TOA BG-2060 CU D00 5-Input Mixer/Amplifier (BG2060 CU D00)

Product Description

TOA BG-2060 CU D00 5-Input Mixer/Amplifier

The BG-2060 is a 60 W 5-input mixing amplifier for general announcements and background music. It is designed for use in pubs, retail businesses, and banquet spaces, and includes the MOH OUT feature, which allows for 2-channel broadcasting when used with the optional booster amplifier BA-235 (35 W) or BA-260 (60 W).

Specifications

-Power Source: 120 V AC, 60 Hz -Rated Output: 60 W -Power Consumption: 163 W (rated output), 80 W (based on cULus standards) -Frequency Response: 50 Hz - 20 kHz -Total Harmonic Distortion: 0.5 % or less, at 1 kHz, rated output -Input: Mic: -60 dB*, 600 ?, electronically balanced, removable terminal block, Line 1: -10 dB*/ TEL: -20 dB*, Line 1/TEL selectable, 10 k?, electronically balanced, removable terminal block, Line 2, 3: -10 dB*, 10 k?, unbalanced, removable terminal block and, RCA jacks, Module -Output: Speaker: 4 ?, 25 V (10 ?), 70 V (83 ?), balanced, removable terminal block, MOH: 0 dB*, 600 ?, balanced, removable terminal block, Line: 0 dB*, 600 ?, unbalanced, removable terminal block -Output Regulation: 2 dB or less, no load to full load (1 kHz) -Phantom Power: On/Off switch for Mic, +24 V DC -S/N Ratio: Mic: 60 dB or more, Line 1/TEL, Line 2, 3, Module: 75 dB or more, (Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered) -Muting: Manual mute/Automatic mute -Tone Control: Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz

Features & Specs

-Power Source: 120 V AC, 60 Hz
-Rated Output: 60 W
-Power Consumption: 163 W (rated output), 80 W (based on cULus standards)
-Frequency Response: 50 Hz - 20 kHz
-Total Harmonic Distortion: 0.5 % or less, at 1 kHz, rated output
-Input: Mic: -60 dB*, 600 Ω, electronically balanced, removable terminal block, Line 1: -10 dB*/ TEL: -20 dB*, Line 1/TEL selectable, 10 kΩ, electronically balanced, removable terminal block, Line 2, 3: -10 dB*, 10 kΩ, unbalanced, removable terminal block and, RCA jacks, Module
-Output: Speaker: 4 Ω, 25 V (10 Ω), 70 V (83 Ω), balanced, removable terminal block, MOH: 0 dB*, 600 Ω, balanced, removable terminal block, Line: 0 dB*, 600 Ω, unbalanced, removable terminal block
-Output Regulation: 2 dB or less, no load to full load (1 kHz)
-Phantom Power: On/Off switch for Mic, +24 V DC
-S/N Ratio: Mic: 60 dB or more, Line 1/TEL, Line 2, 3, Module: 75 dB or more, (Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered)
-Muting: Manual mute/Automatic mute
-Tone Control: Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz
-Control: Mic gain control, Line 1/TEL gain control, Line 2 gain control, Line 3 gain control,, Module gain control, Bass tone control, Treble tone control, MOH out gain control, Mute control (Manual mute), Remote volume control, Mute sense control, Line 1/TEL selector switch, Phantom power switch (Mic), Auto mute switch (Mic, Line 1/TEL, Module), Mute receive switch (Mic, Line 1/TEL, Line 2, 3, Module), MOH assign switch (Mic, Line 1/TEL, Line 2, 3, Module), Power ON/OFF switch
-Indicator: Power LED, Signal level LED, Peak LED
-Operating temperature: 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
Operating Humidity: 35 % to 80 %RH (no condensation)
-Finish: Panel: ABS resin, black, Case: Steel plate, black, paint
-Dimensions: 264 (W) × 94.3 (H) × 267.3 (D) mm (10.39" × 3.71" × 10.52")
-Weight: 5.3 kg (11.68 lb)
-Accessory: Volume control cover: YA-920 ……5, Removable teminal plug (2 pins) ……4, Removable teminal plug (3 pins) ……2, Removable teminal plug (4 pins) ……1, Removable teminal plug (5 pins) … 1
-Option: Rack mounting bracket: MB-1000

Documents

Warranty

TOA Canada 5 Year Limited Manufacturers Warranty
SKU: BG-2060 CU D00 UPC: 59497218805
$941.73
or

Payment as low as

$78.47/mo
Info icon

This monthly payment does not include any applicable tax or interest

Flash Sale Ends:

Covers shipping up to 7% of product value. If costs exceed this, we'll quote before shipping or cancel and refund. Free ShippingFree Shipping |

We guarantee the best price in Canada—before or 30 days after purchase.* Lowest Price GuaranteeLowest Price Guarantee*

Special Order

-Power Source: 120 V AC, 60 Hz
-Rated Output: 60 W
-Power Consumption: 163 W (rated output), 80 W (based on cULus standards)

Sign up to get notified when it's in stock!

Remember to select the correct model if there are multiple options.

Call for Expert Help

*Quantities may be limited. First come first served. Gibbys Electronic Supermarket does not guarantee a notification when the product is in stock. By signing up, you agree to subscribe to our newsletters, receive marketing emails or be contacted by Gibbys Electronic Supermarket. You also agree to Gibbys' Terms & Conditions.

Phone icon

Call 1-866-696-7189

Call for Expert AdviceCall for Expert Advice
Info icon

Does not apply to special order items.

30-day Return Policy

We guarantee the best price in Canada—before or 30 days after purchase.*

Lowest Price Guarantee*

Product Description

TOA BG-2060 CU D00 5-Input Mixer/Amplifier

The BG-2060 is a 60 W 5-input mixing amplifier for general announcements and background music. It is designed for use in pubs, retail businesses, and banquet spaces, and includes the MOH OUT feature, which allows for 2-channel broadcasting when used with the optional booster amplifier BA-235 (35 W) or BA-260 (60 W).

Specifications

-Power Source: 120 V AC, 60 Hz -Rated Output: 60 W -Power Consumption: 163 W (rated output), 80 W (based on cULus standards) -Frequency Response: 50 Hz - 20 kHz -Total Harmonic Distortion: 0.5 % or less, at 1 kHz, rated output -Input: Mic: -60 dB*, 600 ?, electronically balanced, removable terminal block, Line 1: -10 dB*/ TEL: -20 dB*, Line 1/TEL selectable, 10 k?, electronically balanced, removable terminal block, Line 2, 3: -10 dB*, 10 k?, unbalanced, removable terminal block and, RCA jacks, Module -Output: Speaker: 4 ?, 25 V (10 ?), 70 V (83 ?), balanced, removable terminal block, MOH: 0 dB*, 600 ?, balanced, removable terminal block, Line: 0 dB*, 600 ?, unbalanced, removable terminal block -Output Regulation: 2 dB or less, no load to full load (1 kHz) -Phantom Power: On/Off switch for Mic, +24 V DC -S/N Ratio: Mic: 60 dB or more, Line 1/TEL, Line 2, 3, Module: 75 dB or more, (Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered) -Muting: Manual mute/Automatic mute -Tone Control: Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz

Features & Specs

-Power Source: 120 V AC, 60 Hz
-Rated Output: 60 W
-Power Consumption: 163 W (rated output), 80 W (based on cULus standards)
-Frequency Response: 50 Hz - 20 kHz
-Total Harmonic Distortion: 0.5 % or less, at 1 kHz, rated output
-Input: Mic: -60 dB*, 600 Ω, electronically balanced, removable terminal block, Line 1: -10 dB*/ TEL: -20 dB*, Line 1/TEL selectable, 10 kΩ, electronically balanced, removable terminal block, Line 2, 3: -10 dB*, 10 kΩ, unbalanced, removable terminal block and, RCA jacks, Module
-Output: Speaker: 4 Ω, 25 V (10 Ω), 70 V (83 Ω), balanced, removable terminal block, MOH: 0 dB*, 600 Ω, balanced, removable terminal block, Line: 0 dB*, 600 Ω, unbalanced, removable terminal block
-Output Regulation: 2 dB or less, no load to full load (1 kHz)
-Phantom Power: On/Off switch for Mic, +24 V DC
-S/N Ratio: Mic: 60 dB or more, Line 1/TEL, Line 2, 3, Module: 75 dB or more, (Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered)
-Muting: Manual mute/Automatic mute
-Tone Control: Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz
-Control: Mic gain control, Line 1/TEL gain control, Line 2 gain control, Line 3 gain control,, Module gain control, Bass tone control, Treble tone control, MOH out gain control, Mute control (Manual mute), Remote volume control, Mute sense control, Line 1/TEL selector switch, Phantom power switch (Mic), Auto mute switch (Mic, Line 1/TEL, Module), Mute receive switch (Mic, Line 1/TEL, Line 2, 3, Module), MOH assign switch (Mic, Line 1/TEL, Line 2, 3, Module), Power ON/OFF switch
-Indicator: Power LED, Signal level LED, Peak LED
-Operating temperature: 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
Operating Humidity: 35 % to 80 %RH (no condensation)
-Finish: Panel: ABS resin, black, Case: Steel plate, black, paint
-Dimensions: 264 (W) × 94.3 (H) × 267.3 (D) mm (10.39" × 3.71" × 10.52")
-Weight: 5.3 kg (11.68 lb)
-Accessory: Volume control cover: YA-920 ……5, Removable teminal plug (2 pins) ……4, Removable teminal plug (3 pins) ……2, Removable teminal plug (4 pins) ……1, Removable teminal plug (5 pins) … 1
-Option: Rack mounting bracket: MB-1000

Documents

Warranty

TOA Canada 5 Year Limited Manufacturers Warranty
