Pioneer DMH-W2770NEX 6.8″ Shallow Mount Digital Multimedia Receiver | Alpine S-A60M Mono Power Amplifier | RUX-KNOB.2 Remote Control | JL Audio CP210-W0v3 10″ Subwoofer – Bundle

This Bundle Includes:

(1) Pioneer DMH-W2770NEX 6.8″ Shallow Depth Digital Multimedia Receiver
(1) Alpine S-A60M Class-D S-Series Mono Power Car Amplifier
(1) Alpine RUX-KNOB.2 Remote Bass Level Control
(1) JL Audio CP210-W0v3 10″ 600 Watt 2 Ohm Subwoofer – #93265

Pioneer DMH-WT3800NEX 9″ Multimedia Digital Media Receiver

DMH-WT3800NEX 9″ – Android Auto™, Apple CarPlay®, Bluetooth® – Multimedia Digital Media Receiver

DMH-WT3800NEX 9-inch display has the latest connectivity solutions designed especially for today’s smartphone driven lifestyle. This receiver features a capacitive floating touchscreen display attached to a 1-DIN chassis, allowing you installation flexibility and the greatest fit and usage for your vehicle’s dash. Access Apple CarPlay or Android Auto via a wireless or wired connection, and use split screen mode to see more on-screen information. When sunlight is reflected in the vehicle, the Light and Dark modes make it easier to see the screen.

LIGHT and DARK MODE – Choose Your Style!

Introducing new Light Mode for the Pioneer NEX interface! This mode will make the receiver screen much easier to see when sunlight is being reflected in the car. The receiver will automatically switch between light/dark mode at a set time, or when your vehicles headlights turn on/off. This can also be controlled manually.

Split-Screen Mode

If you’ve ever wanted to control two apps simultaneously when using Apple CarPlay or Android Auto, get excited for Pioneer’s Split-Screen mode.

With Split-Screen mode you can simultaneously display and control both the Apple CarPlay -or Android Auto- UI and the receiver’s menu for your secondary source at the same time, on one screen. This function is useful when you want to access your music content (i.e. AM/FM Tuner or USB) while navigating through Apple CarPlay or Android Auto without having to toggle back and forth.

Pioneer’s intuitive Split-Screen mode also allows different configurations you can switch between by tapping the switch key icon. Display your current or last app in full screen, view several apps in split-screen mode, customizable widget sizes for easy viewing, or view the home screen with access to all your apps.

Split-Screen mode allows seamless operation for various functions on the same screen to personalize features and customize menu settings. The NEX in-dash receiver when interfaced with a Metra Axxess or iDataLink Maestro RR/RR2 module (sold separately) offers smart vehicle integration solutions to retain and control settings that would otherwise be lost after replacing the factory head unit, including HVAC functions, audio controls on the steering wheel, gauges, heated/cooled seats, visual parking assistance, and more, without fully exiting the Apple CarPlay UI.

Floating Display

The DMH-WT3800NEX floating display configuration allows a large display to be installed using a universal 1-DIN chassis. The floating screen offers horizontal, vertical and tilt adjustability to ensure the best fit and usability in the vehicle’s dash.

Wireless or wired, the choice is yours

The DMH-WT3800NEX supports a cable free connection between your smartphone and the receiver using Wi-Fi® wireless connectivity.

Now compatible with both Android Auto Wireless (available on Google Pixel and Nexus devices)¹ and Android Auto over USB, the DMH-WT3800NEX makes it easier than ever to connect. Android Auto¹ makes it easier to access your favorite navigation, media and communication apps on the road while minimizing distractions.

Compatibility with Apple CarPlay supports connecting to an iPhone device using either a wireless connection or a wired USB connection. Now you no longer need to worry about taking your smartphone out of your bag or your pocket before you get into your car.

Apple CarPlay

The DMH-WT3800NEX features Apple CarPlay, the smarter, safer and more fun way to use your iPhone in the car. Apple CarPlay gives iPhone users an incredibly intuitive way to make calls, use Maps, listen to music, and verbally send and listen to messages with just a word or a touch. Apple CarPlay requires iPhone 5 or newer with the latest version of iOS.

Android Auto

The DMH-WT3800NEX also features Android Auto, which extends the Android platform into the car in a way that’s purpose-built for driving. Android Auto automatically brings you useful information and organizes it into simple cards that appear just when they’re needed. It’s designed to minimize distraction so you can stay focused on the road ahead.

Android Auto is compatible with Android phones running Android 5.0 (Lollipop) or later. Android Auto may not be available on all devices.

CarAVAssist

The Pioneer DMH-WT3800NEX in-dash receiver is compatible with the CarAVAssist App, which supports home screen customization and other functions. You can bookmark websites that you want to enjoy in your car while parked, register your favorite sports teams to receive real-time game updates, make notifications settings for your smartphone, and more. The app also allows you to customize your receiver’s home screen, including adding your own background image.

Your Favorite Stations Wherever You Go, Wherever You Are

The DMH-WT3800NEX is SiriusXM- Ready® so you can get over 140 channels, including commercial-free music, plus the best sports and live events, comedy, news, exclusive talk and entertainment. SiriusXM programming is received through the SiriusXM Connect Vehicle Tuner (sold separately, SiriusXM subscription required).

Simply connect a SiriusXM SXV300 tuner to the Pioneer receiver and receive additional features like TuneMix™, SportsFlash™ and Traffic and Weather Now™. To learn more or to purchase the tuner, visit SiriusXM.

iDataLink Maestro

Keep your factory features and expand your level of in-vehicle connectivity with Pioneer NEX and iDatalink Maestro RR. When your DMH-WT3800NEX receiver is installed in a compatible vehicle using the iDatalink Maestro RR interface (sold separately), you’ll be able to enjoy the performance and features of the DMH-WT3800NEX receiver plus touchscreen control over key factory audio features.

The DMH-WT3800NEX supports factory functions via the iDatalink Maestro RR interface including: Steering Wheel Controls, Media Player (including the factory AUX-in and USB ports), Hands-Free Telephone, Voice Commands, Satellite Radio, and Secondary Display Support.

*Images will vary dependent on AV receiver and camera system

Metra Axxess

The Metra Axxess Data Interface (sold separately) allows retaining and adjustments of your personalized features and customized menu settings through the DMH-WT3800NEX receiver.

The Metra Axxess Data Interface with plug-n-play harness allows vehicle information and customized settings to be displayed on the DMH-WT3800NEX. Interfacing with the Metra Axxess offers smart vehicle integration solutions to retain and control settings that would otherwise be lost after replacing the factory head unit, including HVAC functions, audio controls on the steering wheel, gauges, and more.

Back Up Camera Input Ready*

Back Up Camera input enables you to add a rear-view camera, with the system automatically switching to a full-screen image of the rear view when the car is placed in reverse gear. The full-screen image returns to the source screen last in use when the vehicle is taken out of reverse gear.

*Rear visibility systems (backup cameras) are required under federal regulations in certain new vehicles according to a phase-in schedule that began on May 1, 2016. Owners of vehicles equipped with compliant rear visibility systems should not install or use this product in a way that alters or disables that system’s compliance with applicable regulations. If you are unsure whether your vehicle has a rear visibility system subject to these regulations, please contact the vehicle manufacturer or dealer.

Second Camera Input

The DMH-WT3800NEX has an additional input where you can add a second camera. The second camera view can be activated at any time and has many potential uses including monitoring a tow vehicle, providing a side view for better lane visibility. Downloading the latest firmware allows the camera to show inverse perspective mapping for additional installation flexibility. This feature comes in handy when positioning a second camera on another area of the vehicle for a mirror imaging perspective from left to right.

Hands-Free Calling and Audio Streaming

Stay safe and obey local hands-free laws with built-in Bluetooth (HFP). Easily pair a Bluetooth enabled phone to the DMH-WT3800NEX without having to go through complicated settings. When a registered Bluetooth device is in proximity to the receiver, the auto connection function automatically pairs the two units.

From hands-free calling, wireless audio streaming (A2DP) with artist, album, and song search*, simple pairing, and control audio (AVRCP profile), Bluetooth® wireless technology has made life in the vehicle much more convenient.

The DMH-WT3800NEX with Bluetooth also includes superior call quality reception using Wideband Speech Handsfree Profile 1.6. Wideband Speech nearly doubles the bandwidth of frequencies of a normal Bluetooth call (when compared to calls without Wideband Speech)**.

Other features include the ability to browse music libraries on smartphones wirelessly.

*Search functions vary by phone.
**Call quality depends on wireless provider’s support of HFP 1.6.

Sound Quality For All

Your car and your music are as unique as you are. With a Pioneer NEX in-dash receiver, sound quality features such as the 13-Band Graphic Equalizer with touch panel swipe settings and built-in high/low pass crossover with adjustable points and slopes provide you with the controls to tailor the listening experience to your vehicle and listening preferences.

Alpine S-A60M Class-D S-Series Mono Power Car Amplifier

Alpine S-A60M is a new S-Series amplifier, known for reliable performance and value-oriented products. The amp contains technology currently implemented in R and X-Series models. It boasts a small footprint of only 8” W x 8” H x 2.25” D. Along with Alpine’s new intelligent amplifier platform, it features an improved heat sink and protection circuit design that eliminates thermal shut-down, for dependable music playback.

Big bass power from a small package

Alpine makes it a little easier to get great bass in your vehicle, especially if you drive a compact car. Their S-Series S-A60M mono subwoofer amplifier can deliver up to 600 watts RMS to your sub, guaranteeing some powerful bass on your drive. And Alpine made this amp so small — it’s got less than an 8″ by 8″ footprint and it’s just over 2″ tall — it can fit almost anywhere. The S-Series amplifiers are designed to fit anywhere.  Measuring at 8”, these amplifiers can be mounted under seats or behind panels.  Though they sport a compact footprint on the outside, they produce impressive power on the inside. At 600 watts RMS, the S-A60M is a powerful partner to drive the versatile S-Series subwoofers.

Technology that keeps you on the air

Enhanced Shutdown Performance technology rolls back the output a bit when the amp threatens to overheat from playing at its limits too long. Instead of shutting down completely, it continues playing your music, until it cools enough to return to full power.

Convenient features

A low-pass filter and adjustable bass boost put you in command of the frequencies that reach your subs. The amp includes preamp- and speaker-level inputs, so you can install it in almost any vehicle, even one with a factory radio. If you’re using the speaker-level inputs, the amp senses an incoming signal and turns itself on, eliminating the need to run a turn-on wire back to your vehicle’s receiver or fuse box. An optional wired remote lets you control bass level from the driver’s seat.

Control Your Subwoofer

You can connect the RUX-KNOB2 remote bass knob (optional available) to the S-A60M to control the subwoofer level straight from your dash (applicable for channel 3+4 in bridged mode for subwoofer usage).

The Better Choice in Performance Value

Perfect for beginners and enthusiasts alike, the S-Series amplifiers have the technology to improve your music experience yet are still friendly on your wallet. Used in conjunction with our advanced S-Series speakers and subwoofers, they create a complete sound system that takes your in-vehicle music experience to the next

Reliable Performance

The S-Series amplifiers contain technology that was previously only available in our premium line up of amplifiers, the R- and X-Series models. The S-Series models are based on Alpine’s intelligent amplifier platform that ensures superior sound reproduction and precision imaging. With an improved heat sink, and protection circuit design that eliminates thermal shut-down, your music will keep playing no matter where your drive takes you.

Alpine RUX-KNOB.2 Remote Bass Level Control

The optional Alpine RUX-KNOB.2 remote bass control knob plugs right in to select Alpine amplifiers for quick direct subwoofer control to make bass adjustments on the fly. This handy little knob adjusts your amp’s level from its set maximum volume all the way down to virtually “off.” Since it adjusts level and not “bass boost,” you’ll maintain the same bass tone as you turn the volume up and down.

Tweak the Subwoofer Volume Driver’s Seat

The RUX-KNOB.2 remote level controller works with Alpine’s amplifiers so you can manage your bass level from the front of your vehicle. This handy little knob adjusts your amp’s level from its set maximum volume all the way down to virtually “off.” Since it adjusts level and not “bass boost,” you’ll maintain the same bass tone as you turn the volume up and down. You can control multiple amplifiers with a single remote by adding a standard phone cable splitter (not included).

From the Inside

With the RUX-KNOB.2, get full control over your Alpine amplifier, conveniently from inside the car. With the RUX-KNOB.2 installed inside the vehicle cabin, easily adjust the bass gain of your amp while seated inside.

Compatible Models

The RUX-KNOB.2 is specifically designed as the controller for use with any of the following PDX Amplifiers: MRV-M1200, Mrv-M500, MRV-M250, PWA-S10V, KTP-190U, MRX-M50, MRX-M100, MRX-V60, PDX-M12, PDX-M6, PDR-M65, PDR-V75, PDX-V9, KTA-200M, X-A70F (3 Channel Mode), X-A90V, and X-A90M.

RUX-KNOB.2 highlights:

• remote level controller for Alpine amplifiers
  • mono amps
  • sub channel of 5-channel amps
• adjusts gain from 0 to -12 dB
• multi-amp capable (standard phone cable splitter required — not included)
• 16′ connection cable

JL Audio CP210-W0v3 Subwoofer with Dual 10W0v3 Subwoofer Drivers – #93265

CP210-W0v3 Enclosed Subwoofer System with Dual 10W0v3-4 Subwoofers, Dark Gray Carpet (600 W, 2 Ω) – Ported Enclosure

This powerful slot-ported BassWedge subwoofer system delivers awesome output at an unsurpassed value. The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofers to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises. The ultra-versatile BassWedge shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle. This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.

JL quality at a great price

JL Audio built the BassWedge CP210-W0v3 enclosure to make car-rattling bass for a reasonable price, without the need for a ton of power. The enclosure’s designed to match the two 10″ subs loaded into it, so you know you’ll get every ounce of performance out of this enclosure.

An excellent combination

The CP210-W0v3 BassWedge contains two 10″ W0v3 subwoofers that handle up to 600 watts RMS, and are loaded into a specially built slot-ported enclosure. The enclosure can be placed with the woofers firing downwards, or in typical front or rear firing applications, giving you immense bass regardless of how you place it.

Solid MDF enclosure

JL Audio uses state-of-the-art automated woodworking equipment to fabricate the high-quality MDF enclosure with rugged automotive carpeting, nickel-plated push terminals, and solid internal wiring.

CP210-W0v3 Features

Overview: The JL Audio slot-ported BassWedge subwoofer enclosure is designed around two of JL Audio’s 10″ W0v3-4 (4″) subwoofers. Aggressive tuning delivers powerful bass without the need for a huge amplifier. The MDF enclosure is covered with gray carpet and has JL AUDIO logos embroidered across the top and front. The enclosure design offers a variety of installation options: forward, rear or down firing. The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer; the port mouth is flared to minimize air-flow noises.

Speaker Terminal: The enclosure uses one pair of nickel-plated, high current spring posts; the subwoofers are internally wired in parallel to the single terminal, presenting a 2″ load to the amplifier. The posts are located on the left side of the box and will accept pin connectors, single or dual banana plugs, or bare wire up to 10 gauge.

W0v3 Woofer Features:

• Dynamic Motor Analysis (DMA): DMA is JL Audio’s proprietary method of improving dynamic motor behavior. As a result of DMA optimization, the 10W0v3-4 motor displays linear force over a long excursion range, and also maintains a stable fixed magnetic field in the gap over a wide power range. The result is a reduced distortion, faithfully reproduced transients, and tight, clean, articulate bass.
• Elevated Frame Cooling: The elevated frame design of the 10W0v3-4 delivers cool air through slots directly above the top plate to the voice coil. This not only enhances power handling, but also sound quality by minimizing dynamic parameter shifts and power compression.
• Rear Gasket: The woofer has a rear gasket to provide an optimal seal when installing into the enclosure.
• Long Excursion: The subwoofer has an Xmax of 11.4mm, giving you louder bass with less distortion.

Optional Grille: The optional SGRU-10 grilles can be added to protect the woofer cones.
