Cerwin Vega SRPM700.2DW 2-Channel SRPM Stroker Full Range Class-D Amplifier - White

Cerwin Vega SRPM700.2DW 2-Channel SRPM Stroker Full Range Class-D Amplifier - White

Cerwin Vega SRPM700.2DW amplifier delivers powerful output, clear full-range sound, and efficient performance in a compact white 2-channel Class-D amplifier. Part of the Cerwin-Vega RPM Stroker Series, this amplifier is designed for car audio enthusiasts who want precise sound reproduction, reliable high-output performance, and practical tuning controls in one streamlined package.

Efficient Class-D Power

The Cerwin Vega SRPM700.2DW uses an advanced high-efficiency full-range Class-D digital topology to produce impressive power while minimizing energy loss and heat buildup. This efficient design helps provide your speakers with consistent, clean power and dynamic sound with minimal distortion, even when you're listening at higher volume levels.

Why choose between power and efficiency? With its Class-D design, the SRPM700.2DW brings both together in a compact amplifier built for modern vehicle audio systems.

Precision Components and Rugged Construction

Inside the Cerwin Vega SRPM700.2DW, advanced surface-mount components work with a rugged 4-layer PCB architecture to support signal accuracy, durability, and stable performance. This carefully engineered construction helps the amplifier maintain reliable operation in demanding car audio environments.

The 4-layer PCB acts as the backbone of the amplifier, providing a solid foundation for the components and helping support consistent signal performance during demanding listening sessions.

Compact White Chassis with Flexible Inputs

The Cerwin Vega SRPM700.2DW features a compact white chassis with single-sided connections, giving it a clean, space-conscious design for vehicle audio systems. The practical layout makes it a convenient choice when working with limited space.

Its flexible input design accepts both high-level and low-level signals up to 12 volts. This allows the amplifier to integrate with factory radios or aftermarket head units, giving you more flexibility when building or upgrading your system.

Fine-Tune Your Full-Range Audio

The Cerwin Vega SRPM700.2DW includes fully variable crossovers ranging from 35Hz to 350Hz with 12dB per octave filtering. These adjustable controls let you fine-tune the frequency range sent to your speakers and tailor the amplifier to your particular audio setup.

Think of the crossover as a filter that helps direct the right frequencies where they belong. With the adjustable range, you have more control over how your speakers respond and how the overall system sounds.

Flexible Turn-On Options

The Cerwin Vega SRPM700.2DW provides multiple speaker-level turn-on options, including VOX signal sensing, DC offset, and remote turn-on. These choices provide added flexibility for different vehicle audio system configurations.

Top-mounted controls make adjustments quick and easy during system tuning. Instead of having to work around awkwardly positioned controls, you can access the adjustment points from the top of the amplifier.

Key Features of the Cerwin Vega SRPM700.2DW

• 2-channel full-range Class-D car amplifier
• White compact chassis
• High-efficiency digital amplifier topology
• Powerful output with dynamic full-range sound
• Advanced surface-mount components
• Rugged 4-layer PCB architecture
• Single-sided connections
• High-level and low-level inputs up to 12V
• Fully variable 35Hz–350Hz crossovers
• 12dB per octave filtering
• Multiple turn-on options including VOX, DC offset, and remote turn-on
• Top-mounted controls for convenient adjustments

Designed for High-Output Car Audio Systems

The Cerwin Vega SRPM700.2DW combines efficient Class-D technology, precision components, flexible signal inputs, and adjustable crossover controls in a compact 2-channel design. Its full-range architecture is built to provide powerful output and clear sound reproduction for vehicle audio systems.

With support for both high-level and low-level signals up to 12 volts, the SRPM700.2DW works with factory radios and aftermarket head units. The adjustable crossover range also gives you the flexibility to shape the frequency range according to your audio setup.

Power, Clarity, and Practical Control

The Cerwin Vega SRPM700.2DW brings together high-efficiency performance and useful tuning features without taking up unnecessary space. Its rugged 4-layer PCB, surface-mount components, compact white chassis, flexible inputs, and variable crossover controls make it a well-rounded option for upgrading a car audio system.

For drivers and audio enthusiasts looking for powerful full-range output with precise control, the SRPM700.2DW provides the performance-focused design expected from the RPM Stroker Series in a clean white finish.

A Focused Upgrade for Full-Range Audio

The Cerwin Vega SRPM700.2DW is designed to give your vehicle audio system powerful, efficient, and controlled full-range performance. With Class-D digital technology, a rugged 4-layer PCB, 35Hz–350Hz variable crossovers, flexible input options, and multiple turn-on methods, it offers the essential features needed for a high-output car audio setup.

Its compact white chassis adds a clean look while keeping the design space-conscious. When you want a 2-channel amplifier that combines efficient power delivery with practical sound-tuning controls, the SRPM700.2DW is built to handle the job.

Power Rating (RMS)

• Power @ 2Ω: 350W x 2
• Power @ 4Ω: 200W x 2
• Power Bridged @ 4Ω: 700W x 1

Power Supply

• Power Supply: Full WPM
• Power Supply Threshold: 10.0V-17.0V (DC)
• Idle Current: (0.7A)

Distortion

• THD 4 (1KHZ @4Ω): 0.05%
• S/N Ratio (A weighted @1W): 77.2 dBA
• S/N Ratio (A weighted @FP): 98.9 dBA

Input Sensitivity

• Low Level Input: 0.2mV-10.0V
• High Level Input: Up to 25W RMS

Input Impedance

• Low Level Input: 22KΩ

Output Stage

• Output Impedance: 0.047Ω
• Damping Factor (50Hz@4Ω): >250
• Bandwidth (-3db): 10Hz-35Hz

Crossover (1-12dB/Oct)

• Variable High-Pass: 40Hz-400Hz
• Variable low-Pass: 40Hz-400Hz

Dimensions

• Length x Width x Height: 8.66”x5.28”x1.75” (220mm x 134mm x 44.5 mm)

FEATURES

• Selectable X-over: Low Pass/Flat/High Pass
• Selectable Turn On Mode: REM/VOX/DC
• LED Power/Protect Light Indicator
• Output Clipping Indicator - Helps Set Gains
• MFR #: SRPM700.2DW

Frequently Asked Questions

1. What type of amplifier is the Cerwin Vega SRPM700.2DW? The Cerwin Vega SRPM700.2DW is a 2-channel full-range Class-D car amplifier designed for powerful output and clear sound reproduction.
2. What color is the Cerwin Vega SRPM700.2DW? The SRPM700.2DW features a white chassis.
3. What crossover range does the Cerwin Vega SRPM700.2DW offer? It features fully variable crossovers ranging from 35Hz to 350Hz with 12dB per octave filtering.
4. Can the Cerwin Vega SRPM700.2DW work with a factory radio? Yes. The amplifier accepts high-level and low-level inputs up to 12 volts, allowing integration with factory radios or aftermarket head units.
5. What turn-on options are available on the Cerwin Vega SRPM700.2DW? The amplifier offers VOX signal sensing, DC offset, and remote turn-on options.
