Panamax SP8-AV 8-Outlet Surge Protector

  • In / Out Telephone Connectors.
  • In / Out Coax Connectors for Cable/Sat.
  • Six (6)ft, Power Cord with Right Angle 45 degree Offset Plug.
  • Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.
  • Ground OK LED
  • ON / OFF Power Switch and 15A Circuit Breaker.
Limited Quantities

Product Description

Features & Specifications

Documents

Warranty

Panamax SP8-AV 8-Outlet Surge Protector

SP8-AV Eliminates voltage irregularities and protects your AV system.

AC power, telephone and coax lines can provide direct pathways for surges and spikes to enter and damage expensive audio/video equipment. Panamax’s SP8-AV eliminates voltage irregularities and protects your AV system.
Guard your home theater system against harmful spikes and power fluctuations with the Panamax SP8-AV. This surge suppressor also filters out the RF (radio frequency) and electromagnetic interference that can degrade your system’s performance.
The SP8-AV comes with eight outlets, each conveniently spaced to allow for bulky transformers. A set of coaxial input/output jacks protects your cable, antenna, or digital satellite TV connections. There’s also a protected telephone line input/output.
The surge suppressor reacts in less than a nanosecond during a spike, breaking the connection to keep your equipment safe. The 6-ft. power cord’s right-angle plug hugs the wall, for an easy fit behind a chair or sofa.

SP8-AV Features

  • Power Status LED.
  • In / Out Telephone Connectors.
  • In / Out Coax Connectors for Cable/Sat.
  • Six (6)ft, Power Cord with Right Angle 45 degree Offset Plug.
  • Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.
  • Ground OK LED.
  • 8 AC Outlets Provide Power Protection with Transformer Spacing Between Outlets.
  • ON / OFF Power Switch and 15A Circuit Breaker.



Brand Panamax   Model Panamax SP8-AV
Product: Panamax SP8-AV 8-Outlet Surge Protector
Features

-Power Status LED.
-In / Out Telephone Connectors.
-In / Out Coax Connectors for Cable/Sat.
-Six (6)ft, Power Cord with Right Angle 45 degree Offset Plug.
-Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.
-Ground OK LED.
-8 AC Outlets Provide Power Proection with Transformer Spacing Between Outlets.
-ON / OFF Power Switch and 15A Circuit Breaker.

Specifications

Voltage Protection Rating (UL 1449 3rd Edition, 3,000A): 500V
Thermal Fusing: Yes
Single Pulse Energy Dissipation: 1125 Joules
Response Time: < 1 ns
Peak Impulse Current: 60,000 Amps

Telco Protection:

Wires Protected: 1 Line (3, 4)
Suppression Modes: Metallic & Longitudinal
Fuseless / Auto-reseting: Yes
Connectors: RJ-11
Clamping Level: 260V
Capacitance: 30pf (approx.)

Universal Coaxial Protection:

Shielded: Yes
Insertion Loss: < 0.5 dB
Frequency Range: OMHz – 2.2 GHz
Connections: Female “F”, Gold Plated
Clamping Level: 75V
Bidirectional: Yes

Estimated Shipping

When you add an item to your cart the Estimated Shipping* cost will be shown.  This estimated shipping* cost is accurate to most major city locations across Canada.  If the shipping cost is higher than the estimated shipping* then GibbysESM will contact you for approval before we process your order.

To learn more click Shipping Terms & Conditions

Panamax Canada Lifetime Limited Product Warranty.
