JVC KW-M150BT 2-DIN AV Digital Media Featuring Receiver

Brand: JVC
Model Number: KW-M150BT
UPC: 046838080197
Model Number: KW-M150BT
UPC: 046838080197
Free Shipping

Save $39.01






Payments as low as


Order Now - In Stock Today!

Availability: In Stock

JVC KW-M150BT 2-DIN AV Digital Media featuring Receiver

  • Bluetooth Voice Recognition
  • USB Mirroring for Android Phones
  • 13-Band EQ
  • USB Mirroring for Android
Order Now - In Stock Today!

Frequently Bought Together

JVC_KW-M150BT_1+Stinger SK6641C Front+Stinger SI4617 Front+iBeam TE-RRSC
Price for all:   $687.96

Product Description

Features & Specifications



JVC KW-M150BT 2-DIN AV Digital Media featuring Receiver

The JVC KW-M150BT is a digital multimedia receiver designed for music enthusiasts who want to enjoy their favorite songs on the go. It features an AM/FM tuner that allows you to listen to your favorite radio stations. It does not play CDs, but it can play media loaded with MP3, WMA, FLAC, and AAC music files. The receiver also comes with a 6.75″ capacitive touchscreen display that provides an intuitive interface for easy navigation and control of your music. This receiver is designed to fit double-DIN (4″ tall) dash openings, making it an ideal choice for most car models. With its impressive features and high-quality sound output, the JVC KW-M150BT is a must-have for any music lover on the move.

The KW-M150BT receiver offers a browsing function that makes it easy to search for songs and select them for playback. You can use this feature to browse folder and song name listings and choose the specific music you want to listen to. Additionally, the device also supports repeat and random playback of audio files.

Android USB Mirroring

With the JVC screen’s real-time display feature via USB, you can view your Android phone’s screen directly on the JVC device. What’s more, both the JVC screen and your smartphone allow touch control, giving you an interactive experience.

Alignment of Time

Once you’ve selected the speaker type and specified the distance to the center of the listening position, the receiver will automatically synchronize the sound output from each speaker. This ensures that the sound from all speakers reaches the listening location at the same time, providing an optimal audio experience.

Touchscreen Capacitive Display

The capacitive touch screen on the KW-M150BT is extremely clear and enables for better operation with lighter contact and improved precision.

Ready for a Back View Camera

You may attach an optional rear view camera to the Rear View Camera input (sold separately).
Back view cameras enable you to securely back up your car, monitor towing, and perform other tasks.

Ready for Steering Wheel Remote Control

Using a third-party adaptor, factory steering wheel control capabilities can be kept (sold separately).

How to USE KW-M150BT Mirroring Feature

  • Step-1 : Simply download the free Mirroring for JVC app.
  • Step-2 : Connect your smartphone via Bluetooth and USB.
  • Mirroring OB for JVC App

You can enjoy apps like these and more on the KW-M150BT!

  1. Navigation App
  2. Video App
  3. SNS App



Brand JVC   Model JVC KW-M150BT
Product: JVC KW-M150BT 2-DIN AV Digital Media Featuring Receiver

Screen Size 6.8" Wide VGA
Touch Panel Capacitive with Printing
Key Illumination Color Blue
Multilingual Display Yes[2]

Media Playback

MP3 Compatible with Tag USB
WMA Compatible with Tag USB
WAV Compatible with Tag USB
AAC Compatible with Tag USB
FLAC Compatible with Tag USB
H.264 Compatible USB
MPEG 1/2 Compatible USB
MPEG 4 Compatible USB
AVI/MKV Compatible USB

Bluetooth Control

Built-in Bluetooth[1] Yes (Version 4.2, Wired-Mic included)
Hands Free Call Yes (HFP1.6 Wideband Speech)
Audio Streaming & Control (A2DP, AVRCP) Yes
Voice Dialing (voice recognition compatible mobile phone required) Yes
Phone Book Access Profile (PBAP) Yes

Phone Control

Android Control
Mirroring for Android Yes (via USB)
Android Music Playback Yes (via Bluetooth(R))

iPod/iPhone Control
iPod/iPhone Music Playback Yes (via USB or Bluetooth(R))


USB Port x1 (High Speed)
Position Rear
USB Power Supply Yes (1.0A)

Radio Tuner

Radio Broadcast Data System (RBDS) Yes
Preset Stations 30 (6ch x 5band)
Auto Memory Entry Yes
FM Frequency Range 87.9-107.9MHz
AM Frequency Range 530-1,700kHz


Maximum Power Output (Front & Rear) 45Wx4
Full Bandwidth Power (Front & Rear) 16W x 4 (Full Bandwidth Power, at less than 1% THD)
EQ Yes (13-Band Graphic EQ)
Preset EQ Yes (7Preset + 3user)
Bass Boost Yes
High-Pass Filter/Low-Pass Filter Yes/Yes
Time Alignment Yes

Inputs and Outputs

AV Input RCA x 1
Video Out RCA
Rear view camera Input Yes
Line Output Terminals 3 Pairs (Front (L/ R), Rear (L/ R), Sub.W (Mono) x1)
Pre-output Level/Impedance 2V / 10k ohms
Subwoofer Output with Level/Frequency Control Yes


Face Type Fixed
Short Chassis Yes
Wireless Remote Control Ready (RM-RK258 required)
Steering Remote Control Ready Yes
Learning Direct OEM Remote Yes
ISO Connector Yes
Dimensions (W x H x D)
Installation Size 7-3/16" x 4-7/16" x 3" (182 x 112 x 75 mm)
Weight 2.7 lbs. (1.2kg) : Including sleeve and trim plate
Unit weight in individual package 3.75 lbs. (1.7kg)

Car/Marine Receiver Features


Car/Marine Receiver Type

Double Din
