TOA F-1300BT 5″ Wide-Dispersion Speaker System

The F-1300 Series Speakers are two-way compact speakers with great efficiency, wide range, and high power handling capacity. These speaker systems can be set up in a way that is appropriate for the location and application.

Specifications

-Enclosure: Bass-reflex type
-Rated Input: 30 W (high impedance)
-Power Handling Capacity:  Continuous pink noise: 50 W (low impedance), Continuous program: 150 W (low impedance)
-Rated Impedance: 8 Ω, 100 V line: 330 Ω (30 W), 1 kΩ (10 W), 3.3 kΩ (3 W), 10 kΩ (1 W), 70 V line: 170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
-Sensitivity: 90 dB (1 W, 1 m) at installation in 1/2 free sound field
-Frequency Response: 80 Hz – 20 kHz, -10 dB at installation in 1/2 free sound field
-Crossover Frequency: 2 kHz
-Directivity Angle: Horizontal: 110゜, Vertical: 100゜
-Speaker Component Low frequency: 13 cm (5″) cone-type, High frequency: 25 mm (1″) dome tweeter
-Input Terminal: Push-in terminal
-Finish: Enclosure: HIPS, black, Punched net: Surface-treated steel plate, black, paint, Joint bracket, wall bracket: Steel plate, t1.6, black, paint, Speaker bracket: Die-cast aluminum, black, paint
-Dimensions: 162 (W) × 250 (H) × 161 (D) mm (6.38″ × 9.84″ × 6.34″)
-Weight: 3.6 kg (7.94 lb) (including the supplied brackets)
-Accessory Speaker bracket…1, Joint bracket…1, Wall bracket…1, Bracket fixing screw…1 set
-Option Board hanger bracket: HY-BH10B, Ceiling mount bracket: HY-CM10B (used for the horizontal speaker mounting), Cluster bracket: HY-CL10B, Speaker stand: ST-16A
