Pro-Ject PJ71658588 Tube Box S2 Phono Pre-Amplifier – Black

Brand: Pro-Ject
Model Number: PJ71658588
UPC: 9120071658588
Pro-Ject
Model Number: PJ71658588
UPC: 9120071658588

Pro-Ject PJ71658588 Tube Box S2 Phono Pre-Amplifier – Black

  • Fully discreet circuit design without OpAmps
  • Front-sided Subsonic filter button
  • 2x ECC83 tubes (replaceable)
  • Front-sided Gain control
Special Order

$629.99

|

OR

|

Payments as low as

$52.50/mo

PayBright
Special Order
30 DAY RETURN POLICY
LOW PRICE GUARANTEE

Product Description

Features & Specifications

Documents

Warranty

Pro-Ject PJ71658588 Tube Box S2 Phono Pre-Amplifier – Black

The Pro-Ject PJ71658588 Tube Box S2 is our very first product to feature a fully discreet circuit design without using any operational amplifiers (OpAmps). It also is the first product to come with replaceable tubes for tube rolling and sound-shaping. This gives the customer many options to pick from and alter the sound signature to his preference. Tube Box S2 will give a full and relaxed laid back sound with lush mids, just like you would expect it from a much bigger high end tube phono pre-amplifier.

It offers support for both MM and MC cartridges. It also comes with many gain settings on the front panel. Five variable input impedance settings are available to adjust to any MM cartridge, the 47k ohm input impedance setting is fixed and suited for high output MC cartridges. The Pro-Ject PJ71658588 aluminium/metal casing is adapted to our DS2 line in looks and lastly, protects against vibrations and electromagnetic interferences for superior sound.

Subsonic Filter

The Subsonic filter helps to reduce low-frequency rumble and wasted amplifier power. The Subsonic filter button is located on the front-panel.

Gold-Plated RCA Connections

The Pro-Ject PJ71658588 Tube Box S2 includes gold-plated RCA connections and also excellent clarity on the output stage and input stage. The gold-plated RCA connectors offer corrosion-free signal transfer.

Power Requirements

The Pro-Ject Tube Box S2 tube phono preamplifier operates off of standard household current using the included external power supply. The outboard power supply helps reduce noise and interference.

MM & MC Cartridge Support

The Pro-Ject PJ71658588 Tube Box S2 offers support for both MM and MC cartridges. Also including a variety of settings for your type of turntable and catridge.

Aluminum/Metal Casing

The Pro-Ject Tube Box S2’s aluminum/metal casing looks protects against vibrations and also electromagnetic interferences for superior sound.

Brand Pro-Ject   Model Pro-Ject PJ71658588 | Pro-Ject TUBE BOX S2
Product: Pro-Ject PJ71658588 Tube Box S2 Phono Pre-Amplifier - Black
Specifications

– Tube assembly: 2x ECC83 (12AX7)
– Input impedance: 10/100/470/1k/2k ohms, fix 47k ohms
– Capacitance: 50 / 150 / 270 / 370 / 490 / 590 pF
– Gain MM / MC: 40 / 43 / 50 / 60 / 63 dB
– Signal-to-noise ratio: 77dBA
– THD+N: < 0,0025%
– RIAA curve accuracy: +/- 0,4dB/20Hz – 20kHz
– Subsonic filter: 20Hz @ 12dB/octave
– Input / Output: 1x RCA / 1x RCA

Dimensions

– Dimensions WxHxD: 103 x 73 x 119 mm

Amplifier Channels

Mono

Color

Black

Amplifier - DAC

No
