Panamax C3-IP Compact Power Conditioner and Power Sequencer (C3IP)

Product Description

Panamax C3-IP Compact Power Conditioner and Power Sequencer

The Panamax® C3-IP is a BlueBOLT-enabled compact power conditioner and power sequencer with three separate outlet controls. BlueBOLT's cloud-enabled platform allows installers to monitor, control, and program power from anywhere. C3-IP's slim design makes it suitable for virtually any discrete installation, such as behind a flat screen, in a structured wiring enclosure, or at the back of a rack. Automatic over/under voltage protection via Panamax technology ensures fewer service calls and maximum equipment longevity.

C3-IP Features

  • Bluebolt™ Enabled Power Manager in a Small Package
  • 3 Independently Controlled Outlets
  • Protect-or-disconnect Surge protection
  • Filtration of standard EMI/RFI
  • Disconnect for Over/Under Voltage Load
  • Sequencing of Power
  • 12A Circuit Breaker Capacity
  • Wall Mounting Brackets Included

Features & Specs

  • AC Power : 120Vac 50/60Hz
  • Total Outlets : 3
  • Operating Control : Type 1
  • Total Current Capacity : 12A Maximum
  • Rated Impulse Voltage : 1500V
  • Voltage Protection Rating (UL1449) : L-N 500V
  • Initial Clamping Level : 200V Peak, 141 Vrms
  • Energy Dissipation : 1680 JoulesPeak Impulse
  • Current : 12,000
  • Protect-or-Disconnect : Yes
  • Over-Voltage Load Disconnect : 140 Vac
  • Under-Voltage Load Disconnect : 90 Vac
  • Filtration Technology : Standard RFI/EMI Filtration
  • Filtration Rating : 10dB @ 10kHz, 17dB @ 30kHz, 33dB @ 100kHz, 55dB @ 1MHz
  • Thermal Fusing : Yes
  • Cord Length : 0.5M IEC cord
  • Dimensions (LxWxH) : 7.35″ x 5.5″ x 1.58″
  • Weight : 2.6lbs

Environmental Specifications

  • Temperature : 0˚ C -+40˚ C (+32˚F- +104˚F)
  • Operating Humidity : 0-90% non-condensing
  • External Pollution Degree : Pollution Degree 2

Documents

Warranty

Panamax Canada Offers Limited Warranty
SKU: C3-IP UPC: 050616010351
