JL Audio RBC-1 Car Audio Bass Remote Control 98015
The JL Audio RBC-1, is a “Bass Boost” switch that activates a +6dB boost centered at 48 Hz.
JL Audio amplifiers feature bass-boost circuitry to help you adjust low-frequency impact in your vehicle. The RBC-1 wired remote bass control works with all of JL Audio’s A-Series, G-Series, RD Series, mono JX-Series, and most Slash v2 amps. You can mount the RBC-1 controller in the front of your vehicle and dial in the amount of bass you want from the driver’s seat — mounting instructions, hardware, and a 18′ cable are included.
Connect the JL Audio RBC-1 to your amp, and it converts the amp’s selectable bass boost (0 or 6 dB) to a variable boost (0 to 12 dB). With the Slash v2 amps, the RBC-1 takes the place of the amp’s boost knob, allowing you to adjust your bass boost from 0 to 15 dB. With RD Series and JX-Series mono amps, the RBC-1 controls the amp’s subwoofer level, from full mute to full volume.
The RBC-1 remotely controls the Bass Level of the following JL Audio amplifiers
When the JL Audio RBC-1 is connected to the above amplifiers, the on-board “Boost” control of the amplifier is defeated and the RBC-1 becomes the active controller.
The RBC-1 kit includes the rotary control with a black ABS knob, mounting hardware and one 18 ft. (5.5 m) cable.
What’s in the Box:
- Owners Manual
- Bass Controller with attached knob and 9″ cord terminated by a female RJ-11 port
- 18′ control cable with a male RJ-11 connector on each end
- 2 Nuts
- 2 Washers
- Installation Instructions
