Pioneer TS-ME770FC 7.7″ 2-Way Coaxial 250w Marine Speakers with Classic Grilles – Pair

Brand: Pioneer
Model Number: TS-ME770FC
UPC: 0884938467025
Model Number: TS-ME770FC
UPC: 0884938467025

Pioneer TS-ME770FC 7.7″ 2-Way 250w Marine Speakers with Classic Grilles – Pair

  • 75 Watts Nominal Power
  • Handles up to 75 watts RMS (250 watts peak power)
  • Frequency response: 32-23,000 Hz
  • Impedance: 4 ohms
  • Sensitivity: 88 dB
Order Now - In Stock Today!





Payments as low as


Order Now - In Stock Today!

Availability: In stock

Product Description

Features & Specifications



Pioneer TS-ME770FC 7.7″ 2-Way 250w Marine Speakers with Classic Grilles – Pair

Pioneer TS-ME770FC speakers are protected from the effects of sun and water exposure, meeting both IPX7 and ASTM D4329 certification to achieve all-weather reliability.

Awesome sound and bright RGB lights

Pioneer’s TS-ME770FC marine speakers give you big, bold sound when you’re out having fun on the water. These 7.7″ speakers have super-stiff mica-reinforced polypropylene cones, durable butyl rubber surrounds, and great-sounding neodymium dome tweeters mounted directly to the grilles for optimal sound.

Built tough for boating life

Life on the water can be hard on electronics, but these speakers can stand up to just about anything. They’re IPX7-rated for water resistance and built to withstand punishing sunlight that can weaken lesser speakers. The grilles look terrific, of course, but they’re also durable enough to survive in harsh marine environments.

Add a little light

Want to bring cool-looking RGB LED lighting to your boat? Pioneer’s UD-ME770LED RGB LED Kit is designed to work with these TS-ME770FC speakers and made for marine use.

Choose the look you like

These speakers are available in two styles. There’s the sleek white Classic grille design, or you can go with Sport grilles, which come with both black and white grilles.

TS-ME770FC Features:

  • Marine-Tested: The speakers meet both IPX7 (water immersion) and ASTM D4329 (UV exposure) marine certifications.
  • Woofers: Each woofer cone is mica reinforced injection-molded polypropylene (IMPP). This process of cone molding assures a uniform cone thickness for superior linearity and clarity. Additionally, the cones are lightweight and rigid for decreased distortion and superior bass response.
  • Tweeters: The tweeters are bridge mounted to the grilles, rather than to a pole piece, thus there is no chance of water leaking through the woofer cone.
  • Optional LEDs: The optional UD-ME770LED kit (sold separately) can be added the the speakers, offering multi-color illumination to the cones.
Brand Pioneer   Model Pioneer TS-ME770FC
Product: Pioneer TS-ME770FC 7.7" 2-Way Coaxial 250w Marine Speakers with Classic Grilles - Pair

Speaker Size: 7.7
Design: 2-way
Tweeter Design: 20mm Dome
Tweeter Composition: Polyimide
Woofer Composition: Mica-Reinforced IMPP
Woofer Surround: Butyl Rubber
Sensitivity: 88 dB at 1 watt
Frequency Response: 32 – 23k Hz
Max RMS Power Handling: 75
Peak Power Handling (Watts): 250
Impedance (Ohms): 4
Top-mount Depth (Inches): 3 1/8
Cutout Diameter or Length (inches): 6 1/4

What's in the box

Pioneer TS-ME770FC owner's manual
Two 2-way speakers
2 White grilles (installed)
Twelve 1-3/8" Philips-head stainless-steel screws
12 Stainless-steel flat washers
Installation manual (English/ German/ French/ Italian/ Spanish/ Portuguese/ Russian)
Warranty information (English/ French)

Speaker Design

2-Way, Coaxial

Speaker Sensitivity

86 – 90 db

Speaker Size


RMS Power

56 to 75 Watts


4 Ω
