Size & Weight
Dimensions (W x H x D) 18.13 in x 7.88 in x 18.59 in
Weight Approx. 28 lb (13 kg)
Display
Display System 4K SXRD™ panel, projection system
Display Resolution 720 x 576/50p, 720 x 480/60p, 1280 x 720/50p, 1280 x 720/60p, 1920 x 1080/50i, 1920 x 1080/60i, 1920 x 1080/24p, 1920 x 1080/50p, 1920 x 1080/60p, 1920 x 1080/120p, 3840 x 2160/24p, 3840 x 2160/25p, 3840 x 2160/30p, 3840 x 2160/50p, 3840 x 2160/60p, 4096 x 2160/24p, 4096 x 2160/25p, 4096 x 2160/30p, 4096 x 2160/50p, 4096 x 2160/60p
Light source Laser diode
Picture processor X1™ Ultimate for projector
General Features
Contrast ratio ∞: 1 (Dynamic Contrast)
Effective display size 0.61" x 3
Effective pixels 24,883,200 (3840 x 2160 x 3) pixels
Projection lens shift Manual, Vertical +/- 71%, Horizontal +/- 25%
Throw ratio 1.38:1 to 2.21:12
Hardware
Projection lens zoom / focus Manual (Approx. x1.60) / Manual
Interface
Input and Output Terminals HDMI (TWO INPUTS)3 – Digital RGB/Y Pb/Cb Pr/Cr, IR IN – Minijack, LAN – RJ45, 10Base-T/100BASE-TX, REMOTE – RS-232C, D-sub 9-pin (male), TRIGGER – Minijack, DC 12 V Max. 100 mA, USB – Type A, DC 5 V, Max. 500 mA
Operating Conditions
Operating temperature / humidity 41 °F to 95 °F (5 °C to 35 °C) / 20% to 80% (no condensation)
Storage temperature / humidity 14 °F to +140 °F (–10 °C to +60 °C ) / 20% to 80% (no condensation)
Power
Acoustic noise 24 dB4
Power requirement AC 100 V to 240 V, 50/60 Hz
Power consumption 295 W
Video Features
Light Output 2,000 lm
Color Light Output 2,000 lm
Eco and energy saving
Power Consumption (Standby Mode) 0.3 W (When "Remote Start" is set to "Off")
Power Consumption (Networked Standby Mode) – Terminals 0.5 W (LAN) (when “Remote Start” is set to “On”) When a LAN terminal is not connected, it becomes a low power consumption mode (0.5 W)
Standby Mode Activated After about 10 Minutes
Accessibility
Screen Reader Yes
Projector - Features
4K, SXRD
Projector - Size
181" and above
Color
Black
Bluetooth
Yes
Brightness (Lumens)
2200
HDMI Inputs
2
USB
Yes
