Wet Sounds SYN-DX2.3HP Class D 2-Channel Marine Amplifier

Wet Sounds SYN-DX2.3HP Class D 2-Channel Marine Amplifier

The Wet Sounds SYN-DX2.3HP delivers high-output amplification for marine and powersports audio systems that need strong, controlled power in a compact design. Part of the SYN-DX Series, this Class D 2-channel amplifier combines performance circuitry with efficient power delivery, making it a practical choice for demanding audio setups where space and current draw matter.

High Power in a Compact Design

When your audio system needs more power without taking up unnecessary space, the Wet Sounds SYN-DX2.3HP offers a compact solution. Its Class D power supply supports high output while helping maintain thermal efficiency and reduced current draw. The 2-channel configuration works with full-range speaker systems or bridged applications, giving you flexibility when planning your audio setup.

Flexible Crossover Controls

Fine-tune your system with fully variable high-pass and low-pass crossovers. Both crossover ranges extend from 50 Hz to 500 Hz with a 12 dB-per-octave slope, allowing you to adjust the amplifier to suit your audio configuration. Extended input compatibility also helps simplify integration into a variety of systems.

Protection for Marine Environments

Marine and powersports audio equipment must handle challenging conditions. The Wet Sounds SYN-DX2.3HP features thermal overload protection, smart microprocessor-controlled operation, and a conformal-coated PCB board. These design elements support dependable operation in environments exposed to moisture, vibration, and temperature extremes.

Power Output and Specifications

The SYN-DX2.3HP provides two-channel amplification with the option to bridge the channels for a higher-power output. Its listed power ratings make it suitable for a range of compatible speaker configurations.

• Channels: 2
• Amplifier Class: Class D
• Power at 4 Ohms: 300W x 2
• Power at 2 Ohms: 600W x 2
• Bridged Power at 4 Ohms: 1200W x 1
• Input Sensitivity: 0.2V–6.0V
• High-Pass Crossover Range: 50Hz–500Hz, 12dB/octave
• Low-Pass Crossover Range: 50Hz–500Hz, 12dB/octave
• Frequency Response: 20Hz–20kHz
• Chassis Dimensions: 14.63" x 8.52" x 3.08"

Versatile Marine and Powersports Applications

The Wet Sounds SYN-DX2.3HP is designed to work with Wet Sounds speakers and subwoofers, making it a useful option for building or expanding an audio system. Its compact chassis and flexible crossover controls suit a variety of applications, including boats, wake and surf boats, UTVs, ATVs, side-by-sides, motorcycles, Jeeps, off-road vehicles, golf carts, and custom outdoor audio systems.

With high output, adjustable crossover controls, and protective circuitry, the Wet Sounds SYN-DX2.3HP brings flexible amplification to demanding marine and powersports audio systems. Its two-channel design and bridging capability give you options for configuring compatible speakers while keeping the amplifier footprint compact.

Frequently Asked Questions

1. How many channels does the Wet Sounds SYN-DX2.3HP have? It is a 2-channel Class D marine amplifier.
2. How much power does the SYN-DX2.3HP produce? It is rated at 300W x 2 at 4 ohms, 600W x 2 at 2 ohms, and 1200W x 1 when bridged at 4 ohms.
3. Does the Wet Sounds SYN-DX2.3HP have adjustable crossovers? Yes. It features variable high-pass and low-pass crossovers, each with a 50Hz–500Hz range and a 12dB-per-octave slope.
4. What is the frequency response of this amplifier? Its listed frequency response is 20Hz–20kHz.
5. What audio systems can use the SYN-DX2.3HP? It is designed for marine and powersports systems, including boats, wake and surf boats, UTVs, ATVs, side-by-sides, motorcycles, Jeeps, off-road vehicles, golf carts, and custom outdoor audio installations.
