The Ultra Evolution Pinnacle represents the apex of SVS's relentless pursuit of audio perfection. Combining cutting-edge driver design, premium materials, and state-of-the-art cabinet architecture, this floorstanding speaker is the epitome of high-fidelity sound. Let's delve into what makes this speaker a standout in the world of audio.

Acoustically Centered Time Alignment Cabinet Architecture

SVS has crafted the Ultra Evolution Pinnacle with a unique cabinet architecture that ensures all drivers are vertically aligned on a single plane. This design choice means that sound from each driver reaches your ears simultaneously, creating an impeccably coherent and immersive soundstage. The midrange drivers and woofers are strategically placed above and below the tweeter, blending seamlessly to create an idealized "point source" of sound.

Diamond-Coated Aluminum Dome Tweeter

The tweeter in the Ultra Evolution Pinnacle is a marvel of modern material science. Utilizing a process called Vapor Deposition, a layer of diamond carbon is applied to the aluminum dome. This treatment enhances the rigidity and acoustic properties of the tweeter, pushing its frequency response beyond the limits of human hearing. The result is crystal-clear, airy highs with no measurable distortion. Additionally, the diamond coating extends the low-frequency response, ensuring a smooth transition with the midrange.

Quad 8” Glass Fiber Woofers in Force-Balanced Array

The Ultra Evolution Pinnacle features four 8-inch glass fiber woofers arranged in a force-balanced array. This setup delivers powerful, deep bass evenly throughout the listening area while addressing room modes. The mechanical energy from each front-firing woofer is counterbalanced by a rear-firing woofer, eliminating unwanted vibrations and coloration for pure, accurate low frequencies.

Dual 5.25” Glass Fiber Composite Midrange Drivers

The dual midrange drivers are designed for optimal performance, with a superb stiffness-to-mass ratio that ensures stunning dynamics and flawless tonal accuracy. These drivers convey midrange frequencies with exceptional clarity, bridging the gap between the deep bass and the sparkling highs.

Frequency Response and Sensitivity

The Ultra Evolution Pinnacle offers a wide frequency response from 24Hz to 40kHz (+/-3 dB), ensuring you experience every nuance of your music. With a nominal impedance of 6 ohms and a sensitivity of 88dB, this speaker can handle amplifier power ranging from 20 to 300 watts, making it versatile enough for various audio setups.

Precision Engineering

SVS employs meticulous anechoic and real-world measurements to fine-tune the Ultra Evolution Pinnacle. This attention to detail ensures that every speaker delivers pristine clarity, absolute transparency, stunning dynamics, and effortless bass. The result is a speaker that connects you deeply to the emotion of sound, whether you’re enjoying a symphony or the latest blockbuster.

Elegant Finishes

The Ultra Evolution Pinnacle is available in piano gloss black, piano gloss white, and real black oak veneer finishes. These options allow you to match the speaker to your décor while adding a touch of sophistication to any room.

User-Friendly Features

The speaker includes dual gold-plated 5-way binding posts for secure connections, dual 3-inch wide-flared rear-firing ports for improved bass performance, and both cloth and magnetic grille options. Additionally, the elastomer screw-in feet and spiked metal feet are adjustable for level, ensuring stability on any surface.

Cabinet Dimensions

The cabinet measures 49.61” (H) x 11.81” (W) x 18.14” (D), with overall dimensions of 50.2” (H) x 11.81” (W) x 18.14” (D) including the grille, feet, and binding posts. It ships in a package weighing 110.8 pounds and has an unboxed weight of 96.7 pounds, highlighting the substantial build quality of this speaker.

The SVS Ultra Evolution Pinnacle in Piano Gloss White is not just a speaker; it's a statement of sonic excellence, embodying the perfect blend of innovation, design, and performance.

FAQs

1. What makes the diamond-coated tweeter special? The diamond-coated tweeter enhances rigidity and extends frequency response, delivering clear and airy highs without distortion.

2. How does the force-balanced woofer array work? The force-balanced array features dual opposing woofers that eliminate mechanical coloration by balancing mechanical energy, resulting in pure, accurate bass.

3. What is Acoustically Centered Time Alignment? This design ensures that sound from all drivers reaches your ears simultaneously, creating a coherent and immersive soundstage.

4. Can the Ultra Evolution Pinnacle handle high power? Yes, with a recommended amplifier power range of 20 to 300 watts, it can handle a wide range of audio setups.

5. What finishes are available for the Ultra Evolution Pinnacle? It comes in piano gloss black, piano gloss white, and real black oak veneer finishes, allowing you to choose one that best matches your décor.
