Blustream C44CS-KIT Contractor 4x4 HDBaseT CSC Matrix 70m (C44CS-KIT)
Product Description
Product Description
Blustream C44CS-KIT Contractor 4x4 HDBaseT CSC Matrix 70m (C44CS-KIT)
The Blustream C44CS-KIT is a 4x4 HDMI 2.0 HDBaseT matrix that distributes 4K 60Hz 4:4:4 video, audio, control, and Power over Cable over a single CAT cable with included RX70CSL receivers. It supports 4K UHD up to 40m and 1080p up to 70m, with down-conversion on HDBaseT outputs to accommodate mixed-resolution displays.
4K HDBaseT distribution over a single CAT cable
Advanced HDBaseT technology delivers video and audio over one CAT run, while Advanced Colour Space Conversion supports the HDMI 2.0 18Gbps specification including HDR. CSC feature compatible with RX70CSL only.
- Supports 4K 60Hz 4:4:4 UHD up to 40m; 1080p up to 70m
- HDCP 2.2 compliant with advanced EDID management
- Supports all industry standard video resolutions including VGA–WUXGA and 480i–4K
- Bitstream passthrough of multichannel surround sound including object‑based audio formats in line with HDMI specifications
Flexible 4x4 switching and mixed‑resolution support
Four HDMI inputs can be independently routed to four HDBaseT outputs, with simultaneous HDMI and HDBaseT available on Output 1. Video down‑conversion on HDBaseT outputs allows a display that supports lower resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 content while other outputs maintain the maximum original 4K UHD resolution.
- 4 x HDMI inputs to 4 x HDBaseT outputs
- Simultaneous HDMI + HDBaseT on Output 1
- Down‑conversion on HDBaseT outputs for mixed‑resolution systems
Comprehensive control and integration
The matrix provides multiple control pathways and integration tools for setup and daily operation, including a web interface module for configuration.
- Control via front panel, iOS/Android App, IR, RS‑232, or TCP/IP
- Bi‑directional IR on all HDBaseT outputs
- 3rd‑party drivers available for all major control brands
- 1U design for 19" rack‑mount integration; mounting kit included
Installation‑ready kit
The C44CS-KIT arrives with receivers and core accessories to deploy the system.
- Supplied with 4 x RX70CSL receivers
- Supports 12V PoC (Power over Cable) to power compatible HDBaseT receivers
- Supplied with Blustream IR receivers and emitters
Frequently Asked Questions
-
How far can the C44CS-KIT extend video?
It supports 4K 60Hz 4:4:4 UHD up to 40m and 1080p up to 70m.
-
Does it support mixed‑resolution displays?
Yes. HDBaseT outputs include video down‑conversion so a lower‑resolution display (4K 60Hz 4:2:0 or 1080p) can receive the signal while other outputs maintain maximum original 4K UHD resolution.
-
What inputs and outputs are available?
There are 4 HDMI inputs and 4 HDBaseT outputs, with Output 1 also providing a simultaneous HDMI output.
-
What control options are provided?
Control is available via the front panel, iOS/Android App, IR, RS‑232, or TCP/IP, and there is a web interface module for configuration.
-
Are third‑party control drivers available?
Yes. 3rd‑party drivers are available for all major control brands.
-
Does it support HDR and HDCP 2.2?
Advanced CSC supports the HDMI 2.0 18Gbps specification including HDR, and the matrix is HDCP 2.2 compliant. CSC feature is compatible with RX70CSL only.
-
What is included in the kit?
1 x C44CS matrix, 4 x RX70CSL receivers, 1 x rack mounting kit, 4 x mounting kits for RX70CSL, 4 x mounting feet, 1 x remote control, 4 x IR emitters, 5 x IR receivers, 1 x DB9 serial cable, 1 x 3.5mm‑to‑3.5mm IR control cable, 1 x quick reference guide, and IEC power cable(s).
Add the Blustream C44CS-KIT to your cart to deploy a 4x4 HDBaseT matrix with robust 4K routing and flexible control. For personalized system‑matching or setup advice, contact or visit Gibbys Electronic Supermarket for expert guidance.
