JL Audio C7-100CT 1" Component Tweeter - Each – #99759

JL Audio C7-100ct 100W RMS 1" Component Car Tweeter - #99759

When it comes to high-performance audio, the JL Audio C7-100CT 1" component tweeter stands out as a masterpiece in automotive loudspeaker design. Designed with a commitment to precision and an arsenal of advanced development tools, this tweeter elevates your car audio experience to a whole new level. Whether you're a casual listener or a serious audiophile, the C7-100CT promises to deliver sound quality that’s nothing short of spectacular.

Unmatched High-Frequency Performance

At the core of the C7-100CT's design is its exceptional ability to reproduce high-frequency sounds. This tweeter features a corundum ceramic-coated aluminum alloy diaphragm. What does that mean for you? Simply put, it means you're getting crystal-clear treble frequencies with outstanding detail and accuracy. Thanks to the innovative suspension design, which employs a treated silk s-roll surround, you’ll experience smooth highs that are free from distortion. It’s like the sound is being delivered straight from a live performance, filling your vehicle with the richness of every note.

Designed for Active Systems

One of the key aspects of the C7-100CT is that it’s designed specifically for active audio systems. Unlike conventional tweeters that come with passive crossover networks, the C7-100CT thrives in a setup where it can be individually powered. This means you’ll need to pair it with a high-quality digital signal processor (DSP) like the JL Audio TwK™ 88 or the D8 amplifier. These tools allow for precise tuning and optimization of your audio system, ensuring that every frequency is finely balanced for optimal in-vehicle performance. It’s like having a custom audio engineer tuning your system to perfection!

The Magic of Immaculate Highs

When you listen to music through the C7-100CT, you'll be amazed by the immaculate highs it delivers. The edge-driven dome design ensures that the highs are not just loud but smooth and accurate. With the specialized corundum coating, this tweeter manages to handle breakup behaviors well beyond the audible range, eliminating any harshness from your listening experience. The elegant grille design adds a touch of sophistication, making it a perfect fit for any vehicle's interior.

Personalize Your Sound Experience

JL Audio has put years of effort into developing the C7 series, focusing on providing an unparalleled tuning solution to maximize performance. Each C7-100CT tweeter is sold individually, allowing you the freedom to design your audio system according to your personal taste. Whether you prefer a more laid-back sound or a punchy audio experience, the C7-100CT is neutral and uncolored, making it the perfect canvas for your audio masterpiece.

With the TüN audio-tuning software, you can adjust equalization, delay, and crossover filters to craft the ideal sound profile for your vehicle. It’s like painting a masterpiece where every brushstroke contributes to an incredible auditory experience.

Innovative Design Features

JL Audio didn’t cut corners when designing the C7-100CT. Here’s a breakdown of some of its innovative features:

• Dome Diaphragm: The diaphragm's corundum ceramic coating provides high stiffness and low mass, allowing it to maintain its shape at higher frequencies. This means no compromise on sound quality.
• Suspension Design: With a treated silk s-roll surround and ferrofluid in the magnetic gap, the tweeter's motion is finely controlled. This ensures optimum damping and excursion without compromising performance.
• Motor Design: Utilizing a high-density magnetic circuit with a neodymium magnet and U-Yoke motor topology, the C7-100CT minimizes distortion for a cleaner sound. Advanced finite element analysis (FEA) tools have optimized the motor magnetics, delivering a listening experience that's both powerful and clear.
• Acoustical Design: The tweeter housing is expertly shaped to enhance sensitivity within specific bandwidths, ensuring a balanced frequency response and improved control over directivity.

Performance Specifications

• Design Bandwidth: The C7-100CT performs exceptionally well across various filter settings:

1. 48 dB/octave filters: 3,000 Hz - 30,000 Hz
2. 24 dB/octave filters: 4,000 Hz - 30,000 Hz
3. 12 dB/octave filters: 5,000 Hz - 30,000 Hz

• Included Accessories: Each tweeter comes with flush and surface mounting fixtures, as well as a 15µF tweeter protection capacitor.
• Quality Assurance: Every C7-100CT is rigorously tested, verified, and assigned a unique serial number. Registering your speaker online grants you access to its specific Acoustical Test Report, ensuring you know exactly what you're getting.

Elevate Your Audio Game

If you're serious about car audio, the JL Audio C7-100CT is a game-changer. It’s designed to meet the demands of audiophiles who crave high-fidelity sound without compromise. The blend of cutting-edge technology, superior materials, and meticulous engineering makes it a standout choice for anyone looking to upgrade their vehicle’s sound system.

When you decide to integrate the C7-100CT into your audio setup, you're not just upgrading your speakers; you're transforming your entire auditory experience. You’ll feel like you’ve stepped into a concert hall every time you hit play.

Frequently Asked Questions

1. What is the frequency response of the JL Audio C7-100CT? The frequency response ranges from 3,000 Hz to 30,000 Hz, depending on the filter settings used.
2. Can the C7-100CT be used in passive systems? No, the C7-100CT is designed for active systems and does not come with passive crossover networks.
3. What type of amplifier is recommended for the C7-100CT? A high-quality amplifier with dedicated channels for each speaker is recommended. The JL Audio VXi amplifier with built-in DSP is an excellent choice.
4. How do I ensure optimal performance from the C7-100CT? Using a DSP like the JL Audio TwK™ 88 to set equalization, delay, and crossover filters will help achieve the best sound.
5. Is the C7-100CT sold as a pair or individually? The C7-100CT is sold individually, allowing you to customize your audio setup as desired.

C7-100ct Dimensions:
