Mechanical
– Dimensions: 139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01")
– Weight: 210 g (7.41 oz)

Hardware
– Networking Interface: (5) 10/100/1000 Ethernet Ports
– Button: Reset
– Power Method: PoE/PoE+
– Supported Voltage Range: 44 to 57VDC
– Power Supply: UniFi Switch (PoE)
– PoE Out: 48V Passthrough (Pins +1, 2; -3, 6)
– Maximum Power Consumption With PoE Passthrough: 11W, 23W (Requires PoE+ switch)
– Max. TX Power: 2.4 GHz (23 dBm), 5 GHz (26 dBm)
– Dual-Band Antennas: 2.4 GHz (1.8 dBi Each), 5 GHz (3.4 dBi Each), (2) Single-Port, Single-Polarity Dual-Band Antennas
– Single-Band Antennas: 5 GHz (6 dBi Each), (2) Single-Port, Dual-Polarity, Single-Band Antennas
– Mounting: 1-Gang Electrical Wall Box (Not Included)
– Operating Temperature: -10 to 60° C (14 to 140° F)
– Operating Humidity: 5 to 95% Noncondensing
– Certifications: CE, FCC, IC

Software
– WiFi Standards: 802.11 a/b/g/n/r/k/v/ac/ac-wave2
– Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF
– BSSID: Up to 8 per Radio
– VLAN: 802.1Q
– Advanced QoS: Per-User Rate Limiting
– Guest Traffic Isolation: Supported
– Power Save: Supported
– Beamforming: Supported
– WMM: Voice, Video, Best Effort, and Background
– Concurrent Clients: 200+

Supported Data Rates (Mbps)
– 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
– 802.11b: 1, 2, 5.5, 11 Mbps
– 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
– 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
– 802.11ac: 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80), 58 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 160)
