Kanto PMX900HD Full Motion TV Wall Mount for 65–140" TVs

Kanto PMX900HD Full Motion TV Wall Mount for 65–140" TVs

The Kanto PMX900HD gives you heavy-duty full motion control for TVs ranging from 65 to 140 inches. Designed to support up to 275 lb, this mount combines extensive adjustment, a wide VESA range, and a slim 2.7-inch retracted profile. Need to fine-tune your screen after it is already mounted? Its vertical and horizontal adjustment systems give you extra control over final TV placement.

Built for Extra-Large TVs

The Kanto PMX900HD supports displays from 65 to 140 inches and handles up to 275 lb, or 124.7 kg. Additionally, its VESA compatibility ranges from 200×100 to 1000×700, giving it the capacity needed for very large compatible screens. Like a strong foundation beneath a large structure, its heavy-duty design provides the support required for oversized displays.

Post-Mount Vertical Height Adjustment

The Kanto PMX900HD provides up to 2 inches, or 5.1 cm, of total post-mount height adjustment. Therefore, you can fine-tune the TV's vertical position after it is on the wall. This adjustment is particularly useful when positioning a screen within a recess or directly above a center-channel speaker.

Up to 22 Inches of Horizontal Offset

Off-center studs do not have to determine where the television sits. The Kanto PMX900HD offers up to 22 inches, or 55.8 cm, of total horizontal offset along the wall plate. As a result, you can shift the articulating arms horizontally and better center the display within your viewing area.

33-Inch Full Motion Extension

The dual articulating arms extend the Kanto PMX900HD from 2.7 inches to as much as 33 inches from the wall. Consequently, you gain generous reach for adjusting a large display while maintaining convenient access to rear inputs and cabling. When retracted, the mount keeps the TV remarkably close to the wall for a cleaner appearance.

Wide Swivel Range

The Kanto PMX900HD can swivel up to 90 degrees left or right, depending on the size and position of the display. This broad range lets you redirect the screen toward different viewing areas instead of keeping it locked in one forward-facing position. For a large television, that flexibility can make the room feel far less restrictive.

Toolless Tilt Adjustment

With its heavy-duty cam-lever system, the Kanto PMX900HD provides +12° to -3° of toolless tilt. You can adjust the viewing angle without reaching for additional tools, then secure the screen once you find the desired position. Want to change the angle to help manage glare? The tilt mechanism keeps those adjustments straightforward.

Slim Profile with Heavy-Duty Strength

Despite supporting very large televisions, the Kanto PMX900HD retracts to just 2.7 inches from the wall. That slim profile keeps the display closer to the surface while preserving the benefits of full motion articulation. The result is a cleaner, more finished appearance without giving up extension, swivel, or tilt capability.

Wide 35-Inch Wall Plate

The Kanto PMX900HD uses a 35-inch, or 88.9 cm, wall plate and accommodates dual studs with spacing up to 24 inches. Its extra-wide design provides additional flexibility when working with the wall structure and complements the mount's extensive horizontal offset capability.

Integrated Metal Cable Management

The Kanto PMX900HD includes integrated cable management channels made from metal rather than plastic. These channels help route and protect wiring while the mount moves through its range of motion. Additionally, aluminum covers conceal the lag bolts, helping the finished setup maintain a cleaner appearance.

Adjustable Horizontal Leveling

Small positioning adjustments can make a noticeable difference on a 140-inch screen. For that reason, the Kanto PMX900HD includes adjustable horizontal leveling to help refine the television's final position. Combined with vertical height adjustment and horizontal offset, it gives you several ways to dial in screen placement.

Organized Hardware and Included Accessories

The Kanto PMX900HD comes with a comprehensive hardware kit containing labeled lag bolts, spacers, and VESA screws. It also includes a paper wall template for marking pilot holes, an installation manual, and mounting hardware for wood stud and concrete applications. Keeping the hardware organized makes it easier to identify the required components during setup.

Product Specifications

• TV size compatibility: 65" to 140"
• Maximum weight allowance: 275 lb (124.7 kg)
• VESA compatibility: 200×100 to 1000×700
• Extension: 2.7" to 33"
• Swivel: Up to ±90° left or right
• Toolless tilt: +12° to -3°
• Post-mount height adjustment: Up to 2" (5.1 cm)
• Horizontal offset: Up to 22" (55.8 cm)
• Wall plate width: 35" (88.9 cm)
• Dual stud spacing: Up to 24"
• Product weight: 57.3 lb (26 kg)
• Shipping weight: 68.3 lb (31 kg)
• Shipping dimensions: 44.6" × 21.7" × 4.9" (113.3 × 55.2 × 12.5 cm)
• UPC: 800152726304

Heavy-Duty Control for Large-Screen Setups

The Kanto PMX900HD brings together high weight capacity, extensive full motion adjustment, post-mount positioning, and a low-profile design for very large televisions. With up to 33 inches of extension, 22 inches of horizontal offset, 2 inches of vertical adjustment, and support for TVs up to 140 inches, it gives you considerable control over where and how your screen sits.

Frequently Asked Questions

What TV sizes does the Kanto PMX900HD support? The Kanto PMX900HD is designed for compatible televisions ranging from 65 to 140 inches.

How much weight can the Kanto PMX900HD hold? It supports TVs weighing up to 275 lb, or 124.7 kg.

What VESA patterns are compatible with the Kanto PMX900HD? It supports VESA mounting patterns from 200×100 to 1000×700.

How far can the mount extend from the wall? It extends up to 33 inches and retracts to a slim 2.7-inch profile.

Can the TV position be adjusted after it is mounted? Yes. The mount provides up to 2 inches of vertical height adjustment and up to 22 inches of horizontal offset.
