Pioneer TS-A300TW A-Series .75″ Component Tweeter

Brand: Pioneer
Model Number: TS-A300TW
UPC: 884938416580
Model Number: TS-A300TW
UPC: 884938416580

Pioneer TS-A300TW A-Series .75″ Component Tweeter

  • 3/4″ polyimide hard dome tweeter
  • flush- and surface-mount hardware included
  • Inline crossovers included
  • handles up to 40 watts RMS (120 watts peak power)





Payments as low as



Availability: In stock

Product Description

Features & Specifications



Pioneer TS-A300TW A-Series .75″ Component Tweeter

Pioneer TS-A300TW A-series sound design purposely matches the subwoofer and full-range loudspeakers to provide seamless and smooth sound characteristics with dynamic, high impact bass that lets you hear and feel the music. Tweeters contributes to clearer high frequency sound reproduction—significantly outperforming OEM systems. The 450 watt max tweeters are driven by large neodymium magnets and voice coils that reproduce clear high sound.

Easy Installation

Included tweeter mounting for surface mounting, flush mounting and specially designed multi-fit adapters for mounting in original equipment (OE) tweeter locations. Integrated/in-line crossover network eliminates the need for an outboard module to increase installation flexibility.


Pioneer’s OPEN & SMOOTH sound concept provides a seamless and smooth transition between the midrange and tweeter drivers and delivers uniform off-axis frequency response optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears.

CarSoundFit App

Pioneer’s CarSoundFit app is actually a car sound simulator for experiencing in-car sound with your own smartphone. Hear the difference between original car speakers and different Pioneer audio upgrades: convince yourself of the level of quality Pioneer can offer for your vehicle. For a virtual listening demonstration of these and many other Pioneer car speakers, download the free Pioneer CarSoundFit app.

Brand Pioneer   Model Pioneer TS-A300TW
Product: Pioneer TS-A300TW A-Series .75" Component Tweeter

Speaker Size: 3/4
Design: 1-way
Tweeter Design: 3/4" Dome
Impedance (Ohms): 6
Tweeter Composition: Polyimide
Sensitivity (1W at 1 meter): 88
Frequency Response: 1400 – 69k Hz
Maximum RMS Wattage: 100
Peak Power Handling (Watts): 450
Top-mount Depth (Inches): 0 9/16
Cutout Diameter or Length (inches): 1 11/16
Mounting Height (Inches): 0.233

Speaker Design


Speaker Sensitivity

86 – 90 db

Speaker Size


RMS Power

101 to 200 Watts


6 Ω

Tweeter Size

0.75" – .99"

What's in the box

Pioneer TS-A300TW owner's manual
Two tweeters (with attached 10" speaker leads terminated with quick-connects)
Two 40" Lengths of speaker wire with in-line crossovers (each has quick slides to connect to the tweeter on one end and bare wire on the other)
2 Angled surface mount housings
2 Flush mount rings
2 Factory mount brackets
Six 1/2" Screws
2 Speed clips
2 Adhesive backed foam discs
Specs on box
