JL Audio XD400/4v2 4 Ch. 400 Watt Amplifier – #98602

Brand: JL Audio
Model Number: XD400/4V2
UPC: 699440986021
Model Number: XD400/4V2
UPC: 699440986021
Free Shipping

$849.95

|

OR

|

Payments as low as

$70.83/mo

Affirm
Last Chance - Only 2 Left

Availability: In Stock

JL Audio XD400/4v2 4-Channel Car Amplifier 75w RMS x 4 – #98602

  • 4-channel car amplifier
  • 75 watts RMS x 4 at 4 ohms (100 watts RMS x 4 at 2 ohms)
  • 200 watts RMS x 2 bridged at 4 ohms (4-ohm stable bridged)
  • Variable low- and high-pass filters (50-500 Hz, 12 dB/octave)
  • Optional wired remote controls sub or system level
  • Class D amplifier design with NextD™ switching amp technology
  • Differential-balanced inputs eliminate noise coming from your vehicle’s electrical system
  • Advanced Rollback Protection System prevents thermal shut-down
Last Chance - Only 2 Left

Product Description

Features & Specifications

Documents

Warranty

JL Audio XD400/4v2 4-Channel Car Amplifier 75w RMS x 4 – #98602

If you’re a true audiophile, you know that the quality of your car audio system can make or break your driving experience. To take your car audio to the next level, you need a powerhouse like the JL Audio XD400/4v2 4-Channel Car Amplifier. This amplifier is not just about turning up the volume; it’s about delivering a stunning full-range audio experience that will leave you in awe.

Powerhouse Performance

The XD400/4v2 is not your average car amplifier. It packs a serious punch, delivering a whopping 100 watts to each of its four channels into 2 ohms (14.4V, 1% THD). What sets it apart is the groundbreaking NexD™ ultra-high-speed switching design. This technology allows for full bandwidth Class D operation with incredibly low distortion and exceptional efficiency. In simpler terms, it means your music will sound crystal clear, powerful, and distortion-free.

Endless Possibilities

One of the most remarkable features of the XD400/4v2 is its versatility. You can use it in combination with the XD600/1 monoblock to create a 1000W amplification system that can power four satellites and a subwoofer, all while fitting neatly under your seat. Alternatively, you can use the XD400/4v2 on its own to power two satellites and a subwoofer. With the XD series, the possibilities are virtually limitless.

Fine-Tuned Sound

Achieving the perfect sound is all about precision, and the XD400/4v2 understands that. It comes equipped with a 12 dB/octave filter for each channel bank, giving you the flexibility to configure it as a low-pass or high-pass filter. Plus, it offers continuously variable cutoff frequency selection ranging from 50-500 Hz. This level of control allows you to fine-tune your audio to match your exact preferences.

Seamless Integration

The XD400/4v2 boasts the v2 Spec feature set, which includes automatic turn-on capability via signal sensing or DC-offset sensing. This means that your amplifier will seamlessly integrate with your car’s audio system, turning on and off when needed. Additionally, it features a dual-range differential-balanced input section capable of handling a wide range of input voltage levels.

Convenience at Your Fingertips

Imagine having control over your audio system right from the driver’s seat. With the addition of an HD-RLC remote level control (sold separately), you can do just that. Adjust the amplifier’s level with ease, whether you want to tweak the volume of the entire system or focus on the rear channels. It’s all about convenience and customization.

Built to Last

JL Audio knows that your car audio system needs to withstand the rigors of the road. That’s why the XD400/4v2 features a robust black powder-coat finish and a gasketed, brushed aluminum cover for the controls. It’s not just about great sound; it’s about durability too.

Unleash the Power of Sound

The JL Audio XD400/4v2 4-Channel Car Amplifier is a game-changer for anyone who values premium sound quality on the go. With its exceptional power, versatility, fine-tuned controls, and seamless integration, it takes your car audio experience to new heights. Whether you’re a music enthusiast, a road warrior, or simply someone who enjoys the finer things in life, this amplifier is your ticket to an audio adventure like no other.


FAQs (Frequently Asked Questions)

Q1: What sets the JL Audio XD400/4v2 apart from other car amplifiers? The XD400/4v2 stands out due to its NexD™ ultra-high-speed switching design, which allows for full bandwidth Class D operation with minimal distortion and outstanding efficiency. This results in exceptional audio quality.

Q2: Can I use the XD400/4v2 with other amplifiers in my car audio system? Absolutely! You can use it in combination with the XD600/1 monoblock to create a powerful 1000W amplification system. This flexibility ensures that your system can be tailored to your specific needs.

Q3: How does the XD400/4v2 allow for fine-tuned sound adjustments? The amplifier features a 12 dB/octave filter for each channel bank, enabling you to configure it as a low-pass or high-pass filter. It also offers continuously variable cutoff frequency selection from 50-500 Hz, allowing precise sound shaping.

Q4: What is the benefit of the HD-RLC remote level control? The HD-RLC remote level control, available separately, provides the convenience of adjusting the amplifier’s level from the driver’s seat. You can fine-tune the volume of the entire system or focus on specific channels.

Q5: Is the XD400/4v2 built to withstand the demands of a car audio system? Yes, JL Audio has designed the XD400/4v2 with durability in mind. It features a robust black powder-coat finish and a gasketed, brushed aluminum cover for the controls, ensuring it can handle the challenges of the road while delivering top-notch audio quality.


XD400/4v2 Physical Dimensions:

Lineart Top-View and Side-View of XD400/4v2 Amplifier with Height (H), Width (W) and Depth (D) dimension labels
  • Height (H): 2.05 in / 52 mm
  • Width (W): 8.52 in / 216 mm
  • Depth (D): 7.09 in / 180 mm
  • Net Weight: 6.3 lb / 2.86 kg
Model XD400/4V2
Product: JL Audio XD400/4v2 4 Ch. 400 Watt Amplifier – #98602
Weight 2.15 kg
Specifications

Performance
RMS Power Output (Watts x Channels): 75 x 4
Power at 2 Ohms (Watts x Channels): 100 x 4
Bridged Power (Watts x Channels): 200 x 2
Minimum Impedance Bridged: 4
Minimum Impedance Unbridged: 2
Minimum Impedance: 2
Best Frequency Response: 12-22000 Hz
THD at Rated RMS Power: 1%
Signal to Noise Ratio: 84 dB
Input Voltage: 14.4v

Features
Amplifier Class: D
Low-Pass Crossover Frequency: 50-500 Hz
Low-Pass Slope (dB/octave): 12 dB/octave
High-Pass Crossover Frequency: 50-500 Hz
High-Pass Slope (dB/octave): 12 dB/octave
Bass Boost: No
Fan Cooled: No
Fuse Rating: 40
Speaker Level Inputs: Yes
Preamp Outputs: 2
Width (inches): 8-9/16
Height (inches): 2-1/16
Depth (inches): 7-1/8

What's in the box

JL Audio XD400/4v2 owner's manual
Four-channel amplifier
2.5mm Allen wrench
Self-adhesive JL Audio badge
Owner's manual

Mobile Amplifier Channels

4 Channel

Mobile Amplifier Class

Class D

Mobile Amplifier Features

High-Pass Filter, Low-Pass Filter, Pre Amp Outputs, Speaker Level Inputs

Mobile Amplifier Fuse Rating

40

Mobile Amplifier RMS

351 to 750 watts

Mobile Min Impedance

2
