Klipsch RCC-BTS Behind The Screen System

Product Description

Klipsch RCC-BTS Behind The Screen System

The Klipsch RCC-BTS Behind The Screen System has ruled the professional cinema space with exceptional sounding, high output cinema speakers designed and built at our factory in Hope, Arkansas. Now the same components used in those speakers all over the world can now bring movie night home. Utilizing the same acoustic and network components as our legendary professional cinema speakers, the all new Real Custom Cinema systems are specifically designed to bring the exceptional performance and power of these professional speakers to the home theatre. The modular false-wall design allows for incredibly easy system design and installation, while eliminating light creep from behind the screen for a professional cinema experience - acoustically and visually. Introducing the Real Custom Cinema Series from Klipsch. High performance, professional grade cinema speakers for the home. Proudly designed, engineered, and built in Hope, Arkansas, USA.

  • An ultra-premium, high performance behind-the-screen LCR/Sub system for 112”-121” wide screens
  • 18” high output polyfiber cinema subwoofer drivers
  • 15” high output polyfiber cinema woofers
  • 3” titanium HF cinema compression drivers
  • 90° x 60° Tractrix® Horns
  • Modular design ensures full coverage, easy installation, with no light creep
  • Premium double braced MDF construction with high impact textured black finish

Call our Custom Home Installation Team to book an appointment. 1-866-470-1556

Features & Specs

-Speaker System: Behind-the Screen Lcr/sub System For Screens 112”-121” In Width
-Max Continuous Output: 126 Db
-Max Peak Output: 132 Db
-System Frequency Response: 18 – 20khz
-Power Handling Lcrs (Each): 200w Continuous, 800w Peak
-Power Handling Subs (Each): 600w Continuous, 2400w Peak
-System Sensitivity: 107 Db, 2.83v @ 1m, 1/2 Space
-Horizontal Coverage: 90° +/- 20 (1.1khz – 20khz)
-Vertical Coverage: 60° +/- 20 (2.2khz – 20khz)
-Nominal Impedence: 8 Ohm
-Minimum Recommended Amplifier Power Lcrs: 200w Rms
-Minimum Recommended Amplifier Power Subs: 500w Rms
-High Frequency Drivers: (3) K-702 1.75” Titanium Compression Driver Mounted On A K-603-m Horn
-Low Frequency Drivers: (3) K-45-st 15” Poly Fiber Woofers
-Subwoofer Drivers: (2) K-49-ep 18” Poly Fiber Woofers
-Enclosure Type: Double Braced Dado And Rabbit Mdf
-Inputs: Dual 5-way Binding Posts
-System Height: 55” (139.7 Cm)
-System Width: 101.25” (257.18 Cm)
-System Depth: 20.25” (51.44 Cm)
-System Weight: 648 Lbs (293.93 Kg)
-Finish: Textured Black Paint
-Recommended Screen Width: 102” – 112”
-Recommended Screen Size: 16:9: 117” – 129”
-Recommended Screen Size(Diagonal): 1:2.35: 110” – 121”

Documents

Warranty

Klipsch offers a limited lifetime Warranty – Architectural Speakers
SKU: 213004

Save $5,180.00

$24,810.00
$29,990.00
Flash Sale Ends:

We guarantee the best price in Canada—before or 30 days after purchase.* Lowest Price GuaranteeLowest Price Guarantee*

Special Order
Style

This product is backorderable

  • An ultra-premium, high performance behind-the-screen LCR/Sub system for 102 - 122” wide screens and larger
  • 18” high output polyfiber cinema subwoofer drivers
  • 15” high output polyfiber cinema woofers
  • 3” titanium HF cinema compression drivers
  • 90° x 60° Tractrix® Horns
  • Modular design ensures full coverage, easy installation, with no light creep
  • Premium double braced MDF construction with high impact textured black finish
Sign up to get notified when it's in stock!

Remember to select the correct model if there are multiple options.

Call for Expert Help

*Quantities may be limited. First come first served. Gibbys Electronic Supermarket does not guarantee a notification when the product is in stock. By signing up, you agree to subscribe to our newsletters, receive marketing emails or be contacted by Gibbys Electronic Supermarket. You also agree to Gibbys' Terms & Conditions.

Phone icon

Call 1-866-696-7189

Call for Expert AdviceCall for Expert Advice
Info icon

Does not apply to special order items.

30-day Return Policy

We guarantee the best price in Canada—before or 30 days after purchase.*

Lowest Price Guarantee*

Product Description

Klipsch RCC-BTS Behind The Screen System

The Klipsch RCC-BTS Behind The Screen System has ruled the professional cinema space with exceptional sounding, high output cinema speakers designed and built at our factory in Hope, Arkansas. Now the same components used in those speakers all over the world can now bring movie night home. Utilizing the same acoustic and network components as our legendary professional cinema speakers, the all new Real Custom Cinema systems are specifically designed to bring the exceptional performance and power of these professional speakers to the home theatre. The modular false-wall design allows for incredibly easy system design and installation, while eliminating light creep from behind the screen for a professional cinema experience - acoustically and visually. Introducing the Real Custom Cinema Series from Klipsch. High performance, professional grade cinema speakers for the home. Proudly designed, engineered, and built in Hope, Arkansas, USA.

  • An ultra-premium, high performance behind-the-screen LCR/Sub system for 112”-121” wide screens
  • 18” high output polyfiber cinema subwoofer drivers
  • 15” high output polyfiber cinema woofers
  • 3” titanium HF cinema compression drivers
  • 90° x 60° Tractrix® Horns
  • Modular design ensures full coverage, easy installation, with no light creep
  • Premium double braced MDF construction with high impact textured black finish

Call our Custom Home Installation Team to book an appointment. 1-866-470-1556

Features & Specs

-Speaker System: Behind-the Screen Lcr/sub System For Screens 112”-121” In Width
-Max Continuous Output: 126 Db
-Max Peak Output: 132 Db
-System Frequency Response: 18 – 20khz
-Power Handling Lcrs (Each): 200w Continuous, 800w Peak
-Power Handling Subs (Each): 600w Continuous, 2400w Peak
-System Sensitivity: 107 Db, 2.83v @ 1m, 1/2 Space
-Horizontal Coverage: 90° +/- 20 (1.1khz – 20khz)
-Vertical Coverage: 60° +/- 20 (2.2khz – 20khz)
-Nominal Impedence: 8 Ohm
-Minimum Recommended Amplifier Power Lcrs: 200w Rms
-Minimum Recommended Amplifier Power Subs: 500w Rms
-High Frequency Drivers: (3) K-702 1.75” Titanium Compression Driver Mounted On A K-603-m Horn
-Low Frequency Drivers: (3) K-45-st 15” Poly Fiber Woofers
-Subwoofer Drivers: (2) K-49-ep 18” Poly Fiber Woofers
-Enclosure Type: Double Braced Dado And Rabbit Mdf
-Inputs: Dual 5-way Binding Posts
-System Height: 55” (139.7 Cm)
-System Width: 101.25” (257.18 Cm)
-System Depth: 20.25” (51.44 Cm)
-System Weight: 648 Lbs (293.93 Kg)
-Finish: Textured Black Paint
-Recommended Screen Width: 102” – 112”
-Recommended Screen Size: 16:9: 117” – 129”
-Recommended Screen Size(Diagonal): 1:2.35: 110” – 121”

Documents

Warranty

Klipsch offers a limited lifetime Warranty – Architectural Speakers
