Paradigm SIG-LCR 5V3 In-Wall Speakers

Paradigm SIG-LCR 5V3 6-driver, 3-1/2-way integrated in-wall left / center / right system

The Paradigm SIG-LCR 5V3 In-Wall Speakers are a 6-driver, 3-1/2-way integrated in-wall left / center / right system. The critical bracing and volume are supplied by the required Paradigm BX-LCR 5 backbox, which is sold separately. The speaker system has a crossover of 3rd-order electro-acoustic at 2.5 kHz, 2nd-order electro-acoustic at 500 Hz, and 2nd-order electro-acoustic at 350 Hz for the outer bass drivers.

The frequency response of the Paradigm SIG-LCR 5V3 In-Wall Speakers is on-axis ±2 dB from 58 Hz to 45 kHz, with a low-frequency extension of 38 Hz (DIN). The high-frequency driver of the speaker system is a 25-mm (1 in) P-Be™ dome with a rear damping chamber, ARB™ fins, and an integrated heatsink, along with dual super-neodymium magnets, a die-cast heatsink chassis, and IMS/SHOCK-MOUNT™.

The mid/bass frequency driver consists of two 178-mm (7 in) Co-PAL™ cones, anodized solid-aluminum phase plugs, 38-mm (1-1/2 in) dual-layer voice-coils, ceramic/ferrite magnets, AVS™ die-cast heatsink chassis, and IMS/SHOCK-MOUNT™. The midrange frequency driver has a 115-mm (4-1/2 in) Co-PAL™ cone, anodized solid-aluminum phase plug, 25-mm (1 in) dual-layer voice-coil, dual super-neodymium magnets, AVS™ die-cast heatsink chassis, and IMS/SHOCK-MOUNT™.

The low-frequency driver of the speaker system comprises two 178-mm (7 in) mineral-filled polypropylene cones, 38-mm (1-1/2 in) four-layer voice-coils, massive ceramic/ferrite magnets, AVS™ die-cast heatsink chassis, and IMS/SHOCK-MOUNT™. The sensitivity of the speaker system is 94 dB in a room and 90 dB in an anechoic environment, with a frequency response of ±2 dB from 58 Hz to 20 kHz at 30° off-axis.

The Paradigm SIG-LCR 5V3 In-Wall Speakers have a suitable amplifier power range of 15 – 500 watts and a maximum input power of 250 watts. They are compatible with 8 ohms impedance and weigh 23 lbs. (10.4 kg). The finishes of the speaker system are available in white and paintable. The overall dimensions of the speaker system are 36.375″ (92.4cm) in height, 9.125″ (23.2cm) in width, and ” (0.0cm) in depth.
