Pioneer TS-WX1210A 12” Sealed Enclosure Active Car Subwoofer
Brand: Pioneer
Model Number: TS-WX1210A
UPC: 884938379823
Model Number: TS-WX1210A
UPC: 884938379823
Save $102.99
$287.00
$389.99
|
OR
|
Payments as low as
$23.92/mo
Limited Quantities
Availability: In Stock
Pioneer TS-WX1210A 12” Sealed Enclosure Active Car Subwoofer
- 1,300 Watts Max Power. (350 Watts Nom.)
- Built-In 300 Watts Output Class-D Amplifier
- Variable Bass Boost (0 to +12 dB, 40Hz to 100Hz)
- Wired Remote Bass Control & Gain Control at Side Panel
Limited Quantities
Frequently Bought Together
Related Products:
-
Pioneer GM-D8604 Class FD 4-Channel Bridgeable Amplifier – Open Box
Save $40.00
$259.00
$299.00
Pioneer GM-A3702 2-Channel Bridgeable Power Car Amplifier – Open Box
Save $60.00
$79.99
$139.99
Product Description
Features & Specifications
Documents
Warranty
Pioneer TS-WX1210A 12” Sealed Enclosure Active Car Subwoofer
The Pioneer TS-WX1210A, Built with high bandwidth, high output and low distortion 300-watt Class D amplifier mated to high sensitivity woofers specifically optimized for use in small, sealed enclosures.
Flexible sound adjustment
User adjustable controls include a LPF, phase control and variable bass boost (0 to +12 dB, 40Hz to 100Hz) providing enhanced control. To expand system flexibility and user control, input gain can be adjusted using the included wired remote bass control knob or via the input gain control mounted on the enclosure side panel.
Installation Flexibility
The innovative trapezoid shape of the enclosure is designed for high rigidity and to reduce internal standing waves, while also increasing installation flexibility. Can be installed freely in the cabin or under seats and re-positioned with the subwoofer firing rear, front or upwards for optimal bass tuning. The enclosure is fully carpeted, creating a non-slip, durable and scratch resistant surface.
Product: Pioneer TS-WX1210A 12” Sealed Enclosure Active Car SubwooferSpecifications KEY FEATURES
System Type: Powered
Sensitivity (1W/1m): 114 dB
Frequency Range: 20 Hz to 125 Hz
Continuous Power handling (RMS) – Watts: 350 Watts
Maximum Peak Power Handling – Watts: 1300 Watts
Speaker Grill: Fully Covered Steel Mesh Grille
Bass Boost Frequency: 40Hz to 100Hz
Bass Boost Level: 0 to +12 dB
Built In Amp: Yes
Amp Max Power Output: 300 Watts
Amp DIN: 150 Watts
Input Level (@ Gain Max) RCA: 100mV+100mV/22kOhm
Input Level (@ Gain Max) Speaker Line: 2V+3V/5kOhm
Power Source: DS 14.4 V
Amp Max Current Consumption: 13 A
Amp Grounding: NegativeBUILD
Shape: Round
Size: 12"
Cone Material: Cellulose fiber
Center Cap Material: PP
Surround Material: Urethane
Surround Type: Rolled
Basket Material: Stamped Metal
Magnet Material: Ferrite
Magnet Weight: 33.5 oz
Voice Coil Type: Single Voice
Voice Coil Bobbin: Polyimide
Voice Coil wire: Copper
Damper: Aramid
Gasket: ABSWhat’s in the Box TS-WX1010LA Sealed Active Subwoofer
2 Mounting Brackets
8 (M5 x 25mm) screws
1 Wired Remote Bass Controller Knob
1 Power Terminal Connector
1 20A ATO fuse in holder (installed on power wire)
Installation Manual
Warranty SheetCar Subwoofer Size 12"
RMS Power 201 to 400 Watts
Includes Amplifier Yes
