 Car Audio Bass Remote Control 98015

The JL Audio RBC-1, is a “Bass Boost” switch that activates a +6dB boost centered at 48 Hz.

JL Audio amplifiers feature bass-boost circuitry to help you adjust low-frequency impact in your vehicle. The RBC-1 wired remote bass control works with all of JL Audio’s A-Series, G-Series, RD Series, mono JX-Series, and most Slash v2 amps. You can mount the RBC-1 controller in the front of your vehicle and dial in the amount of bass you want from the driver’s seat — mounting instructions, hardware, and a 18″ cable are included.

Connect the JL Audio RBC-1 to your amp, and it converts the amp’s selectable bass boost (0 or 6 dB) to a variable boost (0 to 12 dB). With the Slash v2 amps, the RBC-1 takes the place of the amp’s boost knob, allowing you to adjust your bass boost from 0 to 15 dB. With RD Series and JX-Series mono amps, the RBC-1 controls the amp’s subwoofer level, from full mute to full volume.
