Rockford Fosgate M2D4-10IB 10″ Color Optix Infinite Baffle Marine Subwoofer – Black

Brand: Rockford Fosgate
Model Number: M2D4-10IB
UPC: 780687358259
Model Number: M2D4-10IB
UPC: 780687358259
Free Shipping

Save $120.00

$629.99

$749.99

|

OR

|

Payments as low as

$52.50/mo

PayBright

Availability: IN STOCK

Rockford Fosgate M2D4-10IB 10″ Color Optix Infinite Baffle Marine Subwoofer – Black

  • Injection-molded mineral-filled polypropylene cone with Santoprene rubber surround
  • Integrated Color Optix RGB LED lighting included (requires separate PMX-RGB lighting controller)
  • Power handling: 400 watts RMS/1600 watts peak
  • Sensitivity: 90.3 dB
  • Selectable impedance: 2 or 8 ohms

Product Description

Features & Specifications

Documents

Warranty

Rockford Fosgate M2D4-10IB 10″ Color Optix Infinite Baffle Marine Subwoofer – Black

The Rockford Fosgate M2D4-10IB Color Optix 10” infinite baffle subwoofer delivers loud, clear, accurate bass, and light the way for your journey! M2 provides a customized look by using either the stainless-steel grille or the white “sport” grille insert. The subwoofers connect with the Rockford Fosgate Color Optix™ Controller and RF Connect App, allowing you to customize your own color patterns. The Element Ready™ design and IPX6 certification makes them truly purpose-built for marine or motorsport applications where protection from damaging UV rays and water spray is essential. This subwoofer is optimized for Infinite Baffle installations, where an enclosure is not required.

Bring powerful bass and colorful lighting to your boat

On land or sea, a quality subwoofer is a must if you’re serious about sound. Rockford Fosgate designed their M2D4-10IB marine subwoofer to bring booming bass to your boat, along with versatile RGB LED lighting to give you looks to match their great sound.

Made for life on the water

This M2 Series Rockford Fosgate M2D4-10IB 10″ sub features a rugged, removable grille that looks great and stands up to blistering sunlight and damaging moisture. Underneath the UV-stable shell and durable Santoprene rubber surround, you’ll find a injection-molded mineral-filled polypropylene cone that’s treated with UV inhibitors, plus a moisture- and tear-resistant synthetic fiber blend spider.

Switchable impedance

The 2-position VersaSwitch™ lets you set up the sub for 2-ohm or 8-ohm impedance with a simple flip of the switch. Rockford Fosgate’s corrosion-resistant, spring-loaded push terminals and flexible, insulated silicone lead wire will stand up to the elements, whether you’re on open water or tied up at the marina. This Element Ready™ sub won’t miss a beat — and neither will you.

Light up the night

The sub also features Rockford Fosgate’s Color Optix™ RGB LED lighting system to give you bright, colorful lighting that accents your boat’s interior. The lighting can be programmed for a variety of special lighting effects via the PMX-RGB lighting controller (sold separately) and smartphone app or with their dedicated extension cables.

Maximum versatility

Powerful enough for bass-heavy music, the M2D4-10IB is a great choice for anyone who’s building a serious marine audio system and wants to make a colorful impression.

Available Wiring Diagrams

Please consult your amplifier owner’s manual for lowest recommended impedance.

  1. Rockford Fosgate M2D4-10IB
  2. Rockford Fosgate M2D4-10IB
  3. Rockford Fosgate M2D4-10IB
Brand Rockford Fosgate   Model Rockford Fosgate M2D4-10IB
Product: Rockford Fosgate M2D4-10IB 10" Color Optix Infinite Baffle Marine Subwoofer - Black
Specifications

Size: 10"
Nominal Impedance (Ohms): 2-Ohm or 8-Ohm Switchable
Power Handling (Watts RMS): 400 Watts RMS, 1600 Watts PEAK
Voice Coil Diameter: 2.0" (50.8 mm)
Voice Coil Type: Dual Voice Coil
Magnet Weight (oz): 55.02 oz. (1.56 Kg)
Frequency Response: 20 Hz – 750 Hz
Fs (Hz): 43
Re (Ohms): 6.6
Le (mH): 1.76
Sd (cm2): 363
Qms: 5.67
Qes: 1.07
Qts: 0.90
Vas: 31.5
SPL (dB @ 1w/1m): 90.3
Xmax (mm): 12.0
Woofer Displacement: 0.06 cu. ft. (1.74 Liters)
Speaker Connector: Deutsch™
Cutout Diameter: 8.87 in. (225.3 mm)
Mounting Depth: 4.44 in. (112.7 mm)
Shipping Weight: 13.8 Lbs. (6.26 Kg)

What's in the box

Rockford Fosgate M2D4-10IB owner's manual
One marine subwoofer
1 Centrex plastic grille (Black)
1 Stainless steel grille
1 Grille ring (Black)
One 11" LED power harness with 4-pin Deutsch connector on one end
Six 2-3/8" Stainless steel Allen head screws
4mm Allen head bit
4.5mm Drill bit
Instruction manual (English/ French/ Spanish/ German/ Italian)

Marine Subwoofer Features

Dual Voice Coil

Marine Subwoofer Size

10"

RMS Power

201 to 400 Watts

Impedance

2 Ω, 8 Ω

Color

Black
