Kenwood STZ-RF200WD Motorsports HD Dash Cam with GPS and Rear-View Cam

Brand: Kenwood
Model Number: STZ-RF200WD
UPC: 019048232601
Model Number: STZ-RF200WD
UPC: 019048232601
Free Shipping

Save $221.00

$478.00

$699.00

|

OR

|

Payments as low as

$39.83/mo

Affirm
Limited Quantities

Availability: In Stock

Kenwood STZ-RF200WD Motorsports HD Dash Cam with GPS and Rear-View Cam

  • Full HD dash cam and rear-view cam
  • also includes main module, video selector switch, vehicle power adapter, universal mounts, and 32GB microSD card
  • 195° (diagonal) wide angle lens
  • CMOS image sensor
Limited Quantities

Product Description

Features & Specifications

Documents

Warranty

Kenwood STZ-RF200WD Motorsports HD Dash Cam with GPS and Rear-View Cam

Capture every mile you ride with Kenwood’s STZ-RF200WD dashcam and rear-view cam system for motorcycles, ATVs, and golf carts. Whether you’re documenting accidents or legendary road trips, Kenwood provides everything you need for Full HD video recording with an extra-wide, 195-degree view from the front and rear of your ride. Both cams are wired to a central module that saves video to an included microSD card and provides wireless viewing and syncing on your phone – just download Kenwood’s free app.

Bring on the rough stuff

Kenwood designed this camera system to handle the harshest conditions life on a motorcycle or ATV can deliver. So, you don’t have to sweat the rain, dust, and mud that’s bound to accumulate. And since Kenwood knows you’ll be traveling where most vehicles don’t (or can’t!), they use Electronic Image Stabilization for a steady picture in spite of the bumps and rattles as well as HDR for transitions between bright sunlight and dark shadows.

Built for convenient installation and use

This package includes two cameras and a main unit that taps vehicle power and starts recording once the engine starts, and stops when the engine shuts off. If you want to be sure you catch that magic moment, Kenwood provides a mountable remote control. All the while, the system’s built-in GPS antenna logs time, location, and speed information to enhance your videos. And in case of an accident, the STZ-RF200WD’s G-sensor triggers the system to store essential video for review later.

Catch ALL of the ACTION

Introducing a motorsports-grade Dual Camera recording system with hide-a-way control box for stealth installations in motorcycles, side-by-sides/UTV’s, ATV’s, watercraft & more.
*Operating temperature rated at -4°F to 140°F.

STZ-RF200WD

Motorsports Dual CAM Recording System

2 Megapixel HIGH DEFINITION Recording

Captures clear video from both directions.

full hivision

FRONT & REAR View Recording

The STZ-RF200WD includes 2 cameras: 1 to record in front of your vehicle and 1 to record behind your vehicle, all at the same time.

FRONT&REAR View Recording

EXTRA WIDE VIEW Camera Coverage

Both cameras cover a 195° (diagonal) extra wide range field of view.

Bike Angle

HDR (High Dynamic Range) for Backlighting

Built-in HDR easily records clear images in dark or well lit environments without underexposing or overexposing the image, ensuring superior night vision recording.

without HDRwith HDR
with HDR vs without HDR

EIS (Electronic Image Stabilization)

Bumpy roads and surfaces have met their match! Count on smooth and steady images with effective compensation for camera shakes with its built in image stabilization.

without EISwith EIS
without EIS vs with EIS

3-axis G-sensor & GPS

The STZ-RF200WD is equipped with a 3-axis G-Sensor designed to detect a collision and GPS that records speed, latitude, and longitude.

3-axis G-sensor&GPS

Waterproof & Dustproof

The cameras, GPS, and switch all carry an IP66/67, meaning that they can resist high-pressure, heavy sprays of water. They are also fully sealed against dust entry. The main unit carries an IP55 rating, meaning that it is protected against dust ingress and low pressure water jets.

Waterproof&Dustproof

MEMORY Included

A 32GB microSD card is included so that you can be ready to catch all of the action right out of the box. The system supports up to a 256GB microSD card (sold separately).

SUPER Capacitor

If power is lost, this prevents the recorded video file from being corrupted, as it provides enough power to allow the video file to close properly.

point super capacitor

WIRELESS Link

Enables video playback, file transfer, and easy setup via the KENWOOD Motorsports CAM smartphone app (*Device Requirement OS: Android 7.0 or later, OS: iOS 11.0 or later).
Once files are transferred to device, you can easily share recorded videos.

DashCam Image Smartphone Image
Wireless Link Image

Review the ACTION

KENWOOD Motorsports CAM Viewer is a desktop software for displaying video recorded with this system. Simply download the installer from Kenwood, then install according to the on-screen instructions.
*PC Requierment
Microsoft Windows 10 (32-Bit / 64-Bit). Mac OS-X 10.14 or later.

CamViewerPC Image

Compact Front & Rear Cameras

Small camera size provides for a stealthy look and easier installation in various locations.

YOU are in CONTROL

Multi-function control switch for simplified system control.

System Installation Example

system

Cable Length
(Total connected length from main unit)

  • GPS Antenna : 6.6ft / 2m
  • Switch : 6.6ft / 2m
  • Front Camera : 6.6ft / 2m
  • Rear Camera : 6.6ft / 2m
  • Power Cable : 3.3ft / 1m

EXPAND Your Options

The STZ-RFCC100 is an optional 3.3ft (1m) camera extension cable to enable installation in a larger variety of vehicle types.

Vehicle Image
Brand Kenwood   Model Kenwood STZ-RF200WD
Product: Kenwood STZ-RF200WD Motorsports HD Dash Cam with GPS and Rear-View Cam
Specifications

Recording Resolution: 1920 x 1080
Video Quality: Fine / Normal
Video File Format: MP4 ( Video format : H.264 audio format : AAC)
Recorded File Length: 30 seconds / 1 minute / 3minutes (Recording time for one file)
Recording Mode: Continuous recording, event recording, manual recording
Data Recorded: Video file, time and date, speed, location information
Audio Recording: ON / OFF
HDR: Yes
G-sensor: Yes (5 impact sensitivity settings / OFF)
GPS: Yes
Electronic Image Stabilization: Yes
Positioning Satellites: GPS / GLONASS
Storage Media: microSDHC, microSDXC Class 10 UHS-I, 16GB to 256GB
Power Supply: DC 12V
Power Consumption: 0.48 A
Operating Temperature: -20 °C to +60 °C, (-4 °F to 140 °F)

Waterproofing/ Dustproofing

Main Unit: IP55
Cameras: IP66/67
GPS/GLONASS Antenna: IP66/67
Control Switch: IP66/67

Front & Rear Camera Units

Image Sensor: 2 Megapixels ( effective pixels : 1.86 megapixels)
Lens Viewing Angle: 195° Diagonal (effective angle: 181°)
Frame Rate: 27.5 fps
F-number: 2.2

Recorded video Playback Methods

KENWOOD Motorsports CAM App
iOS 11 or later
Android 7 or later
KENWOOD Motorsports CAM Viewer
Apple Mac OS 10.14(Mojave) or later
Microsoft Windows 10

Dimensions

Measurement( W x D x H)
Main unit: 79 × 104 × 22.5 mm (3-1/8 x 4-1/8 x 7/8 inches)
Camera /pc 23.5 (Φ) × 34.4 mm (15/16(Φ) x 13/8 inches)
GPS/GLONASS Antenna 27.4 × 33 × 13 mm (1-1/8 x 1-5/16 x 1/2 inches)
Control Switch 25.8 × 36.9 × 9.5 mm (1 x 1-7/16 x 3/8 inches)

Weight(Excluding Cable)
Main unit: 105 g (0.2315 lb)
Camera / pc: 42 g (0.0926 lb)
GPS/GLONASS Antenna: 14 g (0.0309 lb)
Control Switch: 9 g (0.0918 lb)

What's in the box

Kenwood STZ-RF200WD owner's manual
Main hideaway module (w/ attached 25" front & rear camera cables / 16" GPS cable / 20.5" push-button cable / 13" power cable)
2 Cameras (attached 55" cable)
GPS Antenna w/ 3M adhesive backing (attached 63" cable)
Push-button w/ 3M adhesive backing (attached 59" cable)
29" Power/ground cable (inline 3A mini-ATO fuse)
32GB Micro-SDHC card
SD Card adapter
Two 3M adhesive camera-pads
Two 2-1/2" 3M adhesive pads
Four 6" wire-ties
2mm Allen key
Instruction manual (Eng/Span/Fren)
Warranty card
