NAD D 3020 V2 Hybrid Digital DAC Amplifier | PSB Alpha P5 Bookshelf Speakers – Walnut – Pair

Brand: PSB, NAD
Model Number: 343353
UPC: Bundle
Model Number: 343353
UPC: Bundle
Free Shipping

Save $49.00






Payments as low as


Order Now Limited Quantities Items may ship separately Call to Inquire

NAD D 3020 V2 Hybrid Digital DAC Amplifier | PSB Alpha P5 Bookshelf Speakers – Walnut – Pair

This Bundle Includes:
(1) NAD D 3020 V2 Hybrid Digital DAC Amplifier
(1) PSB Alpha P5 Bookshelf Speakers – Walnut – Pair

Order Now – Limited Quantities – Items may ship separately – Call to Inquire

Product Description

Features & Specifications



NAD D 3020 V2 Hybrid Digital DAC Amplifier | PSB Alpha P5 Bookshelf Speakers – Walnut – Pair

This Bundle Includes:
(1) NAD D 3020 V2 Hybrid Digital DAC Amplifier
(1) PSB Alpha P5 Bookshelf Speakers – Walnut – Pair

NAD D 3020 V2 Hybrid Digital DAC Amplifier

Reinventing an Icon

By adapting to today’s media sources and using state-of-the-art digital technology for the new world of digital music. The D 3020 puts a completely modern spin on a revered icon. The original designer of the 3020, NAD’s Director of Advanced Technology, Bjorn Erik Edvardsen, has been pivotal in developing the D 3020 for the new digital generation. Offering an excellent quality 24/192 DAC with 8 channels mixed to 2 for improved resolution, the D 3020 V2 represents the same kind of value-bending innovation that gave the original 3020 its legendary overachieving phono stage.

More Connected

The D 3020 offers inputs for your digital and analogue sources. Coaxial and optical inputs allow many different digital sources to be connected, from CD and DVD players, to set top boxes, media streamers like AppleTV, or satellite and cable receivers. There are also analogue inputs including a sophisticated MM Phono input. Far from just another set of sockets, this Phono stage includes highly accurate RIAA equalization, an Infrasonic Warp Filter, and features both high overload margins and extremely low noise. With V2 we’ve also added a PreOut for increased connectivity in the output stage.

NAD D 3020 V2 Lifestyle

Power that Delivers

Power output may sound small at 30W per channel. Like all NAD amplifiers this is very misleading. As a properly designed 30W amplifier can sound superior to a 100W amplifier from a lesser brand. With its very small form factor, the D 3020 will astound many for its ability to drive difficult loudspeakers to satisfying levels without adding noise or distortion.

Real World Performance

NAD rewrote the rules for amplifiers when designing the original 3020. Instead of letting laboratory test equipment have the last word, we made sure that we could properly drive real loudspeakers with real music for the real world. The D 3020 lives up to this promise through a unique implementation of NAD PowerDrive developed by Edvardsen. That allows low impedance drive (current) and high dynamic power (voltage) at vanishingly low distortion levels. This refinement of PowerDrive combined with a precision soft clipping circuit, lets the D 3020 sound even more powerful than it already is. Lastly, an innovative Bass EQ circuit helps small speakers sound big without overdriving or damaging ported woofers.

Stream with Bluetooth

The D 3020 V2 delivers the convenience of wireless streaming with its Bluetooth® capability. Stream all your music from a smartphone, tablet, or also laptop. The D 3020 even supports the highest audio quality Bluetooth, aptX®, which is becoming ever more popular for its excellent sound quality and low power consumption compared to Wi-Fi.

Mean and Green

The D 3020’s highly efficient design wastes less energy, requiring only 20% of the power needed by traditional Hi-Fi amplifiers. It’s like trading in a gas guzzling car for a hybrid vehicle. Standby power consumption is a miniscule <0.5W. NAD has taken amplification to new lows, with lower distortion, lower noise, and also lower power consumption. NAD’s major focus is to find new technology that improves musical performance while consuming less power and using fewer non-renewable resources in manufacturing.

PSB Alpha P5 Bookshelf Speakers – Walnut – Pair

These PSB Alpha P5 Bookshelf Speakers are Priced and Sold as a Pair

Breakthrough design for incredible studio quality sound. A timeless two way bookshelf speaker with a 5.25” woofer, the Alpha P5 allows you to transform your system with pristine sound. Featuring a refined bass reflex cabinet and a port tube first developed for the original Alpha speaker, the Alpha P5 creates a pure and natural soundstage by utilizing the latest and most advanced driver technologies and magnet structures. The Alpha P5 was perfectly tuned inside the anechoic chamber of Canada’s acoustic research facilities to produce a perfectly flat frequency response that lets you enjoy the subtleties of your music and movies with lifelike detail.

PSB Alpha P5


The Alpha P5 uses a 0.75” black anodized aluminium dome tweeter to extend the high frequency response further than any Alpha ever before while lowering distortion to deliver layered sound with detail and clarity. Unlike lesser designs at this price, all of the new Alpha Series tweeters employ ferrofluid cooling to prevent dynamic compression and a neodymium magnet for high sensitivity. The tweeter’s front waveguide and its unique placement below the woofer work together to smooth the response at the crossover and perfect on and off axis performance.


When paired with the Alpha Series’ newly designed tweeter, the Alpha P5’s custom 5.25” woofer provides remarkable low frequency response and the highest speaker efficiency in its class. The woofer is constructed from a special textured polypropylene compound that minimizes cone breakup and lowers distortion at full excursion. It’s also supported with dual layer voice coils and a bass reflex design that uses the rear firing port tube to control the bass response down to room shaking levels.

PSB Alpha P5


The Alpha Series’ new crossover exceeds speaker standards with a special custom design  that does more than direct low and high frequencies to the individual drivers it delivers the tightest control and the flattest frequency response. An unusually complex Link-witz-Riley acoustic filter has also been incorporated into the crossover design to lower distortion and create a seamless soundscape in any type of two channel setup or surround sound system.


A unique combination of wall thickness and bracing controls resonances and provides a perfect platform for the Alpha P5’s driver components, while its internal damping material is from PSB’s flagship lines and has been precisely positioned for optimal effectiveness. Finished with a high quality wood grain vinyl and magnetically attached grilles that are acoustically transparent, the Alpha P5 is perfectly designed to seamlessly disappear into any décor and  provide rich, detailed sound.



First designed and manufactured in a small Canadian town in 1991, the Alpha Series started with the simple idea of creating affordable speakers that were focused purely on performance. With passion and dedication in pursuit of a natural sounding speaker, and by leveraging decades of research conducted at the Canadian National Research Council by PSB’s founder, Paul Barton, the Alphas quickly rose to be one of the world’s most iconic speakers and are still the reference benchmark for entry-level hi-fi speakers today. The newly designed Alphas look to continue their legacy by staying true to the original concept from the ’70s and combining it with today’s latest cutting-edge technologies. Powerful and smooth, the all-new Alpha Series has been rebuilt with enhanced custom drivers and a new crossover design that works perfectly together to deliver natural, detailed sound with precision and less distortion. In a home theatre or stereo setup, the new Alphas outperform the originals in every measurement and will bring your music and movies to life.

Brand NAD   Model NAD 343353
Product: NAD D 3020 V2 Hybrid Digital DAC Amplifier | PSB Alpha P5 Bookshelf Speakers – Walnut – Pair
D 3020 V2 Specifications

– Standby Power : ≤0.5 Watts
– Supports bit rate/sample rate : up to 24/192 (via Digital Audio input)

Audio Specs
– Rated Power at 8 Ohms : 2 x 30 Watts
– IHF Dynamic Power 8 Ohms : 2 x 60 Watts
– 4 Ohms : 2 x 100 Watts
– 2 Ohms : 2 x 150 Watts
– Signal/Noise Ratio (A-weighted, ref. 1 Watt) : ≥90dB
– Channel Separation 1kHz : ≥75dB
– 10kHz : ≥65dB
– Channel Balance : 0 ±0.3dB
– Frequency Response (20Hz – 20kHz) : 0dB to -0.3dB
– Total Harmonic Distortion : ≤0.005%
– Maximum Input Level : 5V
– IMD (SMPTE) : 0.02%
– IMD (CCIF) : 0.003%

MM Phono Input
– Phono Signal-to-Noise Ratio: >82 dB (200 ohms source, A-weighted, ref. 500 mV out) / 76 dB (MM cartridge source, IHF; A-weighted, ref. 500 mV out)
– Input Sensitivity : 1.15 mV (ref. 500 mV out, Volume maximum)
– Maximum Input Signal at 1kHz : >90 mVrms (ref. 0.1 % THD)
– Frequency Response : ±0.3 dB (20 Hz – 20 kHz)

– Width : 58mm ( 2 5/16" )
– Height : 186 mm ( 7 3/8" )
– Depth : 219 mm ( 8 5/8" )

– 1.38 kg ( 3.05 lbs )

Amplifier – DAC

Amplifier Channels


RMS Power
201 to 400 Watts

Watts Per Channel
51 to 150w

Alpha P5 Specifications

– Enclosure: Bass Reflex
– Finish: MDF, Wood-grain vinyl
– Video Shielded: No
– Tweeter Type: Hard-Dome
– Tweeter Size (inches): 0.75
– Woofer Size (inches): 5.25
– Woofer Composition: Polypropylene
– Woofer Surround: Rubber
– Power Range: 10-90
– Sensitivity: 89 dB
– Impedance (Ohms): 8
– Frequency Response: 55-21k Hz
– Connector Type: 5-way post
– Bi-amp Inputs: No
– Height (inches): 11-1/2
– Width (inches): 6-3/4
– Depth (inches): 10
– Weight (pounds): 10.15
– Mounting Bracket Included: No
– Recommended Stand Height (inches): 28-30

Enclosure Type
Bass Reflex

Speaker Sensitivity
86 – 90 db

8 Ω

Number of Speakers
2 Speakers
