Specifications
Amplifier
– Channels: 5.2
Power Output per Channel
– 50 W @ 8 Ohms, 20 Hz to 20 kHz, 0.08% THD, 2 Channels Driven
– 60 @ 6 Ohms, 1 kHz, 0.7% THD, 2 Channels Driven
– 100 W @ 6 Ohms, 1 kHz, 10% THD, 1 Channel Driven
– Audio Formats Supported: Dolby TrueHD, DTS-HD Master Audio
Video
– HDCP Compliance: 2.3
Connectivity
– Wi-Fi: Dual-Band 2.4 / 5 GHz Wi-Fi 4 (IEEE 802.11a/b/g/n)
– Bluetooth: Version 4.1 Class 1 (2.4 GHz)
– AirPlay: Yes, AirPlay 2
– Audio Return Channel (ARC): Yes, eARC
Inputs
– 6 x HDMI (1 Front)
– 3 x RCA Composite Video
– 4 x Stereo RCA Audio (1 Phono MM with Ground Screw)
– 1 x Optical TOSLINK
– 1 x Digital Coaxial
Outputs
– 1 x HDMI
– 1 x Composite Video
– 1 x Stereo RCA Pre-Out
– 2 x RCA Subwoofer Pre-Out
– 1 x 1/4″ / 6.35 mm Headphone Out
– Speaker Connectors: 5 x Binding Post Pairs
Other Ports
– 1 x USB (Front)
– 2 x Bluetooth / Wi-Fi Antennas
– 1 x RJ45 Ethernet LAN
– 1 x AM Antenna
– 1 x FM Antenna
– 1 x 1/8″ / 3.5 mm IR In
– 1 x RCA Remote In
– 1 x RCA Remote Out
– 1 x 1/8″ / 3.5 mm Setup Mic
Tuner
– Tuner Type: AM/FM
– Sensitivity: AM, Effective: 18 μV
– Signal to Noise Ratio: FM, Mono: 70 dB (IHF-A Weighted, Direct Mode)
– Distortion: FM, Mono: 0.7% (1 kHz)
– Power Requirements: 120 VAC, 60 Hz
– Power Consumption (Active): 180 W
– Power Consumption (Standby): 0.2 W
– CEC Standby Mode: 0.5 W
Receivers - Channels
5.2
Receivers - Watts Per Channel
76 to 100w
Receivers - Features
AirPlay, Alexa Ready, Audio Return Channel (ARC), Bluetooth, Dolby TrueHD, Dolby Vision, DTS HD Master, Google Assistant, HEOS, HDR, Internet Radio, SiriusXM, Spotify, Wi-Fi
HDMI Inputs
6
HDMI Outputs
1
Receivers - Multi Room Zones
1
