Memphis Audio PRX1224 Power Reference 12″ DVC Component Subwoofer – Selectable 2 or 4-ohm Impedance

Brand: Memphis
Model Number: PRX1224
UPC: 841992161979
Model Number: PRX1224
UPC: 841992161979
Free Shipping

Save $50.00

$229.95

$279.95

|

OR

|

Payments as low as

$19.16/mo

Affirm

Availability: In Stock

Memphis Audio PRX1224 12″ DVC Component Subwoofer

  • selectable 2- or 4-ohm impedance
  • treated paper cone with double-stitched butyl rubber surround
  • power handling: 300 watts RMS (600 watts peak)
  • sensitivity: 85.8 dB
  • frequency response: 30-150 Hz

Product Description

Features & Specifications

Documents

Warranty

Memphis Audio PRX1224 Power Reference 12″ DVC Component Subwoofer – Selectable 2 or 4-ohm Impedance

Power Reference subwoofers are a staple of the Memphis line.  Proven performance and reliability is the reason Power Reference is our best selling subwoofer. Power Reference has been drastically improved with the additional of Memphis Audios patent pending Selectable Impedance Technology. This unique terminal allows you to switch your subwoofer between 2 Ohm and 4 Ohm simply by moving a jumper cable to a color coded terminal. Our proprietary connection and voice coil designs result in ZERO performance loss making these some of the most versatile subwoofers on the market. Want to upgrade your system froma  single sub to dual subs in the future? no problem, simply switch the setting to achieve the desired impedance and expand your system!

Rolling thunder

Memphis Audio built their Power Reference Series subwoofers to bring strong low-frequency punch into your vehicle. The PRX1224 12″ subwoofer delivers big bass and high output, with a heavy-duty suspension that allows this sub to handle up to 300 watts RMS.

Easy to set up, easy to love

This Power Reference Series subwoofer is built to dish it out and take it. Its treated paper cone and double-stitched butyl rubber surround pump out the lows with toughness and precision. Improvements to the coil and suspension design give you even more of that great Memphis sound. Selectable Impedance Technology allows you to select 2- or 4-ohm impedance using the included color-coded jumpers, making adjustments dead easy and giving you a wide range of installation and system options.

Do you hear a rumble in the distance? That’s the bass you’ve been waiting for on its way to you from Memphis Audio.

PRX1224 Features:

  • Selectable impedance design 2Ohm or 4Ohm
  • DVVC Direct Voice Coil Cooling technology
  • Black on black polypropylene cone
  • Double stitched butyl rubber surround
  • Reinforced spider shoulder
  • Improved suspension and coil design
  • Woven tinsel leads
  • High temperature TIL voice coil former
Brand Memphis   Model Memphis PRX1224
Product: Memphis Audio PRX1224 Power Reference 12" DVC Component Subwoofer – Selectable 2 or 4-ohm Impedance
Specifcations

Size: 12 -inch
Impedance (Ohms): 2, 4
Cone Material: Treated Paper
Surround Material: Rubber
Ideal Sealed Box Volume (cubic feet): 1.25
Ideal Ported Box Volume (cubic feet): 2.75
Free-Air: No
Dual Voice Coil: No
Sensitivity: 86.2 dB at 1 watt
Frequency Response: 30 – 150 Hz
Max RMS Power Handling: 300
Peak Power Handling (Watts): 600
Top Mount Depth (inches): 5 1/2
Cutout Diameter or Length (inches): 11 1/16
Vas (liters): 43.58
Fs (Hz): 35
Qts: 0.664
Xmax (millimeters): 10.5

What's in the box

Memphis Audio PRX1224 owner's manual
One 12" Subwoofer
Rubber trim ring/gasket (installed)
One 4-ohm jumper wire (installed)
Two 2-ohm jumper wires
Specification sheet
Warranty information

Car Subwoofer Features

Dual Voice Coil

Car Subwoofer Size

12"

RMS Power

201 to 400 Watts

Impedance

2 Ω, 4 Ω
