JVC DLA-NP5B 4K 120p Home Theatre D-ILA Projector | Grandview LF-PH-120 120” Curve Fixed Frame Screen

Brand: Grandview, JVC
Model Number: 315179
UPC: BUNLDE
Model Number: 315179
UPC: BUNLDE
Free Shipping

Save $2,271.00

$7,997.99

$10,268.99

|

OR

|

Payments as low as

$666.50/mo

Affirm

Availability: In Stock

JVC DLA-NP5B D-ILA Projector | Grandview LF-PH-120 120” Curved Screen

This Bundle Includes:
(1) JVC DLA-NP5B 4K 120p Home Theatre D-ILA Projector – Black
(1) Grandview LF-PH-120 Prestige Series 120” Permanent Curve Fixed Frame Screen

Product Description

Features & Specifications

Documents

Warranty

JVC DLA-NP5B 4K 120p Home Theatre D-ILA Projector | Grandview LF-PH-120 120” Curve Fixed Frame Screen

This Bundle Includes:
(1) JVC DLA-NP5B 4K 120p Home Theatre D-ILA Projector – Black
(1) Grandview LF-PH-120 Prestige Series 120” Permanent Curve Fixed Frame Screen


JVC DLA-NP5B 4K 120p D-ILA Projector

JVC DLA-NP5 D-ILA projector is wrapped in a whole new design, which is packed with the latest projection features. For instance with the new 0.69-inch native 4K D-ILA device, the projector can produce high-definition native 4K resolution (4096 x 2160) images from its all-glass 65 mm diameter lens system. HDR10 content can be projected at optimum quality with Auto Tone Mapping function, which automatically adjusts settings based on the mastering information. Combining brightness of 1,800 lm with dynamic contrast ratio of 400,000:1, the projector reproduces life like images for latest contents like HDR10 and Hybrid Log Gamma. Original motion control technology Clear Motion Drive is renewed, and together with Motion Enhance which optimizes the driving of D-ILA device according to the motion of the image, motion blur is reduced significantly compared to conventional projectors.

4K Native Resolution

Equipped with refined 0.69″ native 4K D-ILA device and newly developed digital driver LSI for native 4K resolution.

DLA-NP5 D-ILA projectors continue to evolve for the better. The latest three models feature an original native 0.69″ 4K D-ILA devices, which were first adopted on model DLA-Z1; this device has been improved with process refinements on planarization and reflection efficiency to achieve higher contrast and brightness. Additionally, a dedicated driver LSI was also enhanced to simultaneously drive each of the three (R/G/B) native 4K D-ILA devices at high-speed 120fps. As a result, precise and smooth image projection unique to 4K native can be achieved with the combination of a new device and new driver LSI.

HDR10+ Support allows a choice for two dynamic
tone mappings

When it comes to reproducing the rich video information of HDR content including the extended brightness range, BT.2020 wide colour gamut and 10-bit gradation, rely on one of the new DLA-NP5 D-ILA projectors. New models support all HDR formats including HDR10 for Blu-ray and streaming, HLG for broadcasting, and the latest HDR10+ signal format with dynamic metadata compatibility.

JVC projectors are compatible with the two dynamic tone mappings of HDR10+ and Frame Adapt HDR. HDR10+ contains the metadata of the producer’s intentions for each scene, Frame Adapt HDR instantly analyses the peak brightness in HDR10 content using an original algorithm. Ensuring you can watch any HDR content in optimal picture quality.

DLA-NP5 Frame Adapt HDR function

The Frame Adapt HDR function* enables reproduction of any HDR10 content dynamically and in high-resolution!

The colour grading of HDR content varies, some HDR content are adjusted to bright side and others to the dark side. Using JVC’s original algorithm, Frame Adapt HDR instantly analyses the peak brightness in HDR10 content frame-by-frame and in real time adjusts the projector to the optimum dynamic range. What’s more, the gamma processing accuracy of gradation performance has been improved dramatically from, 12-bit to 18-bit.

All these advancements help to bring out deeper blacks in darker scenes, and higher peaks in brighter scenes without losing colours. Reproducing images with smooth gradations, that are closer to reality as seen by the human eye. (*from firmware version 3.10 and higher)

In the picture, scene 1 represents a dark scene, scene 2 a bright scene and scene 3 a combination of bright and dark.

4K120p input ideal for Low Latency Mode

Because these projectors are equipped with 4K120p input, signal latency is infinitesimal, making it effective when displaying high frame-rate gaming content on large screens. What’s more, Low Latency Mode reduces delay in displaying PC signals and games, and improves response to the users’ rapid operations.

High quality, all glass lens

DLA-NP5

All glass, high-resolution lens with full aluminum lens barrel

The DLA-NP5 is equipped with an 18-element, 16-group all-glass lens featuring a full aluminum lens barrel. In order to project high-resolution images to every corner of the screen with the 100 mm diameter lens offering wide lens shift of ±100% vertically and ±43% horizontally, the projector adopts five ED lenses that take into account differences in the R/G/B refractive index to reduce chromatic aberration and colour fringing when lens shift kicks in to deliver precise reproduction of 8K-resolution projection. The DLA-N7 and DLA-N5 models feature a 17-element, 15-group all glass lens with 65 mm diameter to project fully focused 4K native resolution to all corners of the screen.

DLA-NP5 Features

    • New 0.69 inch 4K D-ILA (4096 x 2160) device x 3
    • Exceptionally bright 1,900 lm means bright, high-resolution images
    • Deep Blacks are realized by a High Native Contrast Ratio of 40,000:1 (Dynamic Contrast Ratio 400,000:1)
    • 17-element, 15-group all-glass 65mm diameter high-quality lens
    • Compatible with the two dynamic tone mappings of HDR10+ content and Frame Adapt HDR with Theatre Optimizer
    • As a part the Frame Adapt HDR, the projector offers improved gamma processing accuracy from 12- to 18-bit equivalent to reproduce smoother and finer gradation
    • Theater Optimizer** function, which works in Frame Adapt HDR mode, offers optimum HDR images by analyzing usage environments using the screen size and gain information and intelligently adjusts tone mapping.
    • The projector automatically reproduces HDR10+ content based on the metadata of the producers intentions for each scene.
    • For easy reproduction, the projector switches automatically to HDR picture mode when HDR10 signals are received
    • Display the MaxCLL and MaxFALL mastering data available for HDR content on some UHD Blu-ray discs
    • DLA-NP5 High-definition display at 4K resolution (4096 x 2160)
    • 2x HDMI (48 Gbps, HDCP 2.3) inputs, supporting 4K120P input signals
    • Compatible with Hybrid Log-Gamma that is expected to be used widely in future broadcasting
    • 10 Installation Modes centrally manages various settings related to installation to enjoy video best suited for each environment
    • Settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, Pincushion, and Aspect; stored installation modes for various environments can be called up.
    • Renewed Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever
    • Motion Enhance technology reduces residual images and blurring that are often found in fast-moving images by optimally controlling the drive of D-ILA devices
    • Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles
    • Colour Management System with 6-axis Matrix
    • Auto-Calibration Function using an optical sensor*** is capable of optimizing essential elements in the image, including colour balance, gamma characteristics, colour space and colour tracking
    • ISF C3 (Certified Calibration Controls) mode**** to reproduce excellent picture quality optimized for specific environments.
    • Wireless transmission options for 3D viewing: RF (radio frequency) system transmission with PK-AG3 3D Glasses for 100H continuous operation and PK-EM2 3D Synchro Emitter

Grandview LF-PH-120 Prestige Series 120” Permanent Curve Fixed Frame Screen

Grandview LF-PH-120 Prestige Series 120” Permanent Curve Fixed Frame Screen is designed for the most precision and enthusiast oriented applications. It features an advanced aluminum structure with the goal of creating an image made to fit the natural curve of the human eye. The design is created to eliminate problems caused by different distances between the projector and the screen.

Normal projection screens operate on a flat surface although the human eye bears an oval shape as well as differences in focal length. The Grandview LF-PH-120 is a light and images reflected by different areas of the screen arrive at our eyes unevenly and thus an final image that sometimes is not a perfect match. With the Curved screen, the bend conforms more accurately to our natural viewing focal length and thus creates an image for the viewer that is a near accurate match to the image.

The lens of a projector is designed to be spherical in shape. The larger the projector screen, the larger the spherical distortion will be. By changing the screen’s horizontal arc, the distance between each point on the Curved screen in relation to the projector is near equivalent. The blurred distortion that sometimes occurs at the wider edges of the image can be eliminated, making the large image uniform and perfectly focused.
Grandview-LF-PH-Acclaim-action-03
Grandview’s Prestige Series Permanent Curve Fixed screen is a solution for the size limitation problem that comes with traditional television. The permanent fixed frame brings home the big screen theatre experience. Setting itself apart from other screens, Grandview LF-PH-120 Permanent Curve Fixed Frame screen features a plane positioning design that ensures equal tension from every side which makes the projection surface as flat as possible.

Product Features:

  • Grandview’s Permanent Curve Fixed Frame series features a 3.2 inch beveled high quality aluminum alloy frame wrapped in designer velvet.
  • An adjustable tension system ensures that the screen display surface is completely flat at all times. The flexible material of the screen maintains surface integrity and helps prevent any waves or wrinkles.
  • The PS HDTV high contrast cinema fabric has a 1.0 gain with a 160 degree viewing angle. The projection surface’s backside is reinforced with a special PVC composite material.
  • The PS HDTV high contrast cinema fabric utilizes mini diamond veins that enhance contrast and image details while reducing glare. It provides a clear picture at any angle and is superior to traditional matte white fabric in every way.

Grandview LF-PH-120 Permanent Curve Fixed-Frame screens feature a new innovative easy rail installation system. All Permanent Curve Fixed-Frame screens come with an easy installation kit using innovative rail mounting brackets for various locations including wood and concrete walls. Designed for easy alignment, different screw sizes can be used with the closely positioned screw holes. With the rail mounting brackets, the installation is secure yet flexible, allowing the screen to adjust horizontally. The position connection bar on the frame allows it to be simply inserted into the brackets.
Grandview LF-PH-120 Prestige Series Permanent Curve Fixed screen brings high definition viewing to a high level.

Grandview’s Large-Flat Permanent Fixed-Frame is designed for the most precision and enthusiast oriented applications. It features an advanced aluminum structure with the goal of creating an image made to fit the natural curve of the human eye. The Design is created to eliminate problems caused by different distances between the projector and the screen. This screen brings high definition viewing to a high level.

Brand JVC   Model JVC 315179
Product: JVC DLA-NP5B 4K 120p Home Theatre D-ILA Projector | Grandview LF-PH-120 120” Curve Fixed Frame Screen
DLA-NP5B Specifications

Noise level: 24dB (in Low Mode)
Power requirement: AC100V-240V, 50/60Hz

Power consumption
Projector in use: 420 W
Standby: Normal: 1.5W, Eco-mode: 0.3W
Networked standby: 1.3 W (LAN), 1.0 W (RS-232C), 1.3 W (LAN and RS-232C)
Switchover time: 20 min. (To standby or networked standby; default)
Dimensions: W x H x D, mm: 500 x 234 x 495
Weight, kg: 19.2

Specifications
Lens: All-glass lens with 65 mm diameter
Zoom: 2X zoom & focus, motorized
Lamp life: Approx. 4500 hours in Low mode
Brightness: 1,900 lm
Contrast Ratio: Native: 40,000:1,, Dynamic: 400,000:1
Video format: Digital: 480p, 576p, 720p 60/50, 1080i 60/50, 1080p 120/100/60/50/30/25/24, 2048×1080 120/100/60/50/30/25/24, 3840 x 2160p 120/100/60/50/30/25/24, 4096 x 2160p 120/100/60/50/30/25/24

PC input signal
HDMI: VGA/ SVGA/ XGA/ WXGA/ WXGA+/ SXGA/ WSXGA+/ UXGA/ WUXGA/ WQHD (60)/ WQHD (120)

Video input terminals (back panel)
HDMI: 2 (48Gbps, HDCP2.3, no support for CEC)

3D format
Frame packing: 720p 60/50, 1080p 24
Side-by-side: 720p 60/50, 1080p 60/50/24, 1080i 60/50
Top & bottom: 720p 60/50, 1080p/24

Terminals
Output terminals (back panel)
3D sync: 1 (Mini DIN 3-pin)
Trigger: 1 (mini jack, DC12V/100mA)

Control terminals
RS232C: 1 (D-sub 9-pin)
LAN: 1 (RJ-45)
Device: 0.69-inch Native 4K DILA Device (4096×2160) x3
Resolution: 4096 x 2160
Lens shift function: +/-80% vertical & +/-34% horizontal, motorized in 16:9 aspect mode
Light source lamp: NSH 265 W

Service terminal
Service: 1 (USB Type A) (for firmware update)

Projector - Features

4K, HDR, Lens Shift

Color

Black

Brightness (Lumens)

1900

Projector - Size

120" or less

Estimated Shipping

When you add an item to your cart the Estimated Shipping* cost will be shown.  This estimated shipping* cost is accurate to most major city locations across Canada.  If the shipping cost is higher than the estimated shipping* then GibbysESM will contact you for approval before we process your order.

To learn more click Shipping Terms & Conditions

  • JVC Canada 2 Year Limited Warranty
  • Grandview Canada 1 Year Limited Warranty.
