Rockford Fosgate P3S-1X10-BUNDLE 10″ Shallow Loaded Enclosure | PBR300X1 Mono Amplifier | RFK8I Installation Kit

Brand: Rockford Fosgate
Model Number: P3S-1X10-BUNDLE
UPC:
Model Number: P3S-1X10-BUNDLE
UPC:
Free Shipping

Save $180.00

$959.97

$1,139.97

|

OR

|

Payments as low as

$80.00/mo

PayBright

Availability: In stock

Product Description

Features & Specifications

Documents

Warranty

Rockford Fosgate P3S-1X10-BUNDLE 10″ Shallow Loaded Enclosure | PBR300X1 Mono Amplifier | RFK8I Installation Kit

This Bundle Includes:

(1) Rockford Fosgate P3S-1X10 10″ Shallow Loaded Subwoofer Enclosure
(1) Rockford Fosgate PBR300X1 Punch 300 Watt Compact Mono Subwoofer Amplifier
(1) Rockford Fosgate RFK8I 8 AWG Power & Signal Amplifier Installation Kit


Rockford Fosgate P3S-1X10 10″ Shallow Loaded Subwoofer Enclosure

The Rockford Fosgate P3S-1X10 is a single 10” Punch Shallow subwoofer. Rated at 300 Watts RMS and loaded in a sealed enclosure. This subwoofer enclosure is internally wired to a 1-Ohm load. Features 5/8” MDF and 10 AWG quick-release input terminals.

Nothing fits behind your truck seat? Rockford Fosgate has the solution to your problem with the Punch P3S-1X10 shallow 10” loaded enclosure. This loaded enclosure may look small, but it plays loud, and thanks to its 300 Watt RMS power handing and 1-Ohm load wired impedance, you can actually use an amplifier with some balls. Features a sealed slim-line wedge design for optimum mechanical power handling, durable carpet with stitched Diamond-R logo and quick-release input terminals.

P3S-1X10 Features:

  • Sealed truck box style enclosure
  • 10 AWG input terminals
  • 1-Ohm wired impedance
  • Constructed with 5/8″ MDF
  • Computer optimized design
  • Covered with high density carpet
  • Wired exclusively with Rockford Fosgate speaker cable
  • Included trim ring ready to accept optional stamped mesh grille insert

Rockford Fosgate PBR300X1 Punch 300 Watt Compact Mono Subwoofer Amplifier

The Punch Rockford Fosgate PBR300X1 is a 300 Watt mono amplifier designed for compact subwoofer systems. This efficient amp packs a Punch in motorcycles, ATVs and hybrid-electric vehicles without sucking a lot of juice from your electrical system.

The Rockford Fosgate PBR300X1 is a mono amplifier designed for a subwoofer system that requires little space. The BRT (Boosted Rail Technology) is an ultra efficient design that doesn’t even use a switching power supply to generate its 300 Watts of power! The BRT also has a variable hi-level DC offset turn-on circuit for easy installation into any OEM system. Great for motorcycles and recreational vehicles.

You won’t believe how small and powerful this amp is. The Rockford Fosgate PBR300X1 mono amp can drive up to 300 watts RMS into a one-ohm load, allowing you to power multiple subs to get more bass. And this Punch Class BR amplifier generates this power from a very tiny case — literally the size of your hand. Boosted Rail (BR) amp technology uses capacitors and high-speed circuitry to boost the amp’s power supply voltage, when needed, so it can handle massive musical peaks without missing a beat. Rockford Fosgate uses this new technology to create a remarkable amp that fits almost anywhere and delivers powerful sound.

PBR300X1 Features:

  • MOSFET output stage
  • High level inputs
  • Ultra compact chassis
  • 12dB/octave Butterworth crossover
  • Variable 4-6 volt hi level DC offset voltage input turn-on control

Available Wiring Diagrams

Please consult your amplifier owner’s manual for lowest recommended impedance.


Rockford Fosgate RFK8I 8 AWG Power & Signal Amplifier Installation Kit

8 gauge power, ground and signal installation kit for an amplifier.

Kit includes 17 feet of 8 AWG power wire, 3 feet of 8 AWG ground wire, (1) 16 feet twisted pair RCA, AGU fuse holder and fuse, 20 feet of remote wire, 40 Amp fuse.

RFK8I Features:

  • FULL spec cable – meets or exceeds AWG (American Wire Gauge) requirements
  • 8 AWG (8.36mm²) 735 strands
  • Includes appropriate wire termination hardware
  • 100% Pure Crystal-Oxygen Free Copper (PC-OFC)

CEA-2015

Rockford Fosgate cables conform to the CEA-2015 industry standard. The standard specifies the exact amount of copper needed to indicate a specific wire diameter or gauge size (8 AWG, 4 AWG, etc). Some manufacturers substitute thicker insulation for copper. With Rockford Fosgate, you get exactly what you pay for.

Includes RCA Cables

This amplifier kit includes RCA patch cables. These are the necessary cables used to transfer low-level signal from the source unit to the amplifier, typically located in the rear of the vehicle.

Includes Fused Dist.

This amplifier kit includes fused distribution. It utilizes a stand-alone fuse holder that can be installed in a convenient place under the hood.

Includes Power Wire

This amplifier kit includes power wire by including necessary cable for both B(+) and GND(-) connections. Additionally, amplifier kits include remote turn-on power wire. All cables in this kit conform to the CEA-2015 AWG specification.

Brand Rockford Fosgate   Model Rockford Fosgate P3S-1X10-BUNDLE
Product: Rockford Fosgate P3S-1X10-BUNDLE 10″ Shallow Loaded Enclosure | PBR300X1 Mono Amplifier | RFK8I Installation Kit
P3S-1X10 Subwoofer

Woofer Size (inches): 10
Speakers Per Box: 1
Woofer Material: Anodized Aluminum
Enclosure Type: Sealed
Color: Black
Pieces in System: 1
Width (inches): 19-1/8
Height (inches): 13-5/8
Depth (inches): 6-1/4
Connector Type: Spring posts
Frequency Response: 40-250 Hz
Power Range (Watts RMS): 300
Maximum Wattage: 600
Sensitivity: 83 dB
Impedance: 1 ohms

PBR300X1 Amplifier

RMS Power Output (Watts x Channels): 75 x 1
Peak Power Output (Watts x Channels): 300 x 1
Power at 2 Ohms (Watts x Channels): 150 x 1
Minimum Impedance Unbridged: 1
Minimum Impedance: 1
Best Frequency Response: 20-250 Hz
THD at Rated RMS Power: 0.2%
Signal to Noise Ratio: 85 dB
Input Voltage: 14.4v
Amplifier Class: BR
Low-Pass Crossover Frequency: 35-250 Hz
Low-Pass Slope (dB/octave): 12 dB/oct
Bass Boost: Optional (0-18 dB)
Bass Boost Frequency: 45 Hz
Fan Cooled: No
Fuse Rating: 30
Preamp Outputs: No
Width (inches): 6-15/16
Height (inches): 1-9/16
Depth (inches): 4-5/16

RFK8I Installation Kit

Fuse Type: AGU
Battery PWR/GND Gauge: 8 AWG
Amplifier PWR/GND Gauge: 8 AWG
Fuse Size: 60 Amp
Dual Amp Installation Kit: No

Car Subwoofer Features

Shallow Mount

Car Subwoofer Size

10"

RMS Power

201 to 400 Watts

Impedance

1 Ω

UTV Amplifier

Yes

Mobile Amplifier Channels

1 Channel (Mono)

Mobile Amplifier Class

Class BR

Mobile Amplifier Features

Bass Boost, Low-Pass Filter, Pre Amp Outputs

Mobile Amplifier Fuse Rating

30

Mobile Amplifier RMS

201 to 350 watts

Mobile Min Impedance

1
