All glass, high-resolution lens with full aluminum lens barrel

The DLA-NP5 is equipped with an 18-element, 16-group all-glass lens featuring a full aluminum lens barrel. In order to project high-resolution images to every corner of the screen with the 100 mm diameter lens offering wide lens shift of ±100% vertically and ±43% horizontally, the projector adopts five ED lenses that take into account differences in the R/G/B refractive index to reduce chromatic aberration and colour fringing when lens shift kicks in to deliver precise reproduction of 8K-resolution projection. The DLA-N7 and DLA-N5 models feature a 17-element, 15-group all glass lens with 65 mm diameter to project fully focused 4K native resolution to all corners of the screen.

DLA-NP5 Features

• • New 0.69 inch 4K D-ILA (4096 x 2160) device x 3
  • Exceptionally bright 1,900 lm means bright, high-resolution images
  • Deep Blacks are realized by a High Native Contrast Ratio of 40,000:1 (Dynamic Contrast Ratio 400,000:1)
  • 17-element, 15-group all-glass 65mm diameter high-quality lens
  • Compatible with the two dynamic tone mappings of HDR10+ content and Frame Adapt HDR with Theatre Optimizer
  • As a part the Frame Adapt HDR, the projector offers improved gamma processing accuracy from 12- to 18-bit equivalent to reproduce smoother and finer gradation
  • Theater Optimizer** function, which works in Frame Adapt HDR mode, offers optimum HDR images by analyzing usage environments using the screen size and gain information and intelligently adjusts tone mapping.
  • The projector automatically reproduces HDR10+ content based on the metadata of the producers intentions for each scene.
  • For easy reproduction, the projector switches automatically to HDR picture mode when HDR10 signals are received
  • Display the MaxCLL and MaxFALL mastering data available for HDR content on some UHD Blu-ray discs
  • DLA-NP5 High-definition display at 4K resolution (4096 x 2160)
  • 2x HDMI (48 Gbps, HDCP 2.3) inputs, supporting 4K120P input signals
  • Compatible with Hybrid Log-Gamma that is expected to be used widely in future broadcasting
  • 10 Installation Modes centrally manages various settings related to installation to enjoy video best suited for each environment
  • Settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, Pincushion, and Aspect; stored installation modes for various environments can be called up.
  • Renewed Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever
  • Motion Enhance technology reduces residual images and blurring that are often found in fast-moving images by optimally controlling the drive of D-ILA devices
  • Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles
  • Colour Management System with 6-axis Matrix
  • Auto-Calibration Function using an optical sensor*** is capable of optimizing essential elements in the image, including colour balance, gamma characteristics, colour space and colour tracking
  • ISF C3 (Certified Calibration Controls) mode**** to reproduce excellent picture quality optimized for specific environments.
  • Wireless transmission options for 3D viewing: RF (radio frequency) system transmission with PK-AG3 3D Glasses for 100H continuous operation and PK-EM2 3D Synchro Emitter
  • **Theater Optimizer can be activated only when the projectors picture mode is set to Frame Adapt HDR.
  • ***Exclusive JVC software installed in PC and optical sensor are required. Please visit the JVC website for details.
