Klipsch DS-250W LCR Dual 5.250″ In-Wall LCR Speaker x2 with Installation Bracket x2

Brand: Klipsch
Model Number: 154155
Model Number: 154155

Klipsch DS-250W LCR Dual 5.250″ In-Wall LCR Speaker (2) | Klipsch IK-502-W II Installation Kit (2) Bundle

  • Dual 5.25” Polypropylene woofer
  • 1” Silk Dome tweeter
  • Patent-Pending SkyHook™ Tool-Free Installation System
  • Bezel-Free Magnetic Grille





Payments as low as



Product Description

Features & Specifications




Klipsch DS-250W LCR Dual 5.250″ In-Wall LCR Speaker (2) | Klipsch IK-502-W II Installation Kit (2) Bundle

Klipsch DS-250W LCR Dual 5.250″ In-Wall LCR Speaker – (2)

The Klipsch DS-250W LCR uses the same Tractrix® horn technology and design principles of our premium architectural and box speaker lines, the all new Klipsch Designer series brings true Klipsch power and performance. With dual 5.25” Polypropylene woofers and a 1” Silk Dome tweeter mated to a round Tractrix® horn, the DS-250W LCR brings dynamic, powerful, detailed Klipsch sound to your home theater system or 2-channel system.

Klipsch DS-250W LCR

Patent-Pending Skyhook™ Tool-Free Installation System

The exclusive installation system engages the dog legs automatically when the speaker is inserted into the cutout hole with a preset clamping force, eliminating the possibility of over torquing. This fast, easy installation system reduces install time by up to 75%.

All New, Bezel-Free Magnetic Grille

A completely redesigned powercoated magnetic steel grille eliminates the bezel for seamless, pristine integration into the living space.

Klipsch IK-502-W II In-Wall LCR Speaker Install Kit for Klipsch Speaker – (2)

The Klipsch IK-502-W II installation kit brings increased mounting flexibility to three of our high-performance in-wall LCR speakers the R-2502-W, R-5502-W and KL-6502-THX.

This revolutionary kit design incorporates a mud ring breakaway wire tie and color-coded brackets for easy speaker size identification. A flat side with a raised wall allows it to be mounted directly to a joist making it much easier to align the speakers with other items in the ceiling.

The kit also comes with perforated metal wings that easily fasten to the studs via screws staples or nails. Ribbed for increased rigidity these wings enable a kit to span up to 24 inches easily. Painted white for easy marking and placement these metal wings will fold around the edge of the studs if necessary.

Brand Klipsch   Model Klipsch 154155
Product: Klipsch DS-250W LCR Dual 5.250" In-Wall LCR Speaker x2 with Installation Bracket x2
Weight 2.95 kg

– Frequency Range: 73Hz – 20kHz +/- 3dB
– High Frequency Driver: 1" (2.54cm) Silk Dome Tweeter mated to a 90°x90° Tractrix® Horn
– Low Frequency Driver: Dual 5.25" (13.34cm) Polypropylene Woofers
– Sensitivity: 92 dB @ 2.83V / 1m
– Coverage Angle: 100°
– Power Handling: 60W RMS / 240W Peak
– Impedance: 8 Ohm Compatible
– Enclosure Type: ABS/Infinite Baffle
– Finish: Black Baffle/Frame, White Paintable Grille
– Product Dimensions: 7.5” W x 17.4” H x 3.8” D (19.1cm H x 44.2cm W x 9.6cm D)
– Mounting Depth: 3.78” (9.35cm)
– Cutout Dimensions: 16.5” H X 6.5” W (41.9cm H X 16.5cm W)
– Product Weight: 6.5lbs (2.95kg)
– Included: Flat Magnetic Grille
– Installation Kit: IK-502-W II (Sold Separately)
– Built From: 2017

Number of Speakers

Speaker Size


, ,


Back Order Allowed

Estimated Shipping

When you add an item to your cart the Estimated Shipping* cost will be shown.  This estimated shipping* cost is accurate to most major city locations across Canada.  If the shipping cost is higher than the estimated shipping* then GibbysESM will contact you for approval before we process your order.

To learn more click Shipping Terms & Conditions

Klipsch offers a limited lifetime Warranty – Architectural Speakers
