Provision 4MP Turret Camera Security Bundle x 8 – Grey

Brand: Provision
Model Number: PROVO884MPGY
UPC:
Model Number: PROVO884MPGY
UPC:

$2,158.00

|

OR

|

Payments as low as

$179.83/mo

Affirm
Special Order - Call to Inquire

Provision 4MP Turret Camera Security Bundle x 8 – Grey

This Bundle Includes:
(1) Provision-ISR H.265 Stand Alone NVR, 8CH 5MP at 25fps, MM case with PoE
(8) Provision-ISR 4MP Turret S-Sight IP Fixed 2.8mm Lens w/ 20M IR Camera – Grey
(1) WD Purple™ 2TB SATA 6 Gb/s 3.5 inch Surveillance HDD

Special Order - Call to Inquire

Product Description

Features & Specifications

Documents

Warranty

Provision 4MP Turret Camera Security Bundle x 8 – Grey

This Bundle Includes:
(1) Provision-ISR H.265 Stand Alone NVR, 8CH 5MP at 25fps, MM case with PoE
(8) Provision-ISR 4MP Turret S-Sight IP Fixed 2.8mm Lens w/ 20M IR Camera – Grey
(1) WD Purple™ 2TB SATA 6 Gb/s 3.5 inch Surveillance HDD

Provision-ISR H.265 Stand Alone NVR, 8CH 5MP at 25fps, MM case with PoE

Features

Video: Input: 8 Channel PoE / Conventional Connection (8 x RJ-45 + 1 x RJ-45 Network) Support, Output: HDMI: 1920×1080 (1080P), VGA: 1280×1024/1024×768
Bandwidth: Incoming: 40Mbps, Outgoing: 40Mbps
Decoding Support: H.265, H.264
Recording: Real-Time 8CH 5MP, FPS: 200 (PAL) / 240 (NTSC), Resolution: 2592×1944
Playback: 8 Channels Simultaneously
Analytics support: Camera Tampering, Line Crossing, Sterile Area, Object Monitoring
Audio: Input: IP Camera inputs
Alarm: Input: IP Camera inputs only, Output: IP Camera outputs only
Storage: 1 x SATA (Up to 6TB)
USB Port: total 3 – 2 x USB2.0
Network: RJ-45: 100Mbps

Provision-ISR 4MP Turret S-Sight IP Fixed 2.8mm Lens w/ 20M IR Camera – Grey

Features

1/2.7” CMOS
Resolution: 2560×1440/25FPS (4MP)
Lens: 2.8mm Fixed
True Day & Night – ICR
IR Range: 20m (1 IR LED Array)
H.265/H.264 Compression
Basic Analytic Functions
D-WDR/BLC/HLC Support
PoE
SD Card Support (Up to 128GB)
Built-in Microphone
ONVIF
IP67
Weight: 490g
Power: DC 12V/~ 350mA /PoE/ 7.5W

WD Purple™ 2TB SATA 6 Gb/s 3.5 inch Surveillance HDD

In order to better endure the intense heat changes and equipment vibrations present in NVR situations, WD Purple™ SSDs are designed exclusively for surveillance. An average desktop drive is not designed to operate in the demanding 24/7 always-on environment of a high-definition surveillance system, but rather for brief periods of time. With WD Purple, you can receive dependable storage that is suitable for surveillance applications and has been tested to work with a variety of security systems. The exclusive AllFrame™ technology reduces frame loss and enhances video playing overall.

Brand Provision   Model Provision PROVO884MPGY
Product: Provision 4MP Turret Camera Security Bundle x 8 – Grey
Provision-ISR H.265 Stand Alone NVR, 8CH 5MP at 25fps, MM case with PoE Specifications

Video
Input: 8CH RJ45 Direct Connection /Over Network
Output: HDMI /VGA (1080P, 1280×1024, 1024×768)
Decoding Format: H.265 /H.264
Decoding Capabilities: 1Ch -5MP ; 4/8Ch -D1
Analytics Camera: Tampering, Line Crossing, Sterile Area, Object Monitoring

Audio
Input: Depends on Camera Inputs
Output: Depends on Camera Outputs
Two Way Audio: No

Bandwidth
Incoming: 40Mbps
Outgoing: 40Mbps

Recording
Real-Time Recording: 8CH 5MP Real-Time
8MP: No
5MP 240FPS (NTSC)/200FPS (PAL)
4MP: 240FPS (NTSC)/200FPS (PAL)
3MP: 240FPS (NTSC)/200FPS (PAL)
2MP (1080P): 240FPS (NTSC)/200FPS (PAL)
1.3MP (960P) and lower: 240FPS (NTSC)/200FPS (PAL)
Recording Modes: Schedule, Manual, Motion, Sensor, Analytics

Playback
Playback Channels: 8CH
Search Mode: Time-Slice, Time, Event, File Management
Backup: USB 2 USB 2.0 Port
DVD burner: No
Backup Format: AVI/DAT
Remote Application: Master Stream Up to 8CH@Recording Resolution
Sub-stream: Depends on IPC
Browser: Safari (Mac OS) IE (Windows Vista/7/8/10)
CMS: Yes
Mobile Application: Provision CAM2 for iOS/Android
User Access: 10 Users Online with Professional Authority Management

Alarm
Input: Depends on Camera
Output: Depends on Camera

Storage
HDD: 1 SATA (6TB)
E-SATA: No
PTZ Connection: Via Network
Supported Controls: Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
RS-485: No

Network
Ethernet: 100 Mbps (RJ-45)
Protocols: TCP/IP, DHCP, DDNS, NTP, SMTP, P2P, RTSP
ONVIF: Yes
PoE Ports: Yes (8CH)
Interface: 10/100Mbps
Standard: IEEE802.3AF
Total Power: 120W (Average 12.5W per Channel)
Max. Power Output (Per Ch.): ~14W

Others
Power Supply: DC48V/2.5A
Power Consumption (No HDD): 5W
Dimensions: W255xD220xH45mm
Operation Temperature: 0°C ~50°C

Provision-ISR 4MP Turret S-Sight IP Fixed 2.8mm Lens w/ 20M IR Camera Specifications

Image Sensor: 1/2.7" CMOS (16:9)
Effective Pixels: 2560×1440
Electronic Shutter: 1/25s ~ 1/100000s
Frame Rate: 1-25/30FPS
Day & Night: ICR
Min. Illumination: Day: 0.1lux / Night: 0.03lux (@F2.0, AGC On) 0lux with IR on
Audio compression: G.711A/G.711U
Communication: One-way Audio
Image Settings: AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement: Digital WDR, BLC, HLC, ROI
Noise Reduction: 3D-DNR
Image Orientation: Mirror/Flip
Privacy Zone: Yes
Motion Detection: Yes
Analytics: Basic Camera Tampering, Line Crossing, Sterile Area
Video Compression: H.265 / H.264 / MJPEG (Sub-Stream Only)
Resolution: 4MP (2560×1440) / 3MP (2304×1296) / 2MP (1920×1080) / D1 / QVGA /CIF
Multi-Stream: Master Stream: 4MP (2560×1440) / 3MP (2304×1296) / 2MP (1~30fps), Sub-Stream: 1MP (1~12/15fps) /QVGA/D1/CIF (1~30fps), Third Stream: QVGA/D1/CIF (1~30fps)
Bit rate: 64Kbps ~ 5Mbps @ H.265 / 64Kbps ~ 5Mbps @ H.264
Encode Mode: VBR/CBR
Image Quality: Five levels under VBR; Free adjustment under CBR
IR Distance: 20m (1 High Power IR LED)
Lens (Field of View): 2.8mm (110°)
Iris: Fixed Iris
Lens Mount: M12 mount
Protection Rate: Water Proof: IP67
Bracket: 3-Axis Bracket
Dimensions: Φ97mm×82.6mm
Weight (gross): ~450g
Network: RJ45 (+PoE)
Power: DC Socket
Analog Video Output: No
Audio Connectivity: Built-in Microphone
SD Card: Event/Schedule based Main/Sub-Stream recording (Up to 128Gb)
Hard Reset Button: Yes
Alarm: No
Remote Monitoring: IE Browsing, CMS Software, Provision Cam2 Mobile App
User Access: Supports simultaneous monitoring for up to 4 users with multi-stream real time transmission
Network Protocol: IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS
ONVIF: Yes
Ethernet: 100Mbps
PoE: Yes
Power Supply: DC12V/~400mA / PoE/~5.2W
Work Environment: -30°~60°, 10%~90% Humidity

WD Purple™ 2TB SATA 6 Gb/s 3.5 inch Surveillance HDD Specifications

Engineered specifically for 24/7 mainstream surveillance systems
AllFrame™ technology delivers optimizations for write-intensive, low bitrate, high stream-count workloads typical to mainstream surveillance applications
Multiple Cameras, Multiple Streams
Wide Compatibility & Seamless Integration
Enhanced Workload Ratings

Color

Gray
