Rockford Fosgate P1-2X12-BUNDLE 12″ Loaded Subwoofer Enclosure | R2-500X1 500 W Mono Amplifier | RFK4X Installation Kit

Brand: Rockford Fosgate
Model Number: P1-2X12-BUNDLE
UPC:
Model Number: P1-2X12-BUNDLE
UPC:
Free Shipping

Save $260.00

$1,369.97

$1,629.97

|

OR

|

Payments as low as

$114.16/mo

Affirm
Special Order

Availability: In Stock

Product Description

Features & Specifications

Documents

Warranty

Rockford Fosgate P1-2X12-BUNDLE 12″ Loaded Subwoofer Enclosure | R2-500X1 500 W Mono Amplifier | RFK4X Installation Kit

This Bundle Includes:

(1) Rockford Fosgate P1-2X12 Punch Dual P1 12″ Loaded Subwoofer Enclosure
(1) Rockford Fosgate R2-500X1 Prime 500 Watt Mono Subwoofer Amplifier
(1) Rockford Fosgate RFK4X 4 AWG Complete Amplifier Installation Kit


Rockford Fosgate P1-2X12 Punch Dual P1 12″ Loaded Subwoofer Enclosure

The P1-2X12 is a dual P1 12” vented enclosure with 500 Watts RMS power handling wired to a 2-Ohm load. The enclosure is constructed with 5/8” MDF, covered in high density carpet, and features quick release compression terminals.

Dropping in a Punch Loaded enclosure is the most convenient way to get low frequency bass into your system. We’re not talking about junk in the trunk; these are genuine Punch woofers that can be purchased separately. Punch Loaded enclosures are made of 5/8″ MDF and fine-tuned using computer-aided design software. P1 Loaded Enclosures have similar tonal performance to P2/P3 models, but are lighter and easier to move in and out of vehicles.

The P1-2X12 ported enclosure from Rockford Fosgate fills your vehicle with juicy, high-volume bass, allowing you and your passengers to jam out to the latest beats. Two Punch P1 12″ woofers with paper cones reinforced with Kevlar fibres and rubber surrounds are housed in the enclosure. Each of these subs can handle up to 250 watts RMS without flinching thanks to heavy-duty motor assemblies and advanced cooling vents.

This enclosure’s rugged 5/8″ medium-density fiberboard construction ensures that it can withstand the weight of fat, heavy bass. Industrial-grade black carpet gives your trunk a polished appearance and protects it from nicks and scratches. This enclosure features an advanced port design that allows for more air movement while reducing port noise, resulting in louder, deeper bass. Feel the thick low end this enclosure adds to your ride by adding an amp and some wiring.

CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

P1-2X12 Features:

  • Constructed with 5/8″ MDF
  • Proprietary high-flow, low-noise port
  • High current binding posts

Rockford Fosgate R2-500X1 Prime 500 Watt Mono Subwoofer Amplifier

The Rockford Fosgate R2-500X1 Prime Series amplifier can power your subwoofer with up to 500 watts RMS. You can adjust the low-pass filter, infrasonic filter, and Rockford Fosgate’s famous Punch boost to get the best possible bass from the sub and enclosure in your vehicle. Perfect for subwoofers, a variable infrasonic filter and remote level control allows you to tune the bass for the desired level for the music.

Setting it up for optimum performance

Rockford Fosgate’s C.L.E.A.N. technology (Calibrated Level Eliminates Audible Noise) setup system ensures your bass will sound as clean and powerful as possible. It’s a simple system to use — turn it up until the light shows red, then turn it down until the red light goes out. Speaker-level inputs let you hook this amp up to almost any system, even a factory stereo.

Give your sub the power it deserves

The Rockford Fosgate R2-500X1 is developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. These 3rd generation of Prime Series amplifiers are refined with the latest Rockford Fosgate technology for easy setup and configuration, making them perfect for use with factory audio or custom aftermarket systems.

Available Wiring Diagrams

Please consult your amplifier owner’s manual for lowest recommended impedance.


Rockford Fosgate RFK4X 4 AWG Complete Amplifier Installation Kit

4 gauge complete power, ground and signal installation kit for a 2-channel amplifier.

Kit includes 17 feet of 4 AWG power wire, 3 feet of 4 AWG ground wire, 30 feet of 16 AWG speaker wire, (1) 16 feet twisted pair RCA, Maxi fuse holder and fuse, 20 feet of remote wire, 100 Amp fuse.

RFK4X Features:

  • FULL spec cable – meets or exceeds AWG (American Wire Gauge) requirements
  • Includes appropriate wire termination hardware
  • 16 AWG (1.31mm²) 65 strands
  • 4 AWG (21.1mm²) 1,862 strands
  • 100% Pure Crystal-Oxygen Free Copper (PC-OFC)

CEA-2015

Rockford Fosgate cables conform to the CEA-2015 industry standard. The standard specifies the exact amount of copper needed to indicate a specific wire diameter or gauge size (8 AWG, 4 AWG, etc). Some manufacturers substitute thicker insulation for copper. With Rockford Fosgate, you get exactly what you pay for.

Includes Power Wire

This amplifier kit includes power wire by including necessary cable for both B(+) and GND(-) connections. Additionally, amplifier kits include remote turn-on power wire. All cables in this kit conform to the CEA-2015 AWG specification.

Includes RCA Cables

This amplifier kit includes RCA patch cables. These are the necessary cables used to transfer low-level signal from the source unit to the amplifier, typically located in the rear of the vehicle.

Includes Speaker Wire

This amplifier kit includes speaker wire. These cables connect the amplifier to the speakers. All wires in this kit conform to the CEA-2015 AWG specification.

Includes Fused Dist.

This amplifier kit includes fused distribution. It utilizes a stand-alone fuse holder that can be installed in a convenient place under the hood.

Brand Rockford Fosgate   Model Rockford Fosgate P1-2X12-BUNDLE
Product: Rockford Fosgate P1-2X12-BUNDLE 12″ Loaded Subwoofer Enclosure | R2-500X1 500 W Mono Amplifier | RFK4X Installation Kit
P1-2X12 Subwoofer

Woofer Size (inches): 12
Speakers Per Box: 2
Woofer Material: Kevlar/Paper
Speaker Connector: Up to 10 AWG compression terminals
Enclosure Type: Vented/Ported
Enclosure Materia: l5/8" MDF (Medium Density Fiberboard)
Color: Black
Pieces in System: 1
Width (inches): 33-7/8
Height (inches): 15-3/8
Depth (inches): 16-5/8
Connector Type: Spring post
Frequency Response: 25-250 Hz
Power Range (Watts RMS): 500
Maximum Wattage: 1000
Sensitivity: 86 dB
Impedance: 2 ohms

R2-500X1 Amplifier

RMS Power Output (Watts x Channels): 300 x 1
Power at 2 Ohms (Watts x Channels): 500 x 1
Minimum Impedance Unbridged: 2
Minimum Impedance: 2
Best Frequency Response: 20-250 Hz
THD at Rated RMS Power: 1%
Signal to Noise Ratio: 75 dB
Input Voltage: 14.4v
Amplifier Class: D
Low-Pass Crossover Frequency: 50-250 Hz
Low-Pass Slope (dB/octave): 12 dB/octave
Bass Boost: 0-18 dB
Bass Boost Frequency: 45 Hz
Fan Cooled: No
Fuse Rating: 80
Speaker Level Inputs: Yes
Preamp Outputs: 2
Width (inches): 8-1/2
Height (inches): 2
Depth (inches): 7-3/4

RFK4X Installation Kit

Battery PWR/GND Gauge: 4 AWG
Amplifier PWR/GND Gauge: 4 AWG
Fuse Type: MAXI
Speaker Wire Gauge: 16 AWG
Fuse Size: 100 Amp
Dual Amp Installation Kit: No

Car Subwoofer Size

12"

Enclosure Type

Ported

RMS Power

401 to 800 Watts

Impedance

2 Ω

Mobile Amplifier Channels

1 Channel (Mono)

Mobile Amplifier Class

Class D

Mobile Amplifier Features

Bass Boost, Low-Pass Filter, Pre Amp Outputs, Speaker Level Inputs

Mobile Amplifier Fuse Rating

80

Mobile Amplifier RMS

351 to 750 watts

Mobile Min Impedance

2
