SVS Prime Tower Floor Standing Speakers – Pair – Black Ash

Brand: SVS
Model Number: 331230
UPC:
Model Number: 331230
UPC:
Free Shipping

Save $570.00

$1,890.00

$2,460.00

|

OR

|

Payments as low as

$157.50/mo

Affirm
Ships direct from manufacturer, shipping times can vary

Availability: In Stock

SVS Prime Tower Floor Standing Speakers – Pair – Black Ash

  • 1” aluminum dome tweeter
  • 4.5” midrange driver
  • Dual 6.5” woofers
  • Black Ash and Piano Gloss Black finish options
  • 5-way binding posts
  • Dual 1.7” wide- flared rear-firing ports
Ships direct from manufacturer, shipping times can vary

Product Description

Features & Specifications

Documents

Warranty

SVS Prime Tower Floor Standing Speakers – Pair – Black Ash

Prime Tower: Airy, unveiled highs with crisp dynamics and convincing bass, the Prime Tower speaker brings high-end audio to more people than ever. Unique SoundMatch 3.5-Way Crossover is optimized for largest sweet spot possible with pinpoint imaging.

Overview:

The Prime Tower speakers set the bar for sound quality and high-end appeal among tower speakers anywhere near the price. The reference-grade SVS floorstanding speaker is amazingly transparent, with a broad, stable soundstage and sharp imaging of voices and instruments, all punctuated by deep yet accurate low frequency extension.

Challenge the SVS Prime Tower Speakers with any dynamically charged music or movie soundtrack and it reveals new layers of sound and detail you never knew existed. With engineering and design cues taken from the acclaimed SVS Ultra Series speakers, the Prime Tower is a sonic achievement that stands up to the best speakers in the world.

The SVS Prime Tower Floor Standing Speakers in Black Ash offer an impressive combination of quality and style. These speakers boast a 1” aluminum dome tweeter, a 4.5” midrange driver, and dual 6.5” woofers that deliver a powerful and immersive audio experience. They come in both Black Ash and Piano Gloss Black finish options to suit any home décor. The 5-way binding posts ensure secure and versatile connection options. The dual 1.7” wide-flared rear-firing ports offer improved bass response and minimize port noise. The speakers are covered with a cloth grille with a pin/cup retention system that adds a touch of elegance to the overall design. The elastomer screw-in feet are adjustable for level, and the spiked metal screw-in feet are included for additional stability. The cabinet dimensions of 36” (H) X 8” (W) X 10.8” (D) (includes grille, feet, and binding posts) and weight of 40.1 pounds make these speakers substantial and impressive.

Every aspect of the Prime Tower speakers was designed for sonic excellence. From the premium grade drivers and sophisticated SoundMatch crossover to the extra-thick baffle, internal bracing, and FEA optimized tweeter diffuser, the Prime Tower speaker’s design and engineering credentials place it among the best $1,000 tower speakers available.

Prime Driver & Tweeter Design

The 4.5-inch midrange driver of the Prime Tower speaker is thoughtfully designed for acoustic excellence. It is mounted in its own compartment, which is completely sealed to ensure a precise, smooth and clear midrange without any coloration. The cone material is both light and rigid, providing a flat frequency response and excellent handling of the foundational mid-range frequencies.

For a deep and articulate bass, the Prime Tower speaker features dual 6.5-inch woofers that effortlessly set the mood and punctuate the low-end impact of instruments, basslines and movie sound effects. Each woofer has a separate internal compartment in the cabinet with a custom port tuning frequency, resulting in powerful and accurate bass that can be both heard and felt.

The 1-inch aluminum dome tweeter of the Prime Tower speaker is also exceptional. It is light, efficient, and rigid, playing crystal clear at high volumes. The tweeter’s clarity offers a sense of utter transparency, creating an ‘airy’ presentation with incredibly unveiled highs, making female vocals and dialogue sound crisp and smooth.

Innovative SoundMatch Crossover Design

To match the premium drivers of the SVS speaker, an equally capable crossover is essential. The SVS SoundMatch 3.5-way crossover was innovatively designed to meet this requirement, without any compromise on cost. The tapered array of the crossover ensures that each woofer has its own dedicated crossover, minimizing the potential for beaming. This design creates an expansive, yet focused and precise soundstage, with accurate frequency response at all listening positions in the room.

The SoundMatch Crossover of the SVS speaker is precisely tuned, ensuring pinpoint accuracy from sparkling highs down to palpable lows. The crossover maintains the pristine signal purity, providing an exceptional listening experience.

Performance Driven Cabinet Design and Geometry

Chamfers, the tapered edges on the front baffle of the Prime Tower speaker, minimize edge diffraction, resulting in clear and precise soundstaging. The cabinet has a substantial presence without visually overpowering the room. It offers a modern industrial feel with added acoustic enhancements such as shorting rings and a tweeter diffuser. All of these advancements are integrated into a sleek but commanding floor standing speaker cabinet that is available in a stunning piano gloss black or premium black ash finish.

Brand SVS   Model SVS 331230
Product: SVS Prime Tower Floor Standing Speakers - Pair - Black Ash
Frequency Response / Acoustic Data

Rated bandwidth: 30 Hz-25 kHz (±3 dB)
Nominal impedance: 8 ohms.
Sensitivity: 87 dB (2.83V @ 1 meter full-space, 300-3kHz)
Recommended amplifier power: 20-250 watts.

Speaker Specs

Floor Standing Tower Loudspeaker
Black ash and piano gloss black finish options
Single set of 5-way binding posts
Dual 1.7” wide-flared rear-firing ports
Cloth grille with pin/cup retention system
Elastomer stick-on bumper feet (adds 3mm to height)
Spiked metal screw-in feet included – adjustable for level
Cabinet Dimensions: 36" (H) X 8" (W) X 11.1" (D)
Overall Dimensions: 36.6" (H) X 8" (W) X 11.6" (D) (includes grille and feet)
Shipped Dimensions: 41.3" (H) X 14.1" (W) X 17.3" (D)
Weight: 40.1 pounds
Shipped Weight: 46.3 pounds

Driver Specs

1” Aluminum Dome Tweeter:
FEA-optimized diffuser for airy and unveiled presentation
Aluminum dome for exceptional transient response

4.5” Midrange Driver:
Polypropylene cone for excellent stiffness/mass ratio and pistonic behavior
Aluminum shorting ring to reduce gap inductance, lower distortion, and enhance high frequency response
Cast ABS-fiberglass composite basket ensures precision component alignment and excellent thermal transfer
Vented voice coil former minimizes air compression artifacts

Dual 6.5” Woofers:
Long stroke motor and suspension for high output
Polypropylene cone for excellent stiffness/mass ratio and pistonic behavior
Aluminum shorting ring to reduce gap inductance, lower distortion, and enhance high frequency response
Cast ABS-fiberglass composite basket ensures precision component alignment and excellent thermal transfer
Vented voice coil former minimizes air compression artifacts

Crossover & Cabinet Specs

Crossover:
3.5-way crossover with premium-grade capacitors, air-core inductors and heavy-trace printed circuit boards.
Tapered woofer array optimizes the transition to the midrange driver and reduces vertical axis lobing
Midrange-to-tweeter crossover: 2.1 kHz (12 dB/octave slopes)
Top woofer (Combined Woofer) to midrange crossover frequency: 350 Hz (12 dB/octave slopes).
Bottom woofer low pass frequency: 165 Hz (customized filter Q and slope)

Cabinet:
Separate sealed midrange enclosure shifts standing waves beyond the driver pass band, improving sound quality
Separate woofer enclosures with optimized port tuning frequencies for smooth and accurate bass response
Acoustically transparent and FEA optimized grilles minimize diffraction
Chamfered front baffle and flush-mounted drivers reduce edge diffraction and improved on-axis high frequency response
FEA-optimized cabinet and bracing eliminates resonances

Speaker Sensitivity

86 – 90 db

RMS Power

201 to 400 Watts

Impedance

8 Ω

Number of Speakers

2 Speakers

# of Woofers

2

Color

Black Ash
