Wet Sounds REVO12XXXV4-B 12" 1200W RMS Marine DVC Subwoofer - Black - Each
Product Description
Product Description
Wet Sounds REVO12XXXV4-B 12" 1200W RMS Marine DVC Subwoofer - Black - Each
The Wet Sounds REVO12XXXV4-B is a 12-inch marine subwoofer built for extreme SPL performance and high-output audio systems. Designed for demanding marine and powersports applications, it combines high power handling with a heavy-duty construction that helps it stay controlled during extended high-output playback.
With 1200W RMS power and 2400W peak power, the Wet Sounds REVO12XXXV4-B is designed to deliver serious low-frequency output. Its advanced motor structure, integrated cooling system, and 4-inch dual voice coil work together to support high-power operation while helping manage heat under load.
Built for Extreme SPL Performance
The REVO12XXXV4-B uses advanced acoustical engineering and computer-aided design to create a subwoofer suited for competition-level marine audio systems. Its heavy-duty magnetic system and high-stiffness polypropylene, carbon fiber, and glass fiber cone provide the foundation for powerful bass reproduction.
Why settle for ordinary low-frequency output when the system is built around high-power performance? With an SPL rating of 89 dB and an Xmax of 11 mm, this 12-inch subwoofer is designed for systems where output and bass performance are central priorities.
Marine-Grade Construction
The powder-coated gloss black cast aluminum frame provides a durable foundation for the subwoofer, while the high-roll Santoprene thermoformed rubber surround is built for demanding environments. The reinforced cone construction adds stiffness, helping the driver maintain control during high-output operation.
The REVO12XXXV4-B is designed for marine and powersports applications where moisture, UV exposure, vibration, and temperature changes are part of the environment. Its 33.4-pound construction also reflects the substantial components used throughout the woofer.
Advanced Cooling for High-Power Operation
High-output bass generates heat, so the REVO12XXXV4-B uses an integrated multi-part cooling system to help keep voice coil temperatures under control. Its T-yoke heat sink and combination peripheral and pole piece venting are designed to improve heat management during demanding playback.
The result is a subwoofer engineered around sustained high-power use rather than short bursts alone. The 4-inch dual voice coil also gives you flexible wiring options for different amplifier configurations.
Dual 2-Ohm Voice Coil Design
The dual 2-ohm voice coil configuration provides flexibility when building a high-output system. Combined with 1200W RMS power handling, the 4-inch voice coil is designed for serious amplifier setups where the subwoofer needs to handle substantial power.
Gold-plated screw-down binding posts provide the connection point for the dual voice coil design, keeping the heavy-duty construction consistent from the frame to the terminals.
Designed for Enclosure Applications
The REVO12XXXV4-B is designed for enclosure-based systems and is optimized for both sealed and ported configurations. The recommended sealed enclosure volume is 1.2 cubic feet, while a 1.8 cubic foot ported enclosure is recommended when deeper high-output performance is desired.
For the ported enclosure design, the optimum tuning is 41 Hz. Think of the enclosure as part of the subwoofer itself—the right enclosure gives the driver the environment it needs to perform as intended.
12-Inch Design with Substantial Output
The REVO12XXXV4-B measures 12.4 inches in diameter and requires an 11.26-inch hole cutout. With a 6.53-inch mounting depth, it provides a substantial high-output driver platform for custom marine audio builds and enclosure applications.
With a 40 Hz Fs, 510.7 cm² Sd, 24-liter Vas, and 242 g Mms, the driver is engineered around the low-frequency demands of high-output marine audio. Its 0.39 Qts and 0.42 Qes further define its electro-mechanical characteristics for enclosure design.
Specifications
Power & Performance
- Peak Power: 2400W
- RMS Power: 1200W
- Impedance: Dual 2 Ohm
- Voice Coil Size: 4.0"
- SPL: 89 dB
- Xmax: 11 mm
Subwoofer Specifications
- Subwoofer Size: 12"
- Frequency Resonance (Fs): 40 Hz
- Voice Coil Configuration: Dual Voice Coil
- Effective Cone Area (Sd): 510.7 cm²
- Moving Mass (Mms): 242 g
- Equivalent Compliance Volume (Vas): 24 Liters
Construction & Design
- Frame: Powder-Coated Gloss Black Cast Aluminum
- Cone: Polypropylene / Carbon Fiber / Glass Fiber
- Surround: High-Roll Santoprene
- Magnetic System: Heavy-Duty
- Cooling: T-Yoke Heat Sink with Peripheral and Pole Piece Venting
- Terminals: Gold-Plated Screw-Down Binding Posts
- Cone Color: Black
Dimensions & Fitment
- Overall Diameter: 12.4" (314.96 mm)
- Mounting Depth: 6.53" (165.86 mm)
- Hole Cutout: 11.26" (286.00 mm)
- Weight: 33.4 lbs (15.14 kg)
Enclosure Specifications
- Application Type: Enclosure
- Sealed Enclosure: 1.2 cu ft
- Ported Enclosure: 1.8 cu ft
- Recommended Ported Tuning: 41 Hz
Technical Parameters
- Qms: 5.00
- Qes: 0.42
- Qts: 0.39
- Le: 0.5 mH
- Bl: 11.9 T*m
Ideal Marine Applications
- Wake Boats
- Performance Tow Boats
- Center Consoles
- Offshore and Sport Boats
- Custom Marine Audio Builds
- High-Output SPL Marine Systems
From its 1200W RMS power handling to its heavy-duty motor and cooling system, the Wet Sounds REVO12XXXV4-B is built around the demands of extreme marine SPL audio. With a dual 2-ohm 4-inch voice coil, 12-inch driver, marine-grade materials, and enclosure options for sealed or ported systems, it provides a purpose-built foundation for high-output bass in demanding environments.
FAQs
- How much power does the Wet Sounds REVO12XXXV4-B handle? It is rated for 1200W RMS power and 2400W peak power.
- What is the impedance of the REVO12XXXV4-B? The subwoofer features a dual 2-ohm voice coil configuration.
- What size voice coil does this subwoofer use? The REVO12XXXV4-B uses a 4.0-inch dual voice coil.
- What enclosure sizes are recommended? The recommended enclosure volume is 1.2 cubic feet sealed or 1.8 cubic feet ported, with the ported enclosure optimally tuned to 41 Hz.
- How much does the REVO12XXXV4-B weigh? The subwoofer weighs 33.4 pounds, or 15.14 kg.
