Pioneer DMH-T450EX 9″ Digital Media Receiver | Kenwood KAC-D3104 4-Channel Power Amplifier | JL Audio C1-690 6×9″ 2-Way Component Speakers – Pair – Bundle

Brand: Pioneer, JL Audio, Kenwood
Model Number: 342900
Model Number: 342900
Free Shipping

Save $374.96






Payments as low as



Availability: In Stock

Pioneer DMH-T450EX Receiver | Kenwood KAC-D3104 Amplifier | JL Audio C1-690 Component Speakers – Pair – Bundle

This Bundle Includes:

(1) Pioneer DMH-T450EX 9″ Capacitive Touchscreen Digital Media Receiver
(1) Kenwood KAC-D3104 Class D 4-Channel Power Amplifier
(1) JL Audio C1-690 6×9″ 2-Way Component Speakers – Pair – #99046

Product Description

Features & Specifications



Pioneer DMH-T450EX 9″ Digital Media Receiver | Kenwood KAC-D3104 4-Channel Power Amplifier | JL Audio C1-690 6×9″ 2-Way Component Speakers – Pair – Bundle

This Bundle Includes:

(1) Pioneer DMH-T450EX 9″ Capacitive Touchscreen Digital Media Receiver
(1) Kenwood KAC-D3104 Class D 4-Channel Power Amplifier
(1) JL Audio C1-690 6×9″ 2-Way Component Speakers – Pair – #99046

Pioneer DMH-T450EX 9″ Capacitive Touchscreen Digital Media RDS AV Receiver

DMH-T450EX 9″ Capacitive Touchscreen, Amazon Alexa when Paired with Pioneer Vozsis App, Bluetooth®, Back-up Camera Ready – Digital Media Receiver

The DMH-T450EX is a 9″ capacitive touchscreen digital media receiver aimed at improving in-car entertainment and smartphone compatibility. Enjoy features like built-in Bluetooth® for hands-free calling and audio streaming. Playback of audio/video files from a USB drive. Backup camera readiness and other safety features are available.

Floating Display

The DMH-T450EX is a large display double DIN receiver with a floating display and a full-size fitting. The floating screen can be adjusted horizontally, vertically, and tilted to ensure the greatest fit and usage on the vehicle’s dash.

Vozsis with Amazon Alexa

Vozsis is a smartphone app available for both iOS and Android OS devices that brings Amazon Alexa capability to compatible Weblink-enabled Pioneer multimedia in-dash receivers. Downloading both the Vozsis and Weblink applications makes using Alexa in your car simple – just tap-and-ask, and Alexa will respond instantly. With Alexa, you can ask to play music, hear the news, check weather, control smart home devices1, and more. Alexa lives in the cloud, so it’s always getting smarter, adding new capabilities that are delivered to your device automatically.

Hands Free Bluetooth

The DMH-T450EX receiver simplifies hands-free phone calls. The external microphone offered by Pioneer produces crystal clear sound. Stream music, podcasts, audiobooks, and other content from your Bluetooth-enabled phone or other Bluetooth devices.

DMH-T450EX – Back Up Camera Input Ready*

Back Up Camera input enables you to add a rear-view camera, with the system automatically switching to a full-screen image of the rear view when the car is placed in reverse gear. The full-screen image returns to the source screen last in use when the vehicle is taken out of reverse gear.

*Rear visibility systems (backup cameras) are required under federal regulations in certain new vehicles according to a phase-in schedule that began on May 1, 2016. Owners of vehicles equipped with compliant rear visibility systems should not install or use this product in a way that alters or disables that system’s compliance with applicable regulations. If you are unsure whether your vehicle has a rear visibility system subject to these regulations, please contact the vehicle manufacturer or dealer.

Customize Your Colors

Select among five colors (blue/red/amber/green/violet) for the DMH-T450EX display. Also choose from several background images to suit your mood.


Pioneer’s in-dash receivers offer playback of files encoded as high-res FLAC up to 192kHz/24 bit through USB. With Pioneer, your high-res FLAC is no longer confined to your home hi-fi system – put your music on the move.

Kenwood KAC-D3104 Class D 4-Channel Power Amplifier

KAC-D3104 D Series Amplifiers offer a strong solution in a small package, making them ideal for updating your automobile audio system.

The Kenwood KAC-D3104 is a compact 4-channel power amplifier with a max power output of 600W. It features a variable high pass and low pass filter, bass boost, speaker level input, and signal sensing turn-on. The amplifier is designed with a Class D amp technology and has a conformal-coated circuit board, making it suitable for marine and power sports applications. The KAC-D3104 is a small and lightweight amplifier that is easy to install and has a sleek design that will complement any car audio system.

Increased Frequency Response

The Kenwood KAC-D3104 supports Hi-Res Audio and has a frequency response of up to 50kHz, making it perfect for high quality audio playing.

Kenwood KAC-D3104

Dual Sigma Power

The Kenwood KAC-D3104 circuit’s sophisticated negative feedback enhances damping factor, precision, and sound quality. When a signal, such as a 50Hz note, is sent to a subwoofer, the speaker moves and produces the sound. Nonetheless, because the speaker has mass and suspension, it will continue to move once started. This additional movement (sound) causes distortion that was not there in the original signal. When the negative feedback circuit detects this undesirable movement, it sends an opposing pulse to the speaker, thus acting as an electrical brake.

Kenwood KAC-D3104

Compact Size, Massive Power

The Kenwood KAC-D3104 is modest in size, yet it is incredibly adaptable because to its powerful sound output. It may be fitted in vehicles with limited space and is ideal for vehicle owners who do not want to lose cargo capacity or want discreet installations.

KAC-D3104 Outlook

Kenwood KAC-D3104

  • 1 Fuse (20A x 2)
  • 2 Battery Terminal (Power IN BATT.)
  • 3 Power Control Terminal (P.CON)
  • 4 Ground Terminal (GND)
  • 5 Speaker Output Terminals ( /
  • 6 Filter Frequency Control ( /
  • 7 Filter Switch ( /
    • HPF(High-Pass Filter ) Position
    • Off Position
    • LPF (Low-Pass Filter) Position
  • 8 Bass Boost Level Control (
  • 9 Input Sensitivity Control ( /
  • 10 Line In Terminal ( /




JL Audio C1-690 6×9″ 2-way Component Car Audio Speakers #99046 – Pair

The JL Audio C1-690 are starter speakers like no other. After an extensive tour of JL Audio HQ, their engineering and development team talked about the current JL Audio lineup and upcoming projects. Given all the work they’re doing with premium car audio, many were surprised by how excited they were for customers to hear their workhorse C1 Series speakers. Designed for drivers simply looking for a sensible factory speaker replacement, not necessarily an audiophile-grade solution. Every JL Audio speaker must uphold the quality and sound associated with the name. You may be looking for something that’s just listenable, but what you’ll get with the JL Audio C1-690 is an audio experience that puts it at the top of its class. And then, just maybe, you’ll end up being a JL Audio fan for life.

What sets C1 apart?

JL Audio designed the JL Audio C1-690 speakers to be the very best they could be for the price. You’ll find solid construction and finish, along with some eye-popping flair in its striking yellow mineral-filled polypropylene woofer. That woofer delivers impactful lows and is specially designed for a natural roll-off transition to the highs handled by the tweeter. And it’s the separate aluminum edge-driven tweeter that gives the C1 Series its distinctive sound, setting it apart from other speakers in its class. You’ll hear crisp detail in the high frequencies, incredible imaging, and minimal distortion no matter how you power them. Included crossover networks ensure that the right speakers receive the right frequencies.

Why no grilles?

Most folks have no use for aftermarket grilles, opting to use their factory grilles for a streamlined look. With that in mind, JL Audio doesn’t include grilles with the JL Audio C1-690, opting instead to incorporate those savings into building an all-round better speaker.


Woofers: Each JL Audio C1 woofer features a mineral-filled, injection-molded polypropylene cone with a rubber surround.

Tweeters: The 1″ edge-driven, aluminum dome tweeters are damped by a silk surround suspension. Flush and surface tweeter mounting brackets are included.

Tweeter Crossovers: The in-line tweeter crossovers are 2nd order (12 dB/octave slope) and the 31″ input and 14″ output wires are attached. The input wires are terminated with female quick slides that plug into terminals on the woofers and the output wires are terminated with male quick slides that plug into the terminals on the wires attached to the tweeters. The woofer is unfiltered, using its engineered roll-off characteristics to blend with the tweeter. The electronic tweeter protection circuit is designed to minimize the possibility of tweeter failure. It monitors current going to the tweeter and will disconnect the tweeter from the signal when it senses overload. Once the volume has been reduced, the protection circuit will reset itself automatically.

Power Handling: JL Audio publishes several power specifications for this speaker system, 60 watts continuous power handling (RMS), 225 watts peak music power, and 10-100 watts recommended amplifier power (RMS). We’ve listed the conservative combination of 10-60 watts RMS in the specs table.

Woofer Specifications

Lineart Bottom-View and Side-View of C1-690 Coaxial Speaker with dimension labels A-G

Frame Outer Diameter* (A) 6.38 x 9.33 in / 162 x 237 mm
Motor Outer Diameter (C) 3.54 in / 90 mm
Mounting Depth (G) 2.75 in / 70 mm


Tweeter Specifications

Lineart Side-View of flush mounting and surface mounting options for C1-100ct Tweeter with dimension labels A-E

Flush Mount Fixture Diameter (A1)










1.97 in / 50 mm

Surface Mount Fixture Diameter (A2) 2.01 in / 51 mm
Flush Mount Mounting Hole Diameter (B) 1.75 in / 45 mm
Flush Mount Mounting Depth (C) 0.40 in / 10 mm
Flush Mount Tweeter Frontal Protrusion (D1) 0.32 in / 8 mm
Surface Mount Tweeter Frontal Protrusion (D2) 0.87 in / 22 mm


Brand Pioneer   Model Pioneer 342900
Product: Pioneer DMH-T450EX 9" Digital Media Receiver | Kenwood KAC-D3104 4-Channel Power Amplifier | JL Audio C1-690 6×9" 2-Way Component Speakers - Pair - Bundle

CTA-2006: Yes

Continuous Power Output: 22 W x 4-Channel
Load Impedance Allowance: 4 Ohm (4 Ohm to 8 Ohm Allowable)
Max Power Output: 50 W x 4-ch 4 ohm
RCA Preamp Outputs: 5-Channel
RCA Pre-out: 2V
RMS Power Output (CTA-2006): 14 W RMS x 4-ch 4 ohm

Anti-Glare/Reflection: Yes
Back Light: LED
Brightness Control: Yes
Color Customization: 5 key colors, 3 Preset Background Images
Device (Non-DIN/Modular Unit): 2-DIN, Floating
Dimmer: Automatic with vehicle illumination, Manual
Display Off Mode: Yes
Monitor Mechanism: Fixed
Resolution: 1024×600
Screen Size/Aspect Ratio: 9"/16:9
Touch Screen: Capacitive

Advanced Audio Distribution Profile (A2DP): Yes
AVRCP: 1.6
Built-in Bluetooth: Yes
Dual Phone Connection: Yes
Hands-Free: Yes
Microphone Included: Included
Phone Registration: 5-phone
Secure Simple Pairing (SSP): Yes
Serial Port Profile (SPP): Yes

Best Station Memory: Yes
Local Seek tuning: Yes
Presets: 18 FM, 6 AM
PS (Preset Scan): Hide or display radio station name
RDS: Yes

Amazon Alexa: Paired with Pioneer Vozsis
Mobile Operating System: Android / Apple iOS
Pandora: Bluetooth Audio Source
Pioneer App Compatibility: Vozsis Android, Vozsis iPhone
Siri® Eyes Free (VR) (Internet Required): iPhone Only
Spotify: Bluetooth Audio Source
Voice Control: Yes
Weblink: 3.0

Audio Playback via USB: AAC Audio Playback / FLAC Audio Playback (Hi-Res) / MP3 Audio Playback / WAV Audio Playback (Hi-Res) / WMA Audio Playback
Audio Video Playback via USB: .avi / .mpg/mpeg / .mp4 / .mkv / .mov / .flv / .m4v / .ts/.m2ts/.mts / H.263 / H.264
Image Display via USB: BMP / JPEG / PNG

Bass Boost: Yes
Balance: Yes
Built-in Amplifier: MOSFET 50 W x 4
Crossover Standard Mode: HPF/LPF
Customizable Graphic Equalizer: 13 Band
DA Converter: 24 Bit
Digital Signal Processor: Built In
Easy EQ (EEQ) Preset Equalizer: Yes
Fade: Yes
Loudness: High/Mid/Low/Off
Speaker Output: 4-Channel
Subwoofer Control: Yes

RCA Video Output: Yes
USB: Single Rear Type-A (5V, 1.5 A)
USB Direct Control for iPhone: 5s and newer

Input 1: Backup Camera Dedicated
Input 2: AUX (Minijack)

Detachable Face Security: Fixed
Multi-Language Display: English, French, Spanish Portuguese, Chinese (Simplified)
Music Browser: USB
Remote Control: Optional
Steering Wheel Control Ready (Adapter Sold Separately): Yes

What’s in the Box
Digital receiver w/ fixed 9" touchscreen monitor (10A fuse)
Wiring harness
1.5m USB Extension Cable Type A(M) to Type A(F)
Microphone w/ visor-bracket (attached 10' cable terminated by a right-angled 2.5mm connector)
6 Installation Screws
Installation Manual
Quick Start Guide
1 year warranty sheet


Max Power: 600W
Size (inch): (W) 6-11/16″ x (H) 2-3/16″ x (D) 7-3/8″
RMS POWER OUTPUT Bridged: 150W x 2 (Bridged)
Dimensions: (W)6-11/16” x (H)2-3/16” x (D)7-3/8”
Weight 2.9 lbs ( 1.3kg)

Speaker Level Input
Signal Sensing Turn-On
Variable High Pass Filter
Variable Low Pass Filter
Bass Boost


Speaker Size: 6X9
Design: 2-way
Tweeter Design: 1" Edge-Driven Dome
Impedance: 4 Ohms
Tweeter Composition: Aluminum
Woofer Composition: Mineral-Filled injection-Molde
Woofer Surround: Rubber
Sensitivity (1W at 1 meter): 91.5
Sensitivity at 2.83 volts: 94
Frequency Response: 39 – 22k Hz
Minimum RMS Wattage: 10
Maximum RMS Wattage: 60
Peak Power Handling: 225 Watts
Top-mount Depth: 2 3/4"
Bottom-mount Depth: 3 9/16"
Mounting Height: 0.256"

What's in the box
JL Audio C1-690 owner's manual
2 C1-690cw Woofers
2 Bottom mount woofer brackets
2 C1-100ct Tweeters (with 6" wires attached)
2 Tweeter crossovers
2 Flush mount tweeter housings (tweeters installed)
2 Surface mount tweeter housings
2 Metal spring clips for tweeter fixtures
2 Crimp-on 0.187" Female quick slides
2 Crimp-on 0.110" Female quick slides
Four 5/8" Flat head screws
Eight 3/4" Pan head screws
Eight 1-1/2" Pan head screws
8 Speed clips
Two 25mm Stud bolts
Two 10mm Stud bolts
2 M5 Nuts
Owner's manual

Car/Marine Receiver Features

Bluetooth, Navigation, WebLink

Car/Marine Receiver Type

Double Din

Mobile Amplifier Channels

4 Channel

Mobile Amplifier Class

Class D

Mobile Amplifier Features

Bass Boost, High-Pass Filter, Low-Pass Filter, Speaker Level Inputs

Mobile Amplifier Fuse Rating


Mobile Amplifier RMS

351 to 750 watts

Mobile Min Impedance
